Logitech® Illuminated Living-Room

Keyboard K830

Setup Guide

Guide d’installation

Logitech Illuminated Living-Room Keyboard K830

English. . . . . . . . . . . . . . . . . . . . . . .3 Français . . . . . . . . . . . . . . . . . . . . . 13

www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Logitech Illuminated Living-Room Keyboard K830

English 3

Know your product

2 3

45 6

Logitech® Illuminated Living-Room

Keyboard K830

Setup Guide

Guide d’installation

1. Left mouse click

2. Micro-USB charging port

3. On/o power switch

4. Function keys

5. Automatic light sensor

6. Battery status and Bluetooth® connection

indicator

7. Hot keys

8. Touchpad

9. Mouse click buttons

10. Product documentation

11. Unifying receiver

12. USB extender cable

13. Micro-USB charging cable

Logitech Illuminated Living-Room Keyboard K830

4 English

Setting up your keyboard

Using the Unifying receiver

1. Plug in the Unifying receiver into your laptop or desktop computer. You can use the USB extender

cable provided to position the Unifying receiver away from metallic objects or devices that may cause

interference.

USB

Note: You can also use your keyboard to control an Android™ enabled TV. Refer to the documentation

supplied by your TV manufacturer for compatibility information and further connection details.

*HDMI cable is not included.

2. Turn on your keyboard.

Logitech Illuminated Living-Room Keyboard K830

English 5

Using Bluetooth Smart without the Unifying receiver

You have the option to connect your keyboard to a compatible Windows® 8 computer or TV running Android

5.0 or later using the latest generation Bluetooth Smart technology. To pair your Bluetooth Smart Ready PC or

TV and keyboard:

1. Turn on your keyboard and ensure that the Unifying receiver is not connected to your PC or TV.

2. Press the Fn + Del buttons simultaneously.

The Bluetooth connection indicator blinks to indicate the keyboard is discoverable. It remains discoverable

for 2 minutes.

3. Complete Bluetooth Smart pairing on your compatible Windows® 8 computer:

a. Go to Control Panel Devices and Printers.

b. Click ‘Add a device’. A list of discoverable devices is displayed.

c. Select ‘K830’ from the list.

d. Click ‘Next’, and follow the on-screen instructions.

You can also pair your keyboard to an Android enabled TV. Refer to the documentation supplied by your TV

manufacturer for further connection details.

Logitech Illuminated Living-Room Keyboard K830

6 English

Bluetooth Smart connection indicator

After successfully pairing the keyboard with your computer or TV, the Bluetooth Smart connection indicator

turns solid green.

Light Description

Blinking green Fast: The keyboard is in discovery mode, ready for pairing.

Slow: The keyboard is trying to reconnect to your computer or TV.

Software for your keyboard

Download and install the Logitech software for your keyboard to:

• Customize the function keys.

• Adjust your touchpad experience. You can

modify the pointer speed, adjust scrolling, and

disable touchpad tap.

• Connect additional devices to your Unifying

receiver.

• View videos explaining gestures and providing

information about your keyboard’s behavior.

• Reverse the requirement to press the Fn key

when using function keys.

Logitech software is available at www.logitech.com/support/k830.

Logitech Illuminated Living-Room Keyboard K830

English 7

Using your keyboard

Keyboard backlighting

When you start using your keyboard, the automatic

light sensor detects the light level in the room and

adjusts the keyboard backlight intensity accordingly.

There are three intensity levels:

• In bright light: no keyboard illumination.

• In poor light: full intensity backlight.

• In the dark: half intensity backlight.

You can manually override the automatic

backlighting setting. Press the key to cycle

between the three intensity levels.

Please note:

• When your battery charge level is low,

backlighting turns o automatically to conserve

battery power.

• Automatic backlight control is restored

automatically if the keyboard is idle for 30

minutes or more, or after turning the keyboard

o and back on.

Touchpad gestures

To point, scroll and click:

1. Point and slide one ﬁnger anywhere on

the touchpad to move the screen pointer.

2. Scroll with two ﬁngers, up or down.

3. Press for left mouse click.*

4. Press for right mouse click.

*You can also tap the touchpad surface to perform

a click.

Note: To disable gestures and touchpad tap,

press the Fn key plus the left mouse click button. To

re-enable gestures and touchpad tap, press the Fn

key plus the left mouse click button again.

Logitech Illuminated Living-Room Keyboard K830

8 English

Recharging your keyboard

Your keyboard is rechargeable. There are no batteries to be replaced.

A three-hour charge provides up to 10 days of use when you type about two hours a day with backlight on, or

about one year without backlight.

Note: The use you get between charges may vary depending on your usage pattern.

When you turn on the keyboard the battery indicator

shows the charge level.

Indicator Explanation

Blinking green The battery is charging.

Solid green The battery has adequate charge, or charging is complete.

Blinking red Battery power is low. Recharge the battery.

To charge the battery, connect the keyboard

to a computer using the Micro-USB charging cable

supplied.

The battery indicator blinks green while charging takes

place. Charge until the indicator light stops blinking.

You can use the keyboard while it charges.

Note: If the battery power is low (indicator blinking red), the keyboard backlight is disabled.

USB

Logitech Illuminated Living-Room Keyboard K830

English 9

Function keys

Adjust backlight intensity

Back

Home

Switch applications

Show / Hide desktop

Maximize window

Launch media player

Previous track

Play/pause track

Next track

Fn + ins: PC sleep

Fn + del: Bluetooth Smart

Connection

Fn + backspace: Print screen

Fn + caps lock: Scroll lock

Fn + : Page up

Fn + : Page down

Fn + : Home

Fn + : End

Note:

• For keys F1 to F12:

• Press just the key to select the feature: ‘Adjust backlight intensity’...

• Press both Fn and the key to select the function key: F1, F2...

• For all other function keys, press both Fn and the key to select the feature.

• Some function keys may not be available for use on Android devices.

• You can use the Logitech software on a Windows® computer to reverse the requirement to press the Fn key.

Hot keys

Mute Volume down

Volume up

Logitech Illuminated Living-Room Keyboard K830

10 English

The Logitech® Unifying receiver

Plug it. Forget it. Add to it.

Your new Logitech product ships with a Unifying

receiver. Did you know you can add a compatible

Logitech wireless device that uses the same receiver

as your current Logitech Unifying product?

Are you Unifying-ready?

If you have a Logitech wireless device that’s

Unifying-ready, you can pair it with additional

Unifying devices. Just look for the orange Unifying

logo on the new device or its packaging. Build your

ideal combo. Add something. Replace something.

It’s easy, and you’ll use only one USB port for up to

six devices.

Download the Logitech Unifying software by visiting

www.logitech.com/unifying.

Bluetooth Smart

Connect and go

Your Logitech product features the latest

generation Bluetooth Smart technology. Connect

using Bluetooth Smart to eortlessly interact with

applications on your smartphone or tablet.

You can connect your Logitech product to the latest

compatible Bluetooth Smart Ready devices, such as

Bluetooth Smart Ready PCs running Windows® 8 or

later and TVs running Android 5.0 or later.
