LevelOne GSW-0508 Manual de usuario

GSW-0508

4-Port TP + 1-Port SFP

Gigabit Ethernet Switch

User Manual

Ver. 1.0.0-0806

FCC Certifications

This Equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause

harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at his own expense.

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must

accept any interference received; including interference that

may cause undesired operation.

CE Mark Warning

This equipment complies with the requirements relating to

electromagnetic compatibility, EN 55022 class A for ITE, the

essential protection requirement of Council Directive

89/336/EEC on the approximation of the laws of the Member

States relating to electromagnetic compatibility.

Company has an on-going policy of upgrading its products

and it may be possible that information in this document is

not up-to-date. Please check with your local distributors for

the latest information. No part of this document can be

copied or reproduced in any form without written consent

from the company.

Trademarks:

All trade names and trademarks are the properties of their

respective companies.

Index

Unpacking Information........ 4

Introduction ................... 4

General Description........................4

Key Features.....................................5

The Front Panel................................6

The Rear Panel.................................6

Installation ........................ 7

Desktop Installation.......................7

Network Cables Installation........8

Port Operation..................................8

Backbone Network Application..9

Product Specifications ........10

Unpacking Information

Thank you for purchasing this product. Before

installation, please verify that your package

contains the following items.

1. One 4-Port Gigabit Ethernet Switch with

1-Port Mini-GBIC

2. One AC power Adapter

3. User’s Manual

Introduction

General Description

Easily boost your networking throughput; the

product equips 4 Gigabit ports that lead you to a

real Gigabit connection. Users are now able to

transfer large and high bandwidth-needed files

faster and hence get a real efficiency improvement.

In addition to the cooper ports, 1 of the ports

supports fiber connection with the equipped

Mini-GBIC ports for obtaining long-distance

communication.

This product offers users with fast and reliable

network. The store-and-forward architecture filters

errors and forwards packets in a non-blocking

environment. Flow control prevents data loss while

transmitting. The 802.3x and backpressure flow

control mechanisms work respectively for full and

half duplex modes.

The switch features with easy installation and

maintenance. It supports Nway auto-negotiation

protocol that detects the networking speed

(10/100/1000 Mbps) and the duplex modes

(Full/Half) automatically. Auto-MDI/MDI-X function

alleviates the effort to use crossover cables. Also,

rich diagnostic LEDs are provided for users to get

real-time information of the connection status.

Key Features

zComplies with IEEE802.3, IEEE 802.3u,

IEEE 802.3ab, IEEE 802.1x and IEEE

802.3z standards.

z4 * 10/100/1000 Mbps RJ-45 Nway ports

z1* Mini-GBIC port for optional fiber optical

communication

zSupports NWay protocol for speed

(10/100/1000Mbps) and duplex mode

(Half/Full) auto-detection

zSupports MDI/MDI-X auto crossover

zSupports full and half duplex operation on

all copper ports

zSupports back-pressure (half duplex) and

flow control (IEEE 802.3x)

zWire-speed packet filtering and forwarding

rate

zStore-and-forward architecture

zSupports 9K bytes jumbo frame.

zSupports 1K bytes MAC address entries in

whole system

zBroadcast/Multiple storm control

z832K bits buffer memory

zFCC,VCCI,CE Class A

The Front Panel

Please refer to the following table for LED

definition:

LED Status Operation

Steady

Green The switch is

powered on

Power Off The switch is

powered off

Steady

Green Port connected

Blinking

Green The port is

transmitting/receiving

data

Link/Act

Off Port disconnected

The Rear Panel

To power on the switch, plug the female end of the

power cord firmly into the receptacle of the switch

and the other end into an electric service outlet.

After the power cord installation, please check if

the power LED is illuminated for a normal power

status.

Installation

This switch can be placed on your desktop directly,

or mounted in a rack. The installation is a snap.

Users can use all the features of the switch with

simply attaching the cables and turning the power

on.

Before installing the switch, we strongly

recommend:

1. The switch is placed with appropriate

ventilation environment. A minimum

25mm space around the unit is

recommended.

2. The switch and the relevant components

are away from sources of electrical noise

such as radios, transmitters and

broadband amplifiers

3. The switch is away from environments

beyond recommend moisture

Desktop Installation

1. Attach the provided robber feet to the

bottom of the switch to keep the switch

from slipping. The recommend position

has been square-marked.

2. Install the switch on a level surface that

can support the weight of the unit and

the relevant components.

3. Plug the switch with the female end of

the provided power cord and plug the

male end to the power outlet.

Network Cables Installation

1. Crossover or straight-through cable: All

the ports on the switch support

Auto-MDI/MDI-X functionality. Both

straight-through or crossover cables can be

used to connect the switch with PCs as well as

other devices like switches, hubs or router.

2. Category 3, 4, 5 or 5e UTP/STP cable: To

make a valid connection and obtain the optimal

performance. Appropriate cables corresponding

to different transmitting/receiving speed is

required. To choose a suitable cable, please

refer to the following table.

Media Speed Wiring

10Mbps Category 3,4,5 UTP/STP

100Mbps

Category 5 UTP/STP

10/100/1000

Mbps copper

1000Mbps

Category 5,5e UTP/STP

1000Mbps

Fiber

(Mini GBIC

required)

1000Mbps

he cable type differs

from the mini-GBIC you

choose. Please refer to

the instruction came with

your mini-GBIC.

Port Operation

The auto-negotiation feature allows ports

running at one of the following operation

modes:

Media Speed Duplex Mode

Full Duplex10Mbps Half Duplex

Full Duplex100Mbps Half Duplex

10/100/1000Mbps

(copper)

1000Mbps Full Duplex

1000Mbps(Fiber)

(mini GBIC required)

1000Mbps Full Duplex

Note: For the last port, when both the

fiber and cooper interfaces are connected,

the system adapts the fiber interface and

disables the relevant cooper port

automatically.

Backbone Network Application

This switch is ideal for boosting the throughput of

backbone. For an application sample of network

topology, please refer to the following chart.

Product Specifications

Standard

IEEE802.3 10BASE-T

IEEE802.3u 100BASE-TX

IEEE802.3x full-duplex flow control

IEEE802.3z/ab 1000BASE-T

Interface

4 *10/100/1000 Mbps auto

MDI/MDI-X RJ-45 switching ports

1* Mini-GBIC module sockets

Cable

Connections

RJ-45 (10BASE-T): Category 3,4,5

UTP/STP

RJ-45 (100BASE-TX): Category 5

UTP/STP

RJ-45 (1000BASE-T): Category

5,5e or enhanced UTP/STP

Fiber: depend on Mini-GBIC types

Transmission

Mode

10/100Mbps Full-duplex,

Half-duplex

1000Mbps Full-duplex

LED

indications

Power,

LINK/ACT

Memory 1K MAC entries

832K bits buffer memory

Emission FCC, CE, VCCI class A

Operating

Temperature

00~ 400C (320~ 1040F)

Operating

Humidity 10% - 90%(non-condensing)

Power

Supply External power adapter

12VDC 1A

61NB-G30500+200
