Planet IGS-10020PT Manual de usuario
Industrial L2+ 8-Port Gigabit 802.3af/at PoE
+ 2-Port 100/1000X SFP Managed Switch
IGS-10020PT/IGS-10020HPT
Quick Installation Guide
Table of Contents
1. Package Contents ....................................................................................... 3
2. Requirements ............................................................................................. 4
3. Wiring the Power Inputs.............................................................................. 5
4. Terminal Setup ........................................................................................... 7
4.1 Logging on to the Console.................................................................... 8
4.2 ConguringIPAddress......................................................................... 9
5. Starting Web Management .........................................................................12
5.1 LoggingintotheIndustrialManagedPoE+Switch ................................12
5.2. SavingConguration...........................................................................16
6. RecoveringBacktoDefaultConguration.....................................................18
7. Customer Support .....................................................................................19
3
1. Package Contents
Thank you for purchasing PLANET L2+ Industrial Managed Gigabit PoE Switch,
such as IGS-10020PT and IGS-10020HPT. The descriptions of these models are as
follows:
IGS-10020PT/
IGS-10020HPT:
Industrial8-Port10/100/1000T802.3af/atPoE+2-Port
100/1000XSFPManagedSwitch
“Industrial Managed PoE+ Switch” mentioned in this Quick Installation Guide
referstotheabovemodels.
Open the box of the Industrial Managed PoE+ Switch and carefully unpack it. The
boxshouldcontainthefollowingitems:
zTheIndustrialManagedPoE+Switchx1
zQuickInstallationGuidex1
zDIN-railKitx1
zWallMountingKitx1
zDB9 to RJ45 Interface RS232 Console Cable x 1
zDust Cap (Please refer to the table below.)
RJ45 Dust Cap SFPDustCap
IGS-10020PT/IGS-10020HPT: 9 2
If any item is found missing or damaged, please contact your local reseller for
replacement.
4
2. Requirements
zWorkstations running Windows XP/2003/Vista/7/8/10/2008, MAC OS X or later,
Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerial Port Connection (Terminal)
The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
The above Workstations have been installed with terminal emulator, such as
HyperTerminalincludedinWindowsXP/2003.
Serial cable -- one end is attached to the RS232 serial port, while the other
endstotheRJ45consoleportoftheIndustrialManagedPoE+Switch.
zEthernetPortConnection
Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.
The above PC is installed with Web browser and JAVA runtime environment
plug-in.
Note
It is recommended to use Internet Explorer 8.0 or above to access
the Industrial Managed PoE+ Switch. If the Web interface of the
Industrial Managed PoE+ Switch is not accessible, please turn off
theanti-virussoftwareorfirewallandthentryitagain.
5
3. Wiring the Power Inputs
TheUpper Panel of theIndustrial ManagedPoE+Switchindicates aDCinlet power
socketandconsistsofoneterminalblockconnectorwithin6contacts.Pleasefollow
the steps below to insert the power wire.
1.Insert positive/negative DC power wires into Contacts 1 and 2 for Power 1, or
Contacts5and6forPower2.
zIGS-10020PT:48V~56VDC
Input DC 48~56V
DC1 DC2
Fault
DI1 DO0 DO1DI0 GNDGND
1A@24V
Figure 3-1: IGS-10020PT Upper Panel
zIGS-10020HPT:DC12~48V
DI1 DO0 DO1DI0 GNDGND
1A@24V
Input DC 12-48V
DC1 DC2
Fault
Figure 3-2: IGS-10020HPT Upper Panel
6
2.Tightenthewire-clampscrewsforpreventingthewiresfromloosening.
1 2 3 4 5 6
V1+ V1- V2+ V2-
Power 1 Power 2
Positive(+)Pin Negative(-)Pin
IGS-10020PT/IGS-10020HPT Pin1/5 Pin2/6
Note
The wire gauge for the terminal block should be in the range from
12to24AWG.
7
4. Terminal Setup
To congure the system, connect a serial cable to a COM port on a PC or
notebook computer and to RJ45 type serial (console) port of the Industrial
Managed PoE+ Switch. The console port of the Industrial Managed PoE+ Switch is
DCE already, so that you can connect the console port directly through PC without
theneedofnullmodem.
PC/Workstation
with
Terminal emulation software
RJ45 to DB9 RS232 Cable
Serial Port
IP Address:
192.168.0.100
IGS Industrial Managed Switch
Figure 4-1: Industrial Managed PoE+ Switch Console Connectivity
A terminal program is required to make the software connected to the Industrial
Managed PoE+ Switch. Windows’ Hyper Terminal program may be a good choice.
TheHyperTerminalcanbeaccessedfromtheStartmenu.
1. Click START, then Programs, AccessoriesandthenHyper Terminal.
2.When the following screen appears, make sure that the COM port should be
conguredas:
Baud:115200
Parity:None
Data Bits: 8
Stop Bits: 1
FlowControl:None
Figure 4-2: COM Port Conguration
8
4.1 Logging on to the Console
Once the terminal has been connected to the device, power on the Industrial
ManagedPoE+Switchandtheterminalwilldisplay“runningtestingprocedures”.
Note
The following console screen is based on the IGS-10020HPT.
The display of the IGS-10020PT is the same as that of the IGS-
10020HPT.
When the following dialog box shown in Figure 4-3 appears, please enter the
factorydefaultusername“admin”andpassword“admin”.
Username:admin
Password:admin
Figure 4-3: Console Login Screen
Note
1.For security reason, please change and memorize the new pass-
wordafterthisfirstsetup.
2.Only accept command in lowercase letter under console inter-
face.
9
4.2 ConguringIPAddress
The Industrial Managed PoE+ Switch is shipped with default IP address shown
below:
IPAddress:192.168.0.100
Subnet Mask: 255.255.255.0
To check the current IP address or modify a new IP address for the Industrial
ManagedPoE+Switch,pleaseusetheprocedureasfollows:
Display of the current IP Address
1.Atthe“#”prompt,enter“show ip interface brief”.
2.ThescreendisplaysthecurrentIPaddressshowninFigure4-4.
Figure 4-4: IP Information Screen
10
CongurationoftheIPAddress
3.At the “#” prompt, enter the following command and press <Enter> as shown
inFigure4-5.
The previous command would apply the following settings for the Industrial
ManagedPoE+Switch.
IPAddress:192.168.1.100
Subnet Mask: 255.255.255.0
Figure 4-5: Conguring IP Address Screen
4.Repeatstep1tocheckiftheIPaddresshaschanged.
