Ultimate Technology 500 POS Manual de usuario

SERIES 500 POS KEYBOARD

PROGRAMMING & USER’S GUIDE

Series 500 POS Keyboard

SERIES 500 QUICK REFERENCE GUIDE

KEY PROGRAMMING

To Program a Primary Key

1. Swipe Programmer’s Card through Mag Card Reader.

2. Type 00 on the numeric keypad on the Series 500 Keyboard.

3. Press the key on the Series 500 Keyboard that you wish to program.

4. Type the desired key sequence on the AUX (PS/2) keyboard.

5. Press the “ENTER” key next to the numeric keypad on the Series 500 Keyboard.

6. To program additional keys go to Step 3 and repeat process.

7. To exit programming mode type 0099 on the numeric keypad on the Series 500 Keyboardor

swipe Programmer’s Card through Mag Card Reader.

To Program a Secondary Operation Key

1. Swipe a Programmer’s Card through Mag Card Reader.

2. Type 01 onthe numeric keypad on the Series 500 Keyboard.

3. Press the key on the Series 500 Keyboard that you want to program.

4. Type the desired key sequence on the AUX (PS/2) keyboard.

5. Press the “ENTER” key next to the numeric keypad on the Series 500 Keyboard.

6. To program additional keys go to Step 3 and repeat process.

7. To exit programming mode type 0099 on the numeric keypad on the Series 500 Keyboardor

swipe Programmer’s Card through Mag Card Reader.

To Program a Secondary Operation Access Key*

1. Swipe Programmer’s Card through Mag Card Reader.

2. Type 00 on the numeric keypad on the Series 500 Keyboard.

3. Press the key on the Series 500 Keyboard to be used as the Secondary Operation Access

Key.

4. Type 6 on numeric keypad on the Series 500.

5. Press the “ENTER” key on the Series 500 Keyboard.

6. To exit programming mode type 0099 on the numeric keypad on the Series 500 Keyboardor

swipe programmer’s Card through Mag Card Reader.

*A Secondary Operation Access Key provides access to the secondary level of each key as

programmed in the Series 500 Keyboard.

Please Refer to the Programming and User’s Guide for other Programmable Functions.

Series 500 POS Keyboard

TABLE OF CONTENTS

SCOPE ...........................................................................................................vi

SPECIAL NOTE.............................................................................................vi

PRODUCT INFORMATION...........................................................................2

MODEL DESCRIPTION .................................................................................................2

FEATURES.......................................................................................................................2

SPECIFICATIONS...........................................................................................................3

SERVICE AND WARRANTY..........................................................................3

INSTALLATION..............................................................................................4

UNPACKING AND INSPECTION.................................................................................4

EXTERNAL CONNECTIONS........................................................................................5

DRAWER JUMPER CONNECTIONS (PRINTER FIRED).......................................5

OPERATION...................................................................................................9

CONTROLS AND INDICATORS..................................................................................9

PROGRAMMING ..........................................................................................12

PROGRAMMING KEYBOARD OPERATING PARAMETERS..............................12

LOCAL MODE PROGRAMMING -FUNCTION CODES AND SETTINGS.........12

LOCAL MODE PROGRAMMING INSTRUCTIONS................................................18

LOCAL MODE PROGRAMMING................................................................................32

KEY MAKE/BREAK CODES AND EXTENDED FUNCTIONS.............................32

PROGRAMMING IN REMOTE MODE.......................................................................36

REMOTE MODE PROGRAMMING MACROS AND COMMAND SUMMARY....36

101/102-KEY KEYBOARD -KEY CODE IDENTIFICATION .................................51

PROGRAMMING KEY MAKE/BREAK CODES.......................................................52

EXAMPLES OF REMOTE PROGRAMMING FOR KEY MAKE/BREAK CODE53

COPYING KEYBOARD SETUP DATA (CLONING)................................................56

OPERATOR'S AND PROGRAMMER'S MAGNETIC CARDS..............................57

SYSTEM LOG.................................................................................................................57

Series 500 POS Keyboard

MAINTENANCE............................................................................................58

PRECAUTIONS.............................................................................................................58

CLEANING......................................................................................................................58

KEY LEGEND CHANGE..............................................................................................58

3/4 AND 5/8-INCH FULL TRAVEL KEYBOARDS..................................................58

KEY LEGEND CHANGE -FLAT TACTILE MEMBRANE......................................59

BATTERY REPLACEMENT........................................................................................59

Series 500 POS Keyboard

APPENDIX A

SERIES 500 POS STANDARD KEYBOARD LAYOUTS A1

APPENDIX B

KEYBOARD CABLE/CONNECTOR DATA B1

APPENDIX C

ASC11 CHARACTER SET

APPENDIX D

101/102-KEY KEYBOARD KEY NUMBER TO SCAN CODE CROSS

REFERENCE D1

LIST OF TABLES

TABLE 1. SERIES 500 POS KEYBOARD -TYPICAL CONTROLS AND

INDICATORS 8

TABLE 2. LOCAL MODE PROGRAMMING FUNCTION CODES AND

DEFAULT SETTINGS 9

TABLE 3. LOCAL MODE PROGRAMMING INSTRUCTIONS 15

TABLE 4. LOCAL PROGRAMMING COMMANDS FOR KEY MAKE/BREAK

AND EXTENDED FUNCTIONS 29

TABLE 5. REMOTE PROGRAMMING MODE COMMANDS 34

TABLE 6. RMOTE PROGRAMMING COMMANDS FOR KEY

MAKE/BREAK CODE 48

Series 500 POS Keyboard

FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE

STATEMENT

• Reorient the radio or television receiving antenna

• Relocate the keyboard with respect to the receiver

• Move the keyboard away from the receiver

If necessary the user should consult the dealer or an experienced radio/television

technician for additional suggestions. The user may find the following booklet

prepared by the Federal Communications Commission helpful: "How to Identify and

Resolve Radio/TV Interference Problems". This booklet is available from the U.S.

Government Printing Office Washington, DC 20402. Order stock number 004-000-

00345-4.

NOTICE

This equipment complies with the limits for a Class A computing

device in accordance with the specifications in Part 15 of FCC rules

which are designed to minimize radio frequency interference in the

installation; however, there is no guarantee that radio or television

interference will not occur in any particular installation. If this

equipment does cause interference to radio or television reception,

which can be determined by turning the equipment off and on while

the radio or television is on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Series 500 POS Keyboard

SCOPE

This user's guide provides the information and procedures needed to install,

operate and program your Series 500 POS Keyboard. Differences in models and

optional features are described in this manual, where applicable. It is suggested

that the entire manual be read before attempting installation or programming. If

assistance is needed that is beyond the coverage provided in this guide, please

contact Customer Service:

Ultimate Technology Corporation

100 Rawson Road

Victor New York, 14564

Phone: (800) 349-0546

Fax: (585) 924-1434

SPECIAL NOTE

When this publication was written, every effort was made to ensure that information in this

document was complete, accurate, and up to date. UltimateTechnology Corporation assumes no

responsibility for errors beyond its control. Ultimate Technology Corporation also cannot

guarantee that changes in software and equipment made by other manufacturers, and referenced

in this guide, do not effect the applicability of the information in this manual. If assistance is

needed, please contact Customer Service at the address or phone number given above.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE KEYBOARD

TO RAIN OR MOISTURE.

Contents of this publication may be changed without notice and shall not be regarded as a warranty.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT OPEN KEYBOARD ENCLOSURE WHEN

KEYBOARD IS CONNECTED TO SYSTEM.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

Series 500 POS Keyboard

Figure 1. Typical Point-of-Sale station with standard QWERTY Series 500 keyboard

PRODUCT INFORMATION

MODEL DESCRIPTION

Series 500 POS Keyboards are point-of-sale (POS) keyboards designed for use with a PC or

ASCII terminal. These keyboards have total flexibility in keyboard layout coupled with an extensive

programming capability. Each keyboard contains a built-in magnetic stripe reader (MSR), two

serial ports, two cash drawer status ports, a main keyboard port, and an auxiliary keyboard port.

The Series 500 POS Keyboard provides both the hardware and firmware interfaces necessary to

fully integrate a modular "open system" POS workstation when attached to a PC or terminal, and

connected with a printer, cash drawer and display of the users choice.

FEATURES

CHOICE OF KEYBOARD TYPES

•Full travel, standard size keys -up to 112 keys

•Full travel, compact size keys -up to 144 keys

•Flat panel (micro motion), standard size -112 keys

•Flat panel (micro motion), compact size -144 keys

All key locations are available

permanently printed or re-legendable. Full travel

keycaps have removable plastic covers for re-

legending. Flat panel membrane versions are re-

legendable by use of interchangeable overlays.

Standard keyboard configurations

including QWERTY and typical POS layouts are

available. Custom configurations of any number of

keys are also available.

FULLY USER PROGRAMMABLE

•Local (PC Keyboard)

•Remote (from Host)

•Download (Cloning)

All keys can be reprogrammed to output

any code. Single wide, double wide, and quad

keys can be placed anywhere on the keyboard.

Spacers are available for unused key locations.

BUILT-IN MAGNETIC STRIPE READER

•2 track, 3 format

•Programmable for prefix, suffix, separators and

audible annunciation

MAGNETIC STRIPE CARD CONTROLLED

SECURITY

•Keyswitch optional

TWO CASH DRAWER PORTS

•Status monitoring

Autosend (Unsolicited)

Polling (Solicited)

•Optional cash drawer firing

AUX PC KEYBOARD PORT

•For data entry when full alphanumeric capability is

needed

•For programming key codes (local method)

•For keyboard port compatible peripherals (bi-

directional)

TWO RS232 PORTS

•Serial peripherals

•Main communications port when used as a

terminal

•Hardware and software handshaking

•Selectable baud rates (300 bps -57.6 Kbps)

32K NVRAM BUILT-IN

•2048 16 character memory locations

•Control totals

•Other purposes

THREE LED INDICATORS

•User programmable

BUILT-IN AUDIBLE BEEPER

•Programmable

•Selectable tone and duration

BUILT-IN DIAGNOSTICS

•Self test

OPTIONAL PEDESTAL MOUNT
