PROAIM CINEMA Series Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Megagrip Car/Vehicle Camera Mount (CM-MGGP)

Ass e mb l y M a n u a l

3 x Sucon Cups

6 x 360° Rod Clamps

3 x Rod

Jointers Hard Case

Camera Plate with Ball Head

2 x Safety Straps

3 x 24” Rods (Ø 16mm) 3 x 12” Rods (Ø 16mm)

4 x Rubber Sleeves

Note: If you have purchased (CM-MGGP-00) kit, you will receive the following:

Remove the complimentary dust cover and

place your rst sucon cup on selected

posion from where you want to shoot.

Press down sucon cup and keep pushing

pump to rmly x it on surface. Repeat this

process for all sucon cups.

Aach the Adjustable Rod Clamp with sucon

cup and ghten knob to secure the clamp.

Megagrip Setup

Insert rod of any desired length into rod

clamp and ghten it with the knob. Then by

repeang the previous step, aach rod clamp

to other end of rod and x it by the knob.

To guarantee proper adhesion of sucon cups, check that the surfaces of both, sucon cup and

mounng surface are clean, dry & dust–free.

NOTE: Please mount the device on smooth, even and non-porous surfaces.

3 x Sucon Cups

6 x 360° Rod Clamps

3 x Rod

Jointers Flight Case

Camera Plate with Ball Head

2 x Safety Straps

3 x 24” Rods (Ø 16mm) 3 x 12” Rods (Ø 16mm)

4 x Rubber Sleeves

Note: If you have purchased (CM-MGGP-01) kit, you will receive the following:

Use the rubber sleeves to avoid dents and

scratches on car paint. Tighten tension straps

carefully to avoid damages.

The length of Rods can be extended as per

your setup requirements with help of rod

jointer/connector, to achieve dierent

conguraons.

Things To Remember

You can easily adjust/level the angle of each

rod clamp through the provided knob in 360°

Pan & Tilt Rotaon, which gives extra

exibility, and thus you can mount cups to

virtually any part of vehicle.

You can adjust angle of Ball Levelling Camera

Plaorm at any required angle in 360°

rotaon, and can be locked down with knob

when you wish to capture shots in stac

posion.

NOTE: Test all xtures before driving.

Aach ball levelling camera plate with rod

clamp and secure it carefully by ghtening

the knob. Repeat same process for rest of

clamps.

Although the Megagrip’s holding force is

adequate for regular driving shots, safety

belts/tension straps must be used for

addional security. When mounted on cars,

the objects aached to Megagrip (e.g.

camera) have to be secured addionally.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.

YOUR PROAIM MEGAGRIP CAR/VEHICLE CAMERA MOUNT

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)
