StarTech.com MCMGBSC15 Manual del sistema

1000 Mbps Gigabit Single-Mode Fiber Ethernet Media Converter SC 15km

StarTech ID: MCMGBSC15

The MCMGBSC15EU Ethernet Media Converter converts transparently to/from 1000Base-T Ethernet signals

and 1000Base-LH optical signals, providing a cost-effective Ethernet-fiber/copper-fiber link. - Perfect perfect for

extending an Ethernet network connection over a Single Mode fiber backbone.

Supporting a Single Mode fiber optic cable distance of up to 15-kilometers (9.32-miles), this Fiber Media

Converter delivers a simple solution for connecting Gigabit Ethernet networks to remote locations using SC-

terminated SM fiber, while ensuring solid network performance and scalability.

Applications

Extending an Ethernet connection by up to 15km (9.32 miles) using a fiber backbone

Creates an economical Ethernet-fiber/copper-fiber link for connecting remote sub-networks to larger fiber

optic networks/backbones

Converts Ethernet to fiber, fiber to copper/Ethernet, ensuring optimum network scalability for connecting

two or more Ethernet network nodes (e.g. connecting two buildings on the same campus)

www.startech.com/m

1 800 265 1844

Features

Auto detects half/full duplex transfer mode from the TX port

Auto negotiation MDI/MDI-X (Crossover for TX port)

Compact design

LED Indicators for simple Ethernet/Fiber network link monitoring

Simple installation

Supports forced full duplex or auto-negotiation modes on the fiber link

Supports 802.3ab 1000Base-TX, and 1000Base-LX/LH industry standards

Supports a maximum Single-mode fiber optic cable distance of 15km

Supports IEEE 802.1q Tag VLAN pass through

Supports transparent Q-in-Q double tagged frames

1310nm Wavelength

www.startech.com/m

1 800 265 1844

Technical Specifications

Warranty 2 Years

Industry Standards IEEE 802.3z 1000BASE-LX/LH

PoE No

WDM No

Fiber Operating Mode Half/Full-Duplex

Fiber Type Single Mode

Max Transfer Distance 15 km (9.3 mi)

Maximum Data Transfer Rate 1000 Mbps (1 Gbps)

Wavelength 1310nm

Local Unit Connectors 1 - RJ-45 Female

Remote Unit Connectors 1 - Fiber Optic SC Duplex Female

Color Black

Product Height 1.1 in [27 mm]

Product Length 3.9 in [99 mm]

Product Weight 15.9 oz [450 g]

Product Width 2.9 in [73 mm]

LED Indicators 1 - FX Link: On - Valid Fiber Link

LED Indicators 1 - Power Indicator

LED Indicators 1 - TP Link: On - Valid Ethernet Link

LED Indicators 1 - TP RX: On - Receiving Data on the Ethernet Link

Center Tip Polarity Positive

Input Current 0.3 A

Input Voltage 110 ~ 240 AC

Output Current 0.6A

Output Voltage 9 DC

Plug Type M

Power Source AC Adapter Included

Humidity 90% RH

Operating Temperature 0°C to 40°C (32°F to 104°F)

Storage Temperature -10°C to 70°C (14°F to 158°F)

Shipping (Package) Weight 1 lb [0.5 kg]

Included in Package 1 - Media Converter

Included in Package 1 - Power Adapter

www.startech.com/m

1 800 265 1844

Included in Package 1 - Instruction Manual

Certifications, Reports and Compatibility

www.startech.com/m

1 800 265 1844
