PROAIM VI-CYRS-01 Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is

listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assembly Manua l

Cyrus Camera Vibraon Isolator (VI-CYRS-01)

Shock Modules with Tension Cables: 8 x Heavy Modules (Black)

Cyrus Camera Vibraon

Isolator

Flycam Quick Release Mount for DJI Ronin

Universal Cheese Plate

Adapter

8 x Light Modules (Blue)

8 x

Medium

Modules

(Red)

6.10mm Screws - 4pcs

Cyrus Vibraon Isolator Setup

 Loosen the bolts of the Ronin mounng plate

using an Allen key and remove the plate from

the Cyrus Camera Vibraon Isolator.

 Detach the boom part of the Freey-MOVI

Mount (Not included) and place it on the top

of the Cyrus Camera Vibraon Isolator.

 Insert the four bolts into the boom part of

the Freey-MOVI Mount (Not included), then

place that boom part on the top of Cyrus

Camera Vibraon Isolator.

 Secure the boom part of the Freey-MOVI

Mount (Not included) properly with an allen

key and then aach the top part of the

Freey-MOVI mount to it.

 Securely lock the Freey-MOVI Mount

(Not included) to the top of the Cyrus camera

vibraon isolator.

Note: You can easily mount Ronin Gimbal

(Not included) on Freey-MOVI Mount

(Not included). Cyrus Camera Vibraon Isolator

easily handles large Remote Pan Tilt heads and

Gimbal systems like the DJI Ronin or Freey

MōVI.

 Mount the L-plate (Not included) on the

boom view of the Cyrus camera vibraon

isolator. Tighten the bolt with an allen key.

Note: You can also mount the Ronin Gimbal

(Not included) on the L-plate (Not included).

 Loosen the bolt using an allen key to remove

the red cable from the top view of the Cyrus

camera vibraon isolator.

Note: RED Medium Duty/Standard: Compable

RED, Canon C300, heavy DSLRs with Cine primes

with a gimbal like MoVI M5/M10/M15/Pro,

Ronin/Ronin M/Ronin MX.

 Aach the Light Modules blue cable on the top

view & boom view with the help of an allen

key.

 Follow the same process to aach the other

Light Modules blue cables.

Note: Blue Light Duty: Compable with DSLR,

smaller digital cine cameras or hard-mounted

cameras without a gimbal.

 Again, following the same process, replace

the blue cables with black cables with the

help of an allen key.

Note: Black Heavy Duty: compable with Red,

Alexa Mini, Ursa Mini Pro, Phantom Flex, etc.

Package with cine zoom, heavy primes and

larger gimbals like MoVI XL or Ronin 2.

 Pull down the Ronin mounng plate (DJI-QR)

lever to secure your gimbal setup.

 Now you can mount your camera on a

gimbal.

Note: Cyrus Camera Vibraon Isolator easily

mounts on Mitchell Tripods, Cranes, Jibs,

Sliders, Shock Absorber Arms and Dolly

Systems. Mount it to any Camera Gimbal Setup

ranging from 5-50kg, and it'll funcon precisely

the way you need it.

Note: You can interchange the wires according

to the payload requirement.

YOUR PROAIM CYRUS CAMERA VIBRATION ISOLATOR

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of

me, we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor

does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to

inspecon and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our

company.

utmost support and care unl you use our product.
