Oki B6100n Manual de usuario

(continued on back)

Caution!

To avoid damage by static electricity

or rough handling, keep the memory

card in its packaging until you're

ready to install it.

Note: The printer has two slots in

which to install an optional

RAM Memory card.

1. Turn off the printer, and remove the

power cord and interface cable.

2. Loosen the thumbscrews at the top

and bottom of the left side cover.

3. Slide the cover toward the rear of

the printer and then downward to

remove it.

4. Locate the slot for the card:

Caution!

To avoid damage to the RAM card,

ground yourself (touch metal) before

handling it.

5. Remove the RAM memory card

from its packaging.

6. Hold the card with the components

facing up, and the gold contact

edge aimed away from you.

7. Insert the card in the slot and press

firmly into place. Push the white

tabs against the sides of the card to

lock it in place.

8. Replace the side cover:

a. Insert the top part of the left side

cover into the printer. Make sure

the locking tab aligns with the

hole in the printer’s side.

b. Slide the side cover towards the

front of the printer to install it

c. Tighten both thumbscrews.

9. Reattach the interface cord and

power cable, then turn on the

printer.

256 MB RAM Memory Expansion

Option for B6100

Installation Instructions

Oki Data Americas, Inc., 2000 Bishops Gate Blvd., Mt. Laurel, NJ 08054-4620

Phone: (856) 235-2600 Fax: (856) 222-5320 http://www.okidata.com http://my.okidata.com

MemoryPartNumber

70045801

10.Print a menu summary.

a. Press Menu.

b. Press Next repeatedly until you

see Function on the second

line.

c. Press Select.

d. Press Next once. Print

Summary appears.

e. Press Select. The menu summary

prints.

11. Check “Installed Memory” under

INFORMATION on the

second page of the printout.

– It should reflect the newly

installed memory.

– If it does not, repeat the above

steps and be sure the memory is

pushed in completely.

– Then reprint the menu summary

and check the Installed Memory

again.

OKI is a registered trademark/marca registrada/marque déposée, Oki Electric Industry Company, Inc.

59345901
