StarTech.com USB3DDOCKFT Manual de usuario

Manual Revision: 07/13/2015

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the latest information, technical specications, and support for

this product, please visit www.startech.com/USB3DDOCKFT

USB3DDOCKFT

Docking station for two laptops

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Product diagram ....................................................................................3

Front view .................................................................................................................................................... 3

Rear view...................................................................................................................................................... 3

About USB 3.0 and USB 3.1...................................................................4

About installation ..................................................................................4

Install the driver......................................................................................................................................... 4

Install the hardware.................................................................................................................................. 4

Switch which host to control ................................................................................................................ 5

About the docking station ports .........................................................5

Charge a device ......................................................................................5

Charge an iPad with a 30-pin dock connector ............................................................................... 5

Congure a display device....................................................................6

Use DisplayLink to congure a display device ............................................................................... 6

About the display options ....................................................................6

Use Mac OS to congure a display device ....................................................................................... 7

Use Mac OS to change the display mode......................................................................................... 7

Use Mac OS to change the primary display..................................................................................... 7

Supported video resolutions ...............................................................8

Transfer les and settings between the connected host laptops ..8

Use PCLinq software to transfer les ................................................................................................. 8

Use Windows Easy Transfer to migrate settings and transfer les........................................... 9

Technical support...................................................................................10

Warranty information............................................................................10

Instruction Manual

Introduction

Packaging Contents

• 1x laptop docking station

• 2x USB 3.0 host cables

• 1x universal power adapter (NA/EU/UK/AU)

• 1x instruction manual

System Requirements

The docking station requires the following:

• One or two USB-enabled host computer system(s) with an available USB 3.0 port on

each host

• Available AC electrical outlet(s)

• DisplayPort™ and HDMI® enabled display(s) with cables as desired (for additional

external displays)

• Windows® 7 (32-bit and 64-bit)

• Windows 8 (32-bit and 64-bit)

• Windows 8.1 (32-bit and 64-bit)

• Mac OS®10.8 and later (tested up to 10.10)

Note: If you connect the docking station to a USB 2.0 host port or if you use a USB 2.0

host connection cable, performance may be limited.

PCLinq supports the following operating systems:

• Windows 7 (32-bit and 64-bit)

• Windows 8 (32-bit and 64-bit)

• Windows 8.1 (32-bit and 64-bit)

• Windows XP SP2 or SP3 (32-bit and 64-bit)

• Windows Vista

• Mac OS 10.8 and later

Windows Easy Transfer supports the following operating systems:

• Windows 7 (32-bit and 64-bit)

• Windows 8 (32-bit and 64-bit)

Instruction Manual

• Windows XP SP2 or SP3 (32-bit and 64-bit)

• Windows Vista

Note: In Windows 8.1, Microsoft® removed support for cables from the Windows Easy

Transfer software.

Operating system requirements are subject to change. For the latest requirements,

please visit www.startech.com/USB3DDOCKFT

Instruction Manual

3.5mm TRRS headset port

(audio and microphone)

USB 3.0 fast-charge and

sync port

Product diagram

Front view

Rear view

Switch host button

Power

switch

USB 3.0

ports

HDMI

port

RJ45

port

Security

lock port

DisplayPort

USB 3.0

host ports

DC input

port

Instruction Manual

About USB 3.0 and USB 3.1 Gen 1

USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard oers speeds up to

5 Gbps.

About installation

Depending on the version of operating system that you’re currently running and

whether your network connection is active, the docking station might install

automatically or download the proper drivers when the dock is connected to an

available USB port on the host system.

If you receive a prompt to automatically install the driver, complete the on-screen

instructions to complete the installation.

Install the driver

1. On the rst host laptop, use a web browser to navigate to http://www.startech.com/

USB3DDOCKFT.

2. Click the Support tab.

3. Click the driver le and complete the on-screen instructions to download the le.

4. Browse to the location of the driver le that you downloaded and do one of the

following:

• If the operating system that you’re using is a version of Windows, run the

DisplayLink “exe” install le.

• If the operating system that you’re using is a version of Mac OS, run the

DisplayLink “dmg” install le.

5. Follow any on-screen instructions to complete the driver installation process.

6. Repeat the driver installation steps above on the second host laptop.

Note: You may be asked to restart your host laptop(s) to complete the installation.

Install the hardware

1. Select the appropriate regional clip for your region and connect the power adapter

to an AC electrical outlet.

2. Connect the power adapter to the DC input on the docking station.

3. Attach one of the provided USB 3.0 cables to the “HOST 1”USB 3.0 host port on the

docking station and then to an available USB 3.0 port on the rst host laptop.

4. Attach the second provided USB 3.0 cable to the “HOST 2” USB 3.0 host port on the

docking station and then to an available USB 3.0 port on the second host laptop.

5. Connect your DisplayPort and/or HDMI displays to the corresponding ports on the

docking station.

Instruction Manual

6. As necessary, connect any other devices to the docking station, including an RJ45

network connection, USB peripherals, a headset, speakers, or microphones.

Switch which host to control

1. Ensure that both host laptops are connected to the docking station’s two USB 3.0

host ports.

2. Press the“HOST SWITCH” button on the side of the docking station to cycle between

which host laptop to control.

The docking station’s ports, functionality, and connected devices are controlled by

the host laptop that the dock is set to.

Note: Display placement is maintained when switching between host laptops.

For example, If “HOST 1”places the displays vertically, and “HOST 2”places the displays

horizontally, display placement will be maintained when switched.

About the docking station ports

The four USB ports located at the back of the docking station are standard USB 3.0

throughput ports. When the docking station is connected to a host laptop, these ports

provide a trickle charge to a selection of devices.

The side USB 3.0 port is compliant with Battery Charging Specication Revision 1.2 (BC

1.2), which means that you can use the port to connect and charge a device faster than

a traditional standard USB 3.0 port.

This side USB 3.0 port can fast-charge a connected device, even when the docking

station isn’t connected to a host laptop. When the docking station is connected to a

host laptop, the side USB 3.0 port functions as a Charging Downstream Port (CDP),

which has simultaneous charge and sync capabilities.

Charge a device

If you’re only using the side USB 3.0 port to charge a device, a connection to a host

laptop isn’t required.

• To charge a device, connect a device to the USB 3.0 port located on the side of the

docking station.

Note: The side USB 3.0 port can only fast-charge connected devices that comply to

USB Battery Charging Specication Revision 1.2.

Charge an iPad with a 30-pin dock connector

The following steps only apply to an iPad with a 30-pin connector. An iPad that uses

a Lightning connector can be charged using the USB port located on the side of the

docking station.

1. Make sure that the host laptops are not connected to the docking station.

Instruction Manual

2. Connect the iPad to the USB 3.0 port located on the side of the docking station.

Note: If you connect a host laptop (whether it be one or two host laptops) to the

docking station while you’re charging a rst-generation iPad, the iPad will switch to

data sync mode and stop charging. To switch back to charging mode, disconnect

the host laptop and the iPad from the docking station. Then connect the iPad to the

docking station again.

Congure a display device

Use DisplayLink to congure a display device

1. Connect a display device (monitor, projector, and so on) to the docking station.

2. If necessary, to display all of the available icons, click the Show hidden icons arrow

on the toolbar.

3. Click the DisplayLink icon.

4. Click StarTech USB3DDOCKFT.

5. In the drop-down list, click a congurable option.

Each display is congured independently from all of the connected displays.

Note: If you’re using a computer that’s running Windows 7 or Windows 8, you can also

adjust a display device on the Display Settings screen.

About the display options

The following information describes the display congurations available using the

DisplayLink utility.

Extend

Select this option to display an extension of your active Windows desktop on the

display that’s connected to the docking station. When you select this option, you can

view more applications or documents at the same time. The display is extended in the

direction it was the last time that the display was in Extend mode.

For more control, click Extend To and select one of the options. This puts the display

into Extend mode, and places the display to the right or left, above, or below the

primary display.

Mirror

Select this option to display a duplication of the primary display on the display that’s

connected to the docking station. The resolution, color depth, and refresh rate of the

primary display are replicated on the connected display.

Note: When the connected monitor uses a dierent specication than the primary

display, the system’s primary graphics adapter scales all of the settings to a lower

specication to maintain a uniform aspect ratio.

Extend To

Instruction Manual

Select this option to specify the physical location of the display that’s connected to the

docking station in relation to the system’s primary monitor.

Screen Resolution

Select this option to change the resolution on the display that’s connected to the

docking station.

Screen Rotation

Select this option to change the orientation in which the screen is viewed. The two

most common orientation types are portrait and landscape.

Set as Main Monitor

Select this option to specify the display that’s connected to the docking station as the

primary display. The primary display shows all of the system notications, and takes

priority with applications.

O

Select this option to disable the display that’s connected to the docking station.

Use Mac OS to congure a display device

If you’re using a computer that’s running a version of Mac OS, you can adjust a display

device in the Displays section of the Mac System Preferences menu.

Use Mac OS to change the display mode

By default, the docking station will be set up as an extended display.

• Do one of the following:

• To change the display to Mirror mode, on the Arrangement screen on a

display, select the Mirror Display check box.

• To change the display to Extend mode, on the Arrangement screen on a

display, clear the Mirror Display check box.

• To use Extended and Mirror modes simultaneously, clear the Mirror Display

check box. On the Arrangement screen, press and hold Cmd + Alt, and then

drag and drop the display that you want to mirror over the primary display

(indicated with a white bar). Repeat this step for all of the displays that you

want to mirror.

Use Mac OS to change the primary display

Changing the primary display aects where new windows appear.

• To change which of the connected displays is the primary display, on the current

primary display, click the white menu bar and drag it to the display that you wish to

make the primary one.

Tabla de contenidos

Otros manuales de Estación de acoplamiento de StarTech.com

StarTech.com

StarTech.com TB3DKM2HD Manual de usuario

StarTech.com

StarTech.com SDOCK1EU3P2 Manual de usuario

StarTech.com

StarTech.com DK30CH2DEPUE Manual de usuario

StarTech.com

StarTech.com SATDOCKCRH Manual de usuario

StarTech.com

StarTech.com USB7N1DOCKGB Manual de usuario

StarTech.com

StarTech.com TB3DKM2DP Manual de usuario

StarTech.com

StarTech.com SDOCK2U33V Manual de usuario

StarTech.com

StarTech.com SATHDDDOCKU2 Manual de usuario

StarTech.com

StarTech.com TBDOCKHDPBC Manual de usuario

StarTech.com

StarTech.com USB3SDOCKDD Manual de usuario

StarTech.com

StarTech.com TBDOCKHDPBC Manual del sistema

StarTech.com

StarTech.com Thunderbolt TB3CDOCKDP Manual de usuario

StarTech.com

StarTech.com SDOCK2U33HFB Manual de usuario

StarTech.com

StarTech.com 8STSATDOCK5U3ER Manual de usuario

StarTech.com

StarTech.com 8STSDOCK2U33 Manual de usuario

StarTech.com

StarTech.com SDOCK2U313R Manual de usuario

StarTech.com

StarTech.com SATDOCKU3S Manual de usuario

StarTech.com

StarTech.com 8STSATDOCKU3S Manual de usuario

StarTech.com

StarTech.com Thunderbolt TB3CDOCKDP Manual de usuario

StarTech.com

StarTech.com USBDOCK2 Manual de usuario

StarTech.com

StarTech.com TB2DOCK4K2DP Manual de usuario

StarTech.com

StarTech.com UNIDOCK2U Manual de usuario

StarTech.com

StarTech.com SATDOCK4U2E Manual de usuario

StarTech.com

StarTech.com USB3SDOCKHD Manual del sistema

Manuales populares de Estación de acoplamiento de otras marcas

Sony

Sony Dream Machine XDR-DS12iP Manual de usuario

Acer

Acer USB Type-C Dock II Manual de usuario

ATEN

ATEN UC-2000 Manual de usuario

Xcellon

Xcellon HDD-202 Manual de usuario

Dok

Dok CR09 Manual de usuario

Philips

Philips BTM630/12 Manual de usuario

IOGear

IOGear Travel Pro GUD3C09 Manual de usuario

RKI

RKI SDM-E2 Manual de usuario

iHome

iHome iP15 Manual de usuario

VITURE ONE

VITURE ONE MOBILE DOCK Manual de usuario

Lindy

Lindy 42984 Manual de usuario

CipherLab

CipherLab 8001 Manual de usuario

Pyle

Pyle PIPDSP2 Manual de usuario

Avol

Avol AS2350 Manual de usuario

Datalogic

Datalogic JoyaTouch Manual de usuario

Philips

Philips DC190/79 Manual de usuario

Targus

Targus DOCK315EUZ Manual de usuario

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manual de usuario
