StarTech.com VID2HDCON Manual de usuario

Manual Revision: 07/28/2011

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

VID2HDCON

Composite/S-Video to HDMI Video Converter

with Audio

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on,

the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual i

Table of Contents

Introduction............................................................................................. 1

Packaging Contents ..........................................................................................................................1

System Requirements.......................................................................................................................1

Front View.............................................................................................................................................2

Rear View...............................................................................................................................................2

Side View...............................................................................................................................................3

Installation ............................................................................................... 4

Hardware Installation .......................................................................................................................4

Driver Installation...............................................................................................................................4

Specications........................................................................................... 6

Technical Support ................................................................................... 7

Warranty Information............................................................................. 7

Instruction Manual 1

Introduction

The VID2HDCON Composite and S-Video to HDMI® Video Converter with Audio

lets you connect an S-Video or Composite device with supporting 3.5mm audio

to your HDMI monitor or television.

Equipped with convenient selector switches for conguration, the S-Video/

composite converter is able to function in both NTSC and PAL systems, and

oers support for output resolutions up to 1600x1200 (PC) or 1080p (TV) to

seamlessly integrate with almost any display.

An integrated 3.5mm audio connection provides the ability to send your

output through a single HDMI cable to your destination display, avoiding the

hassle of running a separate audio cable.

Packaging Contents

• 1 x Video Converter

• 1 x Universal Power Adapter

• 3 x Power Adapter plug (NA/UK/EU)

• 1 x Instruction Manual

System Requirements

• Composite or S-Video enabled video source (i.e. DVD player, PVR/DVR, etc.)

• Composite or S-Video cable

• HDMI enabled display device (e.g. monitor, projector, etc.)

• HDMI cable

• Available AC electrical outlet

Instruction Manual 2

Front View

Rear View

Instruction Manual 3

Side View

Instruction Manual 4

Installation

Hardware Installation

1. Make sure all devices and components are powered o.

2. Connect the video source to the input side of the video converter using

either an S-Video or composite RCA cable (both sold separately).

3. For audio, connect a 3.5mm Audio mini-jack cable into the “Audio In”

connector on the converter. Audio will be combined and output through

HDMI.

4. Plug the power adapter into the video converter. The Input indicator LED will

light up steady.

5. If not already set to the correct input, press the Input selector button to

change the input source. The LED will light up green for composite and red

for S-Video.

6. Connect the display to the converter using a male/male HDMI cable (sold

separately).

7. Set the Output Signal Mode selector switch along the side of the video

converter to the type of display you are using: “HD”for a TV and “PC” for a

monitor.

8. Select the output resolution using the slide switch next to the HDMI output

connector. Make sure to select an output resolution that is supported by the

display device.

9. Power on the display device.

10.Power on the video source.

Driver Installation

The video converter is an external pure hardware converter, so no driver or

software installation is required.

Instruction Manual 5

Specications

Video Signal (Input) Composite

S-Video

Video Signal (Output) HDMI

Connectors

1 x RCA Composite female

1 x S-Video 4-pin female

1 x HDMI type A female

1 x DC Power

LEDs 1 x Input Selection

Supported Video Systems NTSC, PAL

Supported Video Output

PC: XGA (1024x768), SXGA (1280x1024),

UXGA (1600x1200) @ 60 Hz

HD: 480p, 720p, 1080p @ 50/60 Hz

On Screen Display Yes

Audio Support Yes

Power Adapter 5V DC, 1000mA, center positive,

type M plug

Enclosure Material Plastic

Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)

Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)

Humidity 20% ~ 90% RH

Dimensions (LxWxH) 165.0mm x 162.6mm x 33.5mm

Weight 100g

Instruction Manual 6

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and

workmanship for the periods noted, following the initial date of purchase. During this

period, the products may be returned for repair, or replacement with equivalent products

at our discretion. The warranty covers parts and labor costs only. StarTech.com does not

warrant its products from defects or damages arising from misuse, abuse, alteration, or

normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need.

From the latest technology to legacy products — and all the parts that

bridge the old and new — we can help you nd the parts that connect

your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever

they need to go. Just talk to one of our tech advisors or visit our website.

You’ll be connected to the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com

products and to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and

technology parts. StarTech.com was founded in 1985 and has operations in the

United States, Canada, the United Kingdom and Taiwan servicing a worldwide

market.
