Logitech IK1061 Manual de usuario

Setup Guide | 设置指南

Ultrathin

Magnetic clip-on

keyboard cover

iK1061

带磁力夹的键盘盖

Ultrathin - Magnetic clip-on keyboard cover

Contents / 目录

English. . . . . . . . . . . . . . . . . . 3 简体中文 . . . . . . . . . . . . . . . . 12

Ultrathin - Magnetic clip-on keyboard cover

English 3

Know your product

Ultrathin keyboard cover

50°-70°

1 32

1 2

10°-40°

1 32

Ultrathin keyboard cover

XXXXXX

www.logitech.com/support/ultrathin-i6

PDF

Ultrathin

Magnetic clip-on

keyboard cover

iK1061

带磁力夹的键盘盖

1. Protective cover

2. Battery pull tag

3. Adjustable slot for iPad®

4. Hot keys

5. Keyboard

6. Magnetic clip for attaching to iPad

7. Bluetooth and battery status light

8. Battery holder (two Lithium coin

batteries pre-installed)

9. Bluetooth® connect button

10. On/o switch

11. Documentation

Ultrathin - Magnetic clip-on keyboard cover

4 English

Set up your product

50°-70°

Ultrathin keyboard cover

UltraThin keyboard cover

XXXXXX

1. Pull out the battery tag.

• Your keyboard powers up.

The status light shows solid green

for a few seconds.

• Bluetooth discovery starts

automatically and continues

for 15 minutes. The status light

blinks blue (fast blink).

• If the status light brieﬂy

turns red, replace the batteries.

For more information, see “Replacing

your keyboard batteries.”

2. Place your iPad into the slot in

the Keyboard Cover.

3. Establish Bluetooth connection:

• On your iPad, make sure Bluetooth

is on. Select Settings > Bluetooth

> On.

• Select “Ultrathin” from the Devices

menu.

• Enter the six digit passkey shown on

your iPad screen using your Keyboard

Cover, and press Enter.

The status light shows solid blue for

a few seconds to conﬁrm that Bluetooth

connection is complete.

4. Tilt your iPad to suit your viewing angle.

Multiple angles are available to select,

from 50° to 70°.

Note:

• You will need to apply downward pressure

when you tilt your iPad.

• The maximum weight that can be loaded

onto the slot is 5kg.

Ultrathin - Magnetic clip-on keyboard cover

English 5

Hot keys

Home = iPad Home screen

Switch applications

Siri®

Use your voice to send messages,

make calls, schedule meetings,

and more

Type keywords in the search bar

for contacts, music, notes, events,

mail, web, Wikipedia, and more

Switch language

Switches the keyboard language

Virtual keyboard

Shows/hides the virtual keyboard

Screen Shot

Previous track

Play/Pause

Next track

Mute

Volume down

Volume up

Lock screen

Locks or unlocks the iPad screen

Function keys

Fn + X = Cut

Fn + C = Copy

Fn + V = Paste

Fn + Left cursor = Select left

Selects text on the left,

word by word

Fn + Right cursor = Select right

Selects text on the right,

word by word

Note:

• To select a function key, press and hold the Fn key, and then press the key indicated above.

Ultrathin - Magnetic clip-on keyboard cover

6 English

Connecting to a dierent iPad

1. Place the new iPad into the slot in

the Keyboard Cover.

2. Make sure the Keyboard Cover

is turned on.

3. On your iPad, check that Bluetooth is

turned on. Select Settings > Bluetooth

> On.

4. Press the Bluetooth® connect button on

the Keyboard Cover. The Keyboard Cover

is discoverable for 3 minutes.

5. Select “Ultrathin” from the Devices menu.

6. Enter the six digit passkey shown on

your iPad screen using your Keyboard

Cover, and press Enter.

Bluetooth connection is complete.

Use your product

Status light indications

Light Description

Solid green Battery power is good (90%-100%).

Solid red Battery power is low (less than

10%). Replace the batteries.

Blinking blue Fast: The keyboard cover is in

discovery mode, ready for pairing.

Slow: The keyboard cover is trying

to reconnect to your iPad.

Solid blue Bluetooth pairing or reconnection

is successful.

Ultrathin - Magnetic clip-on keyboard cover

English 7

Detaching your iPad

1. Pull back: Tilt your iPad backwards

until it is vertical:

50°-70°

2. Push down: Apply downward pressure

to ensure that the slot is completely ﬂat:

3. Lift iPad: Lift your iPad out of

the Keyboard Cover vertically:

Ultrathin - Magnetic clip-on keyboard cover

8 English

Attaching your iPad to the Keyboard Cover for travel

1. Slide your iPad towards the hinge at the

back of the Keyboard Cover. As your iPad

gets close to the rear hinge, it pops up:

10°-40°

2. Attach your iPad to the rear hinge:

3. Lower your iPad down on to

the Keyboard Cover until it closes.

A magnetic clip holds the iPad

in position:

Note:

• DO NOT try to slide your iPad into the hinge

from the opposite direction:

Ultrathin - Magnetic clip-on keyboard cover

English 9

Replacing your keyboard batteries

1. Place your Keyboard Cover face down

on a ﬂat surface.

2. Using a ﬁngernail or thumbnail,

pry open the battery holder:

3. Turn your Keyboard Cover over so that

the keys are facing upwards, remove the

old batteries from the holder and insert

new batteries.

4. Close the battery holder:

Note: Your Keyboard Cover is provided with

two Panasonic CR2032 3V 225mAh Lithium coin

batteries pre-installed. These provide two-year

battery life, based on two hours usage per day.

When your batteries need to be replaced,

we recommend that you use Panasonic CR2032

3V 225mAh Lithium coin batteries.

Ultrathin - Magnetic clip-on keyboard cover

10 English

Troubleshooting

The Keyboard Cover does not work

• Press any key to wake the Keyboard

Cover from sleep mode.

• Turn the Keyboard Cover O and then

back On.

• If the battery indicator ﬂashes red,

replace the batteries.

• Re-establish the Bluetooth connection

between the Keyboard Cover and iPad:

1. On your iPad, check that Bluetooth

is turned ON.

2. Select Bluetooth, locate “Ultrathin”

in the Devices list, and remove it.

(Click the “i” symbol, and select

“Forget this Device”.)

3. Turn Bluetooth OFF, and then back

on. “Ultrathin” should NOT be

displayed in the Devices list.

4. Press the Bluetooth connect button

on the Keyboard Cover.

5. Select “Ultrathin” from the Devices

menu.

6. Enter the six digit passkey shown on

your iPad screen using your Keyboard

Cover, and press Enter.

My iPad doesn’t ﬁt into the slot

• Make sure you are inserting your iPad on

its side into the slot, with the Home key

on the right hand side. (The Keyboard

Cover does not support portrait mode.)

• Make sure you are using your keyboard

cover with an iPad only, and not with any

other covers or thick glass protectors.
