PROAIM TP-ULTB-01 Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Universal Ultra Large iPad Teleprompter

Kit (TP-ULTB-01)

Assembly Manua l

Large Tablet Holder (3,4mm2 x Allen Keys)

Magnec Protecve Hood Quick Release

Camera Plaorm

2 x 12" (30.5 cm)

15mm Rods

Boom Hood Flag 2 x Side Hood Flag

60/40 Beam

Splier Glass

5 x Long Tablet

Holder Extension Mount

Hand Gloves Bag Packing

 Loosen the bolt from the quick release

camera plaorm with the help of a

screwdriver.

 Insert the 15mm rods into the Large tablet

holder and ghten the knob exactly where

you need the glass to be posioned.

 You can adjust the Splier Glass up to 45°,

as shown in the image.

Teleprompter Setup

 Mount the quick release camera plaorm

on the top plate of the uid head (Not

Included) and secure it properly.

Note: You can also mount the teleprompter

directly on the tripod stand.

 Insert the 15mm rods and secure them

properly with the knobs on both sides, as

shown in the image.

 Slightly loosen the knob of the iPad holder

bracket and place the tablet on it. You can

extend it as desired.

Note: Adjustable IPad holder Bracket

allows mounng Mobile, Standard / Large

Tablet ranging from 6 x 9” to 9 x 12" in size.

Large Tablet Holder Assembly

 Aer mounng the large tablet on the c-post

holder bracket, properly ghten the knob.

 Press the red pin on the quick release camera

plaorm and remove the camera release

plate.

 Slide the camera onto the quick release

camera plaorm and press the red lever to

lock it.

 Align the camera release plate with the

camera’s thread and secure it properly using

a screwdriver.

 Aach the magnec protecve hood to the

splier glass and close the zips from both

sides to avoid unwanted light.

Note: Magnec Protecve hood quickly

aaches/detaches via a magnec strip.

Magnec Protecve Hood Aachment

 Adequately cover the camera using a fabric

knicker and aach the boom hood ag as

shown in the image.

YOUR PROAIM UNIVERSAL ULTRA LARGE IPAD TELEPROMPTER KIT

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

 Aach the Hood Flags to both Sides.

Note: Hood ag works to protect your lens

from unwanted light, making text readable.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
