Philips BTM630/12 Manual de usuario

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

User Manual

Aux-in Cable MW antenna

FM antenna

Remote Control with

two AAA batteries

Quick Start Guide

User manual

Quick Start Guide

BTM630

AC power adaptor 8 X iPod dock adaptors

BTM630 QSG_12_Eng 2007.9.24, 16:261

AC power adaptor

MW loop

antenna

FM wire antenna

Connect the MW and FM antennas.

Connect the AC power adaptor of the system.

Tips

– See the User Manual for how to

connect other equipment to this

system.

– Use the supplied AC power

adaptor only! Using any other

power connection device may

damage your main set!

Setting the clock

In standby mode, press PROG on the system (or PROG/CLOCK on the remote control).

➜ SET CLOCK is displayed briefly.Then, 12HR or 24HR is displayed.

Press ALBUM•PRESET +/- on the system (or 3/4on the remote control) to select

clock mode. Press PROG on the system (or PROG/CLOCK on the remote control) to

confirm.

➜The clock digits for the hours continue to flash.

Press ALBUM•PRESET +/- on the system (or 3/4on the remote control) to set the

hours.

Press PROG on the system (or PROG/CLOCK on the remote control) again.

➜The clock digits for the minutes flash.

Press ALBUM•PRESET +/- on the system (or 3/4on the remote control) to set the

minutes.

Press PROG on the system (or PROG/CLOCK on the remote control) to confirm the

time.

BTM630 QSG_12_Eng 2007.9.24, 16:262

Enjoy

Playing a disc

Insert a disc into the disc loader.

➜Make sure the label side is facing up.

In DISC mode, press ÉÅ to start playback.

To stop playback, press 9.

Insert the USB device’s USB plug into the socket or fully insert the SD/MMC card into

the SD • MMC slot on the top of the system.

Press SOURCE once or more (or USB/CARD on the remote control) to select USB/

CARD.

Play the available audio files as you do with the albums/tracks on a CD.

Playing a USB mass storage device/SD/MMC card

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards.

Operating a Bluetooth-enabled device via the system

Place a Bluetooth-enabled device for pairing within 10 meters from the system.

Press SOURCE on the top of the system (or BLUETOOTH on the remote control) to

select the Bluetooth source.

Press and hold ANSWER/PAIRING on the top of the system or the remote control

for more than 3 seconds.

Set the Bluetooth-enabled device to search for other available Bluetooth devices until it

recognizes “PHILIPS BTM630”.

Select “PHILIPS BTM630” and wait until you hear a double beep from the system and the

Bluetooth icon turns on.

➜Enter “0000” when prompted for a keyword.

For a paired HFP and/or HSP mobile phone, you can receive, reject or hold a call via the

system with the ANSWER/PAIRING , REJECT and 9buttons respectively.

●For a paired A2DP device, you can enjoy music from it with the ÉÅ, ¡ / ™, S/Tand

9 buttons via the system.

BTM630 QSG_12_Eng 2007.9.24, 16:263

Enjoy

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

CRoyal Philips Electronics N.V. 2007

Playing Apple iPod using BTM630

Select the correct dock adaptor, as indicated on each adaptor, then fit it in

the dock.

Correctly place the compatible iPod player into the dock.

Press SOURCE on the system repeatedly or iPod on the remote control

to select the iPod source.

Power on your iPod player.

Select and play your favourite songs stored in the iPod player.

Programming and tuning to radio stations

Press SOURCE repeatedly (or TUNER on the remote control) to

select the tuner source.

Press PROG on the system (or PROG/CLOCK on the remote

control) for more than two seconds to program all available stations

in order of waveband.

Press ALBUM•PRESET +/- on the system (or 3/4on the remote

control) until the desired preset station is displayed.

Notes for remote control:

–First select the source you wish to

control by pressing one of the source

select keys on the remote control (for

example CD,TUNER).

–Then select the desired function (for

example

ÉÅ

BTM630 QSG_12_Eng 2007.9.24, 16:264
