Logitech K810 Manual de usuario

Logitech® Bluetooth® Illuminated Keyboard K810

Setup Guide

Guide d’installation

Logitech Bluetooth Illuminated Keyboard K810

English. . . . . . . . . . . . . . . . . . 3

Français . . . . . . . . . . . . . . . . 13

Español . . . . . . . . . . . . . . . . 23

Português . . . . . . . . . . . . . . . 33

www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Logitech Bluetooth Illuminated Keyboard K810

English 3

Know your product

1. Bluetooth® status lights

2. Bluetooth keys

3. Function keys

4. Battery status light

5. On/O switch

6. Bluetooth connect button

7. Micro-USB port

8. Micro-USB charging cable

75 6 8

1 2 4

Logitech Bluetooth Illuminated Keyboard K810

4 English

Set up your product

Pair your ﬁrst device

1. Turn on the Bluetooth keyboard.

2. Press the Bluetooth connect button.

The lights above the Bluetooth keys

blink blue.

3. Press a Bluetooth key to assign your ﬁrst

device to that key:

• The light above the selected key

continues to blink blue.

• The Bluetooth keyboard is

discoverable for 15 minutes.

Logitech Bluetooth Illuminated Keyboard K810

English 5

4. Complete Bluetooth pairing on your device:

Windows® 7 and 8:

a. Go to Control Panel >

Devices and Printers.

b. Click “Add a device.”

c. Choose “Logitech K810”

from the device list.

d. Click “Next,” and follow the on-screen

instructions.

Apple iOS® (iPad® or iPhone®):

a. In Settings, choose General

> Bluetooth, and then turn

on Bluetooth.

b. Choose “Logitech K810” from

the Devices menu.

Android®

a. In Settings, choose Wireless

and network > Bluetooth settings,

and then turn on Bluetooth.

b. Choose “Logitech K810” from

“Bluetooth devices.”

Note: If your mobile device requests a PIN,

enter the code using the Bluetooth keyboard and

not the virtual keyboard on your mobile device.

The Bluetooth keyboard and your device are now paired. The light above the Bluetooth

key you have selected turns blue for 30 seconds.

For Windows, to customize the function keys and to specify backlight settings,

download and install software at www.logitech.com/support/k810.

Logitech Bluetooth Illuminated Keyboard K810

6 English

Pair or reassign a Bluetooth key to another device

Pair up to three compatible devices with the Bluetooth keyboard.

1. Make sure the keyboard is on.

2. Press the Bluetooth connect button.

The lights above the Bluetooth keys

rapidly blink blue.

3. Press a Bluetooth key to assign

your device to that key. For example,

if you already paired a device to

Bluetooth key 1, press the Bluetooth

key 2.

• The light above the selected key

continues to blink blue.

• The keyboard is discoverable

for 3 minutes.

4. Go to “Pair your ﬁrst device” and follow

step 4 to complete Bluetooth pairing.

Note: After you press the Bluetooth connect

button, the lights above the Bluetooth keys blink

blue. All three Bluetooth keys can be assigned

or reassigned, and the Bluetooth keyboard is

discoverable for 3 minutes.

Logitech Bluetooth Illuminated Keyboard K810

English 7

Switching among paired devices

To select a paired device:

• Press the Bluetooth key (1, 2, or 3)

associated with it.

• The light above the selected key blinks

blue, indicating the Bluetooth keyboard

is connecting.

• The light turns solid blue for 5 seconds,

indicating the connection has

been made.

• For example, if a device is paired

with the Bluetooth 2 key, press that key

to use the device with the Bluetooth

keyboard.

Note: Only one device can be active at a time.

Logitech Bluetooth Illuminated Keyboard K810

8 English

Charge the batteries

A three-hour charge provides up to 10 days of use when you type about two hours a day

with the backlight on, or about one year without backlight. You can use the Bluetooth

keyboard while it charges.

To check battery power and to charge the keyboard, do the following:

1. Turn on the Bluetooth keyboard.

• Battery Status light ﬂashes green:

the battery has an adequate charge.

• Battery Status light ﬂashes red:

recharge the battery. Go to step 2.

2. Connect the Bluetooth keyboard

to a computer using the Micro-USB

charging cable. The Battery Status light

will pulse green. Charge for 1 to 3 hours,

or until the Battery Status light turns o.

Note: If the battery power is critically low,

the keyboard backlight is disabled and

the battery status light will blink red

USB

Logitech Bluetooth Illuminated Keyboard K810

English 9

Visit Product Central

There’s more information and support

online for your product. Take a moment

to visit Product Central to learn more about

your new Bluetooth keyboard.

Browse online articles for setup help,

usage tips, or information about additional

features. If your Bluetooth keyboard has

optional software, learn about its beneﬁts

and how it can help you customize

your product.

Connect with other users in our Community

Forums to get advice, ask questions,

and share solutions.

At Product Central, you’ll ﬁnd a wide

selection of content

• Tutorials

• Troubleshooting

• Support community

• Software downloads

• Online documentation

• Warranty information

• Spare parts (when available)

Go to www.logitech.com/support/k810

Logitech Bluetooth Illuminated Keyboard K810

10 English

Use your product

Function and media keys

1. Bluetooth keys 1, 2 and 3 Pair up to

three compatible devices.

2. Application switch Cycles through open

apps.

3. Decrease (F5) and Increase (F6)

keyboard backlight intensity

4. Play/Pause

5. Mute

6. Volume down

7. Volume up

8. Home

9. Multifunction key

Calculator Windows only

Show/Hide virtual keyboard iOS only

F-keys: F1 to F12 To use in Windows, press and hold the Fn key, and then press an F-key.

Customizable with optional software. See “Software for Windows.”

1 2 3 7654 8 9
