LevelOne GEU-2429 Manual de usuario

24 GE + 4 GE SFP Switch GEU-2429

Easily boost your networking throughput

The GEU-2429 24 Gigabit ports that lead you to a real

Gigabit connection. Users are now able to transfer

large and high bandwidth-needed les faster and

hence get a real eciency improvement. In addition

to the cooper ports, 4 of those ports support ber

connection with the equipped SFP ports for obtaining

long-distance communication.

Oers users with fast and reliable network

The store-and-forward architecture lters errors and

forwards packets in a non-blocking environment. Flow

control ensures the correctness of data transmitting.

The 802.3x and backpressure ow control mechanisms

work respectively for full and half duplex modes.

Eeasy installation and maintenance

It supports Nway auto-negotiation protocol that

detects the networking speed (10/100/1000 Mbps)

and the duplex modes (Full/Half) automatically.

Auto-MDI/MDI-X function alleviates the eort to

use crossover cables. Also, rich diagnostic LEDs are

provided for users to get real-time information of the

connection status.

Key Features

- Complies with IEEE802.3, IEEE 802.3u, IEEE 802.3ab

and IEEE 802.3az standards.

- 24 x 10/100/1000 Mbps RJ-45 Nway ports

- 4 x SFP ports for optional ber optical

communication

- Supports NWay protocol for speed

(10/100/1000Mbps) and duplex mode (Half/Full)

auto-detection

- Support auto-detection for SFP module inset

- Supports MDI/MDI-X auto crossover

- Supports full and half duplex operation on all copper

ports

- Supports back-pressure (half duplex) and ow

control (IEEE 802.3x)

- Wire-speed packet ltering and forwarding rate

- Store-and-forward architecture lters fragment &

CRC error packets

- Supports 9K bytes Jumbo frame.

- Supports 16K MAC address entries in whole system

- 340K bytes buer memory

GNC-0105T

32-bit Gigabit Ethernet PCI Card

Works Well With

H/W Version: 1

USB-0401

USB Gigabit Ethernet Adapter

1. LED Indicators

2. 10/100/1000Mbps

RJ-45 Ports

3. SFP Slot

4. Internal Power Socket

23 41

www.level1.com

one world_one brand_one level_ Web Smart Switches

Standard

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX

IEEE 802.3ab 1000Base-T

IEEE 802.3az Energy Ecient Ethernet

IEEE 802.3x Flow Control and Back Pressure

Interface

24 x 10/100/1000 Mbps RJ-45 Ports

4 x SFP ports

NWay Protocol Support

Network speed: 10 / 100 / 1000Mbps

10Mbps: Full/Half duplex

100Mbps: Full/Half duplex

1000Mbps: Full duplex

LED Indicators

1x Power LED(Power: Green),

24 x 10/100/1000Mbps (Link/ACT: Green)

Jumbo Frame

9K bytes

Technical Specications

Packet buer memory

3.5Mbit

Mac Address Table

16K

Temperature

Operating: 0°C ~ 40°C (32°~104°F)

Storage: -10°C ~ 70°C (14°~158°F)

Humidity

Operating: 10% ~ 90% RH, non-condensing

Storage: 5%~90% RH, non-condensing

Dimension

441 x 130 x 44 mm

Power Supply

Internal Power Supply

100~240VAC/50~60Hz universal input

Emission

FCC Class A, CE, VCCI Class A

MTBF

System MTBF: 76,836

Server

GEU-2429

Product Diagram

Server Server PC PC PC

Broadband Router

Internet

Order Information GEU-2429: 24 GE + 4 GE SFP Switch

Package Contents GEU-2429

QIG Manual

Power Cord

Rack-mount Brackets

Stackable kit

All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.

V1.0

Optional Accessories

SFP-3001

1.25 G transceiver 850nm

VCSEL, SX (MMF 500m),

Duplex LC

SFP-3211

1.25 G transceiver , 1310 nm

FP-LD, LX (SMF 10m),

Duplex LC

SFP-3611

1.25 G transceiver , 1550nm

DFB-LD, ZX (SMF 80km),

Duplex LC

SFP-3711

1.25 G transceiver 1550nm

DFB-LD, EZX (SMF 120km),

Duplex LC

SFP-3841

1.25G Copper Transceiver

(RJ-45, 100m)

SFP-9421

1.25G BIDI, (SM 40km

1310/1550), Simplex LC

SFP-9431

1.25G BIDI, (SM 40km

1550/1310), Simplex LC

GVT-0300

Mini GBIC SFP transceiver, SX

Multi-Mode (550m)

GVT-0301

Mini GBIC SFP transceiver, LX

Single-Mode (10km)

GVT-0302

Mini GBIC SFP transceiver,

ZX Single-Mode (80km)
