Assembly Manual
Polaris Mini Portable Video Camera Dolly w Universal Track Ends
| Mitchell & 75mm Bowl Mount (DL-PLRS-M01)
Proaim Mini Portable Camera Dolly
2 x End Spacers
4 x Foots
with Knobs
Bag Belt
1 x L Type Allen
Key Size: 3/16”
An-Tilt Safety Brake Bag Packing
75mm Bowl Adapter
8 x Wheels
2
Loosen the knob of the End Spacers and then
mount them onto the C-Stand (Not Included)
NOTE: It comes with end-clamps that let you
attach to any compatible speed rail and can be
mounted on C-stands & tripods in seconds,
allowing you to start filming in a flash.
To properly secure the foot to the End Spacer,
tighten it with the help of a knob. Follow the
same process on the other side.
End Spacers Assembly
After mounting the End Spacers onto the
C-stand (Not Included), properly secure them
with the help of the knob. Then remove the
feet by loosening their knobs.
The feet have been properly attached to the
End Spacers, as shown in the image.
Insert washers to the feet after inserting in
the End Spacers.
After removing the knobs of the feet, match
the feet’s bottom threads to the End Spacers’
and insert them in, as shown in the image.
3
Insert a 4 track into the clamp. Once the
track is properly ed into the clamp, ghtly
secure it with the knob, as shown in the
image.
The same process is to be followed for the
other track.
NOTE: It comes with track-ends for overall
secure and smooth track running.
An-Tilt Safety Brake Assembly
Now place the mini portable dolly onto the 4
track. The handles part of the dolly plaorm
should be inside of the track as shown. Make
sure all wheels are aligned correctly on the
track and dolly runs smoothly.
NOTE: It comes Mitchell mount and a 75 mm
Bowl Adapter and is also compable with
100mm and 150mm Bowl Adapters, giving you
versale camera-heads mounng opons.
The dolly plaorm already has a Mitchell
mount. To Mount the 75mm bowl adapter on
the dolly plaorm.
NOTE: Dolly has eight rolling track wheels that
run smoothly on tracks and a at surface, and it
has double ball bearings for ultra-smooth
performance.
Then insert the screws by aligning to the
boom and properly ghten with the help of
Allen key as shown in the image.
NOTE: Proaim Polaris Mini Camera Dolly is a
compact and versale.
Polaris Mini Portable Dolly Setup
Loosen the knob to properly open the safety
brake.
4
Mount the Safety Brake on side of the Mini
portable dolly plaorm. Adjust the posion of
the bracket so it goes under the track to
prevent the plaorm from lng out.
Properly secure with a knob aer mounng
the safety brake. Follow the same process on
the other side.
NOTE: Dolly has sturdy safety brakes you can
aach to safety es, making sure your plaorm
doesn’t get knocked o the rails.
Remove the locking knob of the Fluid Head
(Not Included) by loosening it, then insert it
into the bowl adapter through the screw.
After mounting the fluid head (Not Included)
on the bowl, secure it properly by inserting
the locking knob from the bottom side.
Aer properly securing the Fluid Head
(Not Included) through the locking knob, push
the red ratchet knob to remove the uid
head’s camera plate.
Mount Fluid Head on the Bowl Adapter
Aer removing the camera plate, aach it to
the boom of the camera (Not Included)
matching the threads.
5
After attaching the plate to the camera,
properly secure it with the help of an Allen
key, then mount the camera (Not Included)
onto the Fluid Head (Not Included).
The camera (Not Included) has now been
properly mounted on the Fluid Head
(Not Included).
NOTE: The mini dolly is compable with small
to medium-sized DSLR cameras; it is the best
lightweight product for your small producon.
NOTE: The whole dolly system is Quick & Easy
to Set up for a steady workow. It saves a lot of
your valuable producon me
YOUR PROAIM POLARIS MINI PORTABLE VIDEO CAMERA DOLLY W UNIVERSAL
TRACK ENDS | MITCHELL & 75MM BOWL MOUNT
ALL DRESSED UP AND READY TO GO!
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
(SHOWN WITH OPTIONAL ACCESSORIES)
