PROAIM JB-FLMS-01 Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Assembly Manua l

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Fly-master 13 Telescopic Carbon Fiber

Jib Crane (JB-FLMS-01)

Fly-Master Jib for Zhiyun Crane-2

Top Cable Wire

Cable Guide Rod

Weight Rod

 Loosen the boom clamp of the uid head

(Not Included) and mount it on the stand.

Fly Master Jib Setup

 Then properly ghten the boom clamp on

the 100mm bowl stand (Not Included), as

shown in the image.

NOTE: It comes with a tripod mount with 1/4"

-20 and 3/8"-16 threads on the boom to mount

it on the uid head.

 Now remove the uid head plate by pressing

the lock lever.

 Aach the plate to the Fly-master Jib and

securely ghten it, matching the threads, with

the help of a screwdriver.

NOTE: It extended when not in use at

congested shoot sites. Just slide in or out when

required.

 Now mount the Fly-master Jib on top of the

uid head and properly ghten it with the

locking lever.

 Loosen the knob and increase the height of

the jib as shown in the image.

 Aach the Gimbal mounng adapter to the

Gimbal (Not Included) and properly ghten

using a screwdriver.

NOTE: Any other gimbal with a handle,

featuring a 1/4"-20 or 3/8" -16 threaded hole at

its boom, can be aached.

NOTE: You can increase the lengths of jib as

per requirement.

 Loosen the ratchet knob and open the clamp.

 Then remove the Gimbal mounng adapter,

as shown in the image.

 Aach the Gimbal (Not Included) to the clamp

and properly ghten it via the knob.

Gimbal Setup

 Then properly ghten the knob.

NOTE: High-grade Aluminum constructed

clamps at each secon’s end promise a strong

clamping force.

 Loosen the knob and insert the weight rod.

 Properly ghten the knob.

NOTE: Provided highly robust weight rod

supports universal weight plates with a 25mm

hole diameter.

 Loosen the clamp’s knob and rotate the

clamp.

 Insert weight (Not Included) according to

your requirement.

Inserng weight rod in Fly master jib

NOTE: It’s compable with Zhiyun Crane-2 &

other hand-held gimbals with 1/4” or 3/8”

Mounng threads.

 Now loosen the clamp's knob and rotate the

clamp.

 Now, properly ghten the knob and insert the

cable guide rod.

 Then insert the top cable wire into the rod, as

shown in the image.

NOTE: Set the Cable Guide rods’s posion

according to your requirement.

 Similarly, insert the second end of the wire

into the clamp, as shown in the image

NOTE: It facilitates convenient underslung &

over-slung operaons for various shot

requirements.

 Properly aach the rst end of the top cable

wire to the clamp.

Aaching Top cable wire

NOTE: Compable gimbals- Zhiyun-Tech

Crane-2 Gimbal (Direct) Single Handle Gimbals

with 1/4"-20 & 3/8"-16 Mounng Threads.

 Then properly ghten with the help of the

knob.

NOTE: Tripod mount also has a total of three

1/4"-20 threaded holes on the sides to aach

monitors & other accessories.

LCD Monitor Setup

Maximum Extandable Length of Fly Master Jib

NOTE: Fully extended length=13. & Length of 1st 3 each secon =3. & length of last secon=4.

 Properly match the threads of the LCD (Not

Included) and mount the LCD, as shown in the

image.

YOUR PROAIM FLY-MASTER TELESCOPIC CARBON FIBER JIB CRANE

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

most support and care unl you use our product.
