PROAIM P-CSHR-01 Manual de usuario

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Surfer Helmet Rig for DSLR Camera/

Smartphone (P-CSHR-01)

Assembly Manua l

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Arca-Type

Quick Release

2 x Camera Bolts

(Size : 1/4”)

2 x L-Type Allen Key

(Size : 4mm, 3mm)

Cam Surfer Helmet Rig

1/4” to 3/8” Converter

Screw BS-100

Weight washers-10 pcs I-Phone Adapter

What’s In The Box

Surfer Helmet Rig Setup

 Add washers according to the setup weight,

and then secure them by ghtening the

stopper knob.

 Insert the weight washer at the back of the

Helmet, as shown in the image.

 Remove the quick-release plate by loosening

its knob.

 Loosen and remove the weight stopper knob

on the back of the helmet rig.

 Aach the quick-release plate to the camera

plaorm knob and properly secure it in place.

 Aach the plate to the boom of your

camera (Not Included), and ghten it using a

screw driver.

 Mount the camera (Not Included) on the

quick-release plate and then secure it using

the provided knob.

 Loosen the center knob of the Helmet Rig

and set the posion according to your

requirement.

 Tighten the knob to secure the posion.

NOTE: Tighten the knob aer matching the

threads of the knob of the Helmet Rig to

properly secure it with opmal gripping.

 Loosen the knobs on either side of the

Helmet Rig and then posion can be set by

twisng the camera plaorm.

 To adjust the posion of the Helmet Rig,

loosen the buon head with the Allen key

and set the angle according to your setup

requirement.

 Aer seng the posion of Helmet Rig,

secure both the bolts by ghtening them

properly with the help of Allen key.

Posion Adjustment (Angle + Height)

 Aach your I-phone in I-Phone Adapter

holder.

 Secure the I-phone adapter holder by

aaching it properly to the knob on the

helmet's camera plaorm, as shown in the

image.

Smartphone Holder

Accessory Mounng Flexibility

Front, Top & Side Plates with 1/4"-20 Threads

YOUR PROAIM SURFER HELMET RIG FOR DSLR CAMERA /SMARTPHONE

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

most support and care unl you use our product.
