StarTech.com USB3SMDOCKV Manual de usuario
Travel Docking Station for Laptops - VGA - USB 3.0
Product ID: USB3SMDOCKV
This travel docking station lets you turn your laptop into a mobile workstation. It’s a travel-friendly solution that helps
you connect extra devices to any computer, even when you’re on the move.
With a lightweight design, this compact laptop docking station tucks neatly into your travel bag. Now, you can avoid
the nuisance of carrying multiple adapters, by consolidating three essential connection ports into one convenient
device.
Plus, the portable docking station complements your Ultrabook nicely, with an aesthetically matching black and silver
housing.
Providing added distance flexibility via an integrated extended-length (21”) USB 3.0 host cable, you can easily
connect a VGA monitor as a second display.
The versatile docking station also adds Gigabit Ethernet and a USB 3.0 port to your laptop, letting you set up a
multi-functional workstation on the run. Plus, you don’t have to worry about sacrificing one of your laptop USB ports.
To save you time, setup is seamless and hassle-free. The travel dock automatically downloads the latest driver when
connected to a Windows system with an active network connection.
The universal travel docking station for laptops works with almost any USB 3.0 capable system. It’s USB-powered
too, so you can get up and running without the aggravation of searching for an available power outlet.
The USB3SMDOCKV is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Work from your Ultrabook or laptop easily, while you’re on the run or on the road, by adding essential connectivity
options
• Use your laptop as a multi-display workstation, through external monitor support
• Connect to your VGA-equipped projector and display multimedia content in boardrooms
• Connect your laptop to a wired Gigabit network in situations where a WiFi connection isn't available, such as in
classrooms, offices, and hotels
Features
• VGA video, USB 3.0 hub port, and GbE through a single USB 3.0 cable
• Compact and lightweight for maximum portability — multiple connection options in a travel-friendly casing
• Built-in, extended-length USB 3.0 cable for convenience and distance flexibility
• USB bus-powered - No external power adapter required (optional auxiliary USB power cable included)
• Hassle-free setup - Latest drivers are automatically downloaded in Windows systems when an active network
connection is present
• IEEE 802.3, 802.3u and 802.3ab (10BASE-T, 100BASE-TX, and 1000BASE-T) compatible
• SuperSpeed USB 3.0 (5 Gbps) interface, backward compatible with USB 2.0
• Support for resolutions up to 2048x1152 (QWXGA)
• Choose between Mirrored, Extended or Primary display configurations
Hardware
Warranty
3 Years
4K Support
No
Fast-Charge Port(s)
No
Displays Supported
1
Bus Type
USB 3.2 Gen 1 (5Gbps)
Industry Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Hub port supports USB 2.0/1.1 backward-compatibility
Chipset ID
DisplayLink - DL-3700
Performance
Maximum Data Transfer
Rate
5 Gbps (USB 3.0) <br / >2 Gbps (Ethernet; Full-Duplex)
Maximum Analog
Resolutions
2048x1152 (VGA)
Type and Rate
USB 3.0 - 5 Gbit/s
UASP Support
Yes
Compatible Networks
10/100/1000 Mbps
Auto MDIX
Yes
Full Duplex Support
Yes
Connector(s)
Connector Type(s)
1 - USB Type-A (9 pin, 5 Gbps)
1 - VGA (15 pin, High Density D-Sub)
1 - RJ-45
1 - USB Type-A (9 pin, 5 Gbps)
1 - USB Micro-B (5 pin)
Software
OS Compatibility
Windows XP SP3 (32-bit), Vista, 7, 8, 8.1, 10, 11
macOS 10.6 to 10.12, 11.0, 12.0, 13.0, 14.0
Special Notes /
Requirements
System and Cable
Requirements
USB enabled computer system with available USB 3.0 port
Note
Micro USB Port (Auxiliary Power Input Port)
If necessary the provided USB power cable may be connected to
draw additional power from the host computer in order to
sufficiently power all outputs simultaneously
Indicators
LED Indicators
1 - Power
1 - Link/Activity
1 - Link
Power
Power Source
USB-Powered
Environmental
Operating Temperature
0C to 50C (32F to 122F)
Storage Temperature
-20C to 60C (-4F to 140F)
Humidity
5~85% RH
Physical
Characteristics
Color
Black & Silver
Material
Plastic
Cable Length
21.0 in [534 mm]
Product Length
4.2 in [10.6 cm]
Product Width
2.7 in [6.8 cm]
Product Height
1.0 in [2.5 cm]
Weight of Product
4.4 oz [126 g]
Packaging
Information
Package Quantity
1
Package Length
5.7 in [14.4 cm]
Package Width
8.1 in [20.7 cm]
Package Height
1.9 in [47 mm]
Shipping (Package)
Weight
9.2 oz [260 g]
What's in the Box
Included in Package
1 - USB 3.0 Mini Docking Station
1 - USB Power Cable
1 - Driver CD
1 - Instruction Manual
*Product appearance and specifications are subject to change without notice.
