Hard Disk Drive (HDD)
Installation Instructions
59375102
© 2007 by Oki Data Americas, Inc. All rights
reserved.
Every effort has been made to ensure that the
information in this document is complete,
accurate, and up-to-date. The manufacturer
assumes no responsibility for the results of errors
beyond its control. The manufacturer also cannot
guarantee that changes in software and
equipment made by other manufacturers and
referred to in this guide will not affect the
applicability of the information in it. Mention of
software products manufactured by other
companies does not necessarily constitute
endorsement by the manufacturer.
For the latest product information, printer drivers,
manuals, special offers, etc., go to
http://my.okidata.com
Trademark Information
OKI is a registered trademark of Oki Electric Industry
Company, Ltd.
Macintosh is a trademark of Apple Computer, Inc., registered
in the U.S. and other countries.
Windows and Windows NT are either registered trademarks
or trademarks of Microsoft Corporation in the United States
and other countries.
Other product names and brand names are registered
trademarks or trademarks of their proprietors.
Oki Data Americas, Inc.
2000 Bishops Gate Blvd.
Mt. Laurel, NJ 08054-4620
www.okiprintingsolutions.com
3
Prepare the Printer
1. Turn off the printer.
2. Detach the power cord from the back of the
printer.
3. Detach the interface cable from the back of
the printer.
4. Remove and save the thumbscrews at the
top and bottom which hold the control
board cover in place.
4
5. Open the control board cover by pulling out
and to the left.
5
Install the Hard Disk
Drive (HDD)
1. Locate the drive connector (1) on the
control board:
6
2. Remove the hard disk drive from its
shipping package.
Caution!
Observe antistatic precautions when
installing the hard disk drive.
3. Lift the handle on the HDD and insert the
connector firmly into the socket on the
control board.
7
4. Press down on the handle to lock it in place.
8
Complete the
Installation
1. Close the control board cover and reinstall
the screws at the top and bottom.
2. Reattach the interface cable, then the
power cord.
3. Turn on the printer.
9
Verify the Installation
Print the Configuration Report
1. Press Enter to access the printer menu.
2. Press Enter to select Configuration.
3. Press the ∇key.
4. Press Enter to select Print Information.
5. Press Enter to select Execute.
The Configuration report prints.
6. In the listing under Configuration, System,
“HDD: installed” should appear.
If you see “HDD: uninstalled”, repeat the
installation steps—checking to be sure that
the Hard Disk Drive is firmly seated in the
printer connector—until it does.
10
Activate the HDD in the
Driver
Windows®
Postscript Emulation Driver
1. First
Windows Vista
a. Click Start →Settings →Hardware and
Sound →Printer.
The Printer dialog box opens.
Windows XP, Server 2003
a. Click Start →Settings →Printers and
Faxes.
The Printers and Faxes dialog box opens.
Windows 2000
a. Click Start →Settings →Printers.
The Printers dialog box opens.
2. Right click the appropriate printer icon.
Click Properties.
3. Click the Device Settings tab.
4. Scroll down to Installable Options. Click
Printer Hard Disk.
