POSIFLEX XT-3915 Manual de usuario

Package Contents

Terminal with base stand………x1

60W power adaptor……………x1

Power cord……………………..x1

Screw for IO cable cover………x2

User manual……………………x1

Recovery or information CD......x1

Product Features

Standard Features

System

Intel Bay Trail-D J1900 2.0G up to 2.42G, 2M Cache, 4 core

Mechanical Structure

Fanless structure with Aluminum die-cast main unit casing

Water resistant structure allowing easy cleaning

Foldable base

Display

High-quality 15” TFT active matrix LCD monitor provided

with true-flat Projected Capacitive touch panel supporting

10-point multi-touch for 3815, with resistive touch panel for

XT-3915, and with Infrared touch panel for XT-3915IR

XT-3815/3915/3915IR

Fanless LCD Touch Terminal

User Manual

16780900050 Ver. D0

http://www.posiflex.com

Optional Items

System

DDR3L SODIMM memory expansions up to 8GB (Max.) for

XT-3815/3915/3915IR (J1900) in one SODIMM

Preload Windows POSReady 7 / Win 7 / Windows Embedded

8.1 Industry / Linux per request

WIFI

Wireless LAN module, through Mini PCI-E Interface

Connection Cable

Parallel extension cable

RJ50-to-DB9 serial port conversion cable

Split cable for 2 cash drawer control

Base

GEN 8E base including UPS battery and poweredUSB board,

and supporting 60W/80W/150W power adaptor

Integration Kit

Integrated side mount upgrade kits, such as SA-105 provided

with optional MSR, SA-205 provided with iButton, SA-305,

and SA-405

1”SATA SSD

PoweredUSB kit in GEN 8E base stand, such as PU-480 or

PU-490

Power adapter kits for 80W/150W power adapters

Back mount displays, such as LM/TM-3010/3014 and PD-

6307

Views of the XT-3815/3915/3915IR

Front and Rear Views of Terminal with Gen 7E Base Stand

Left Side View of Terminal with Gen 7E Base Stand

Bottom View of Terminal with GEN 7E Base Stand

Neck Cover

DDR3 Memory Cover

LCD Touch Panel

Power Indicator

Base Stand

HDD Cover

Hinge

for main unit

Cable Exit

Cable Cover

Power Button

Brightness Adjustment

Button “+”

Brightness Adjustment

Button “-”

USB 2.0 Port

Locking Hook

Bottom Plate

Rubber Cushion

Wrapping Screw

Front and Rear Views of Terminal with GEN 8E Base Stand

Left Side View of Terminal with GEN 8E Base Stand

Bottom View of Terminal with GEN 8E Base Stand

DDR3 Memory Cover

LCD Touch Panel

Power Indicator

Base Stand

HDD Cover

Hinge

for main unit

Cable Exit

Neck Cover

Cable Cover

Power Button

Brightness Adjustment

Button “+”

Brightness Adjustment

Button “-”

USB 2.0 Port

Locking Hook

Rubber Cushion

Wrapping Screw

PoweredUSB Board Cover

Bottom Plate

Power Adaptor Chamber

UPS Chamber

Views of I/O Interfaces of Terminal

DC-IN Power Jack

VGA Port

UPS Port

LAN Port

CR Port

USB 2.0 Port

DB9 COM Port

USB 2.0 Port

RJ50 COM Port

USB 3.0 Port

Positioning your POS for a Perfect Viewing Angle

The adjustable bases designed for XT-3815/3915/3915IR come in two models,

Gen 7E/8E, and allow you to determine an ideal position for your terminal by

using its unique tilt adjustment mechanism. As the below figures suggest, both

bases provide three standard positioning solutions for your terminal: Flat

Folded mode, Low Profile mode, and Full Extended mode.

XT-3815/3915/3915IR with Gen 7E Base

Flat Folded mode

Low Profile mode

Full Extended mode

XT-3815/3915/3915IR with Gen 8E Base

Flat Folded mode

Low Profile mode

Full Extended mode

In general, XT-3815/3915/3915IR will be set up beforehand in Flat Folded

mode and then packaged into the box for shipping. After it is unpacked, you

may re-adjust the terminal in either Low Profile mode or Full Extended mode

according to your situation. Below will provide instructions on how to adjust

the specific base connected to the POS system. As a reminder, please be

careful not to touch the LCD panel while setting up the tilt angle.

XT-3815/3915/3915IR with Gen 7E Base

Please refer to the following instructions on how to switch among different

positioning modes to find an ideal viewing angle for XT-3815/3915/3915IR

with Gen 7E base.

1. Unpack XT-3815/3915/3915IR, which is

supposed to be set in flat folded mode, out of

the package box and then lay your POS

system on a flat surface.

2. Steady the base with one hand, and then tilt

the screen downwards.

3. Position your terminal in Full Extended mode

3.1 After grabbing the bottom edge of the screen with your hand, gently

move the screen upward until the screen is locked into place with a

click sound.

3.2 Support the screen with one hand holding onto its bottom edge.

Then, while pulling the lever backwards, move the display upwards

until the lever is snapped into the lower hook to raise the screen as

shown in the below figure.

3.3 With the screen facing toward you, tilt the

screen up or down to your desired angle.

Please do not press on the LCD panel while

setting up the tilt angle.

3.4 Remove the cable cover from the base.

Lever

Lower

hook

3.5 Fix the base with two #/6/32-14L screws.

4. Return your terminal back to Flat Folded mode from Full Extended

mode.

4.1 Remove the cable cover from the base.

4.2 Remove the two screws from the base.

Remove the two screws.

4.3 Tilt your screen in a horizontal position.

4.4 Support the screen with one hand holding onto its bottom edge.

While pulling the lever backwards, move the display downwards

until the lever is lifted off the hook as shown in the figure.

4.5 Push the cable cover back.

4.6 Tilt the screen again to the horizontal

position.

Hook

Lever

5. Position the terminal in Low Profile mode.

5.1 Follow Step 4 to set up the termimal in Flat

Folded mode.

5.2 Tilt the screen all the way down

5.3 To tilt screen up or down to your desired

angle, please be advised to keep the base

steady with one hand to do so. Do NOT

press on the LCD panel while setting up the

tilt angle.

XT-3815/3915/3915IR with Gen 8E Base

Please refer to the following instructions on how to switch among different

positioning modes to find an ideal viewing angle for XT-3815/3915/3915IR

with Gen 8E base.

1. Unpack XT-3815/3915/3915IR, which is

supposed to be set in flat folded mode, out

of the package box and then lay your POS

system on a flat surface.

2. While steadying the terminal with your

hand holding onto the base, tilt the screen

down.
