The Kramer SID-VGA UXGA Step-In Commander

Congratulations on purchasing your Kramer DigiTOOLS®SID-VGA UXGA Step-In

Commander which is ideal for boardrooms and presentation rooms.

The Kramer SID-VGA is a VGA (up to UXGA) and unbalanced stereo audio remote

control panel that is used to remotely take control of a compatible switcher, for example,

the VP-81SID.

Figure 1 and Table 1 define the SID-VGA UXGA Step-In Commander.

Figure 1: SID-VGA UXGA Step-In Commander Front and Rear Panel

Table 1: SID-VGA UXGA Step-In Commander Front and Rear Features

Feature

Function

AUDIOINPUT3.5mm Mini Jack

Connect to theunbalancedstereoaudiosource

UXGA INPUT15-pinHDConnector

Connect to theVGA videosource

STEP IN Button

Press to switch the input to this remote control commander. The

buttonlights whenactive

ON LED

Lights green when the unit receives power

LINE OUT TwistedPairRJ-45

Connector

Connect to theTPinput of acompatibleswitcher (for example,

theVP-81SID) usingCAT 6 or higher specification cable

RemoteSwitchTerminalBlock

Connections

Connecttotheremotestep-inswitch

12VDC PowerConnector

Connect to thepoweradapter

RemoteLED Terminal Block

Connections

Connect to theremoteLED(observecorrectpolarity as shown

inthegraphic)

Figure 2 illustrates how to connect the SID-VGA to a source and switcher.

Figure 2: SID-VGA Wiring Connections

To connect the SID-VGA as illustrated in Figure 2:

1. Connect the VGA video source (for example, a computer graphics source) to the

VGA connector on the front panel of the SID-VGA.

2. Connect the unbalanced stereo audio source (for example, a computer graphics

source) to the 3.5mm mini jack AUDIO INPUT connector on the front of the

SID-VGA.

3. Using STP cable, connect the LINE OUT RJ-45 connector on the rear panel of the

SID-VGA to one of the inputs on the rear panel of the VP-81SID (up to 50m

away).

4. Optional—Connect the terminal block on the rear of the SID-VGA to the remote

switch and LED.

Note: The LED supply includes a current limiting resistor and is designed to work

with any standard LED.

5. Connect the power adapter to the 12V DC connector on the rear of the SID-VGA

and to the mains electricity.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

Performing a Phase Calibration

In the event that there is noise visible on the picture, you should perform a phase

calibration.

To perform a phase calibration:

1. Press the Step-In button to ensure that the SID-VGA is the active input.

The Step-In button lights.

2. Press and hold the Step-In button.

The phase calibration pattern is displayed.

3. Release the Step-In button as soon as the noise disappears.

Technical specifications

Technical specifications of the SID-VGA are shown in Table 2.

Table 2: Technical specifications1of the SID-VGA UXGA Step-In Commander

INPUTS:

Video:1VGA (uptoUXGA)on a 15-pinHD(F) connector

Audio:1 unbalanced stereoaudio on a 3.5mm mini jack

OUTPUT:

TP on an RJ-45Ethernetconnector

STEP-IN COMMANDER

DISTANCE:

50m (164ft) up to1080p @60Hz

POWER CONSUMPTION:

12VDC, 380mA

OPERATING

TEMPERATURE:

0° to +40°C(32°to104°F)

STORAGETEMPERATURE:

–40° to+70°C (–40°to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

12cm x 7cm x 2.4cm (4.7" x 2.76" x 0.94”) W, D, H

WEIGHT:

0.3kg (0.66lbs)approx

ACCESSORIES:

Power supply

1 Product details are subject to change without notice

SID-VGA

UXGA Step-In Commander

Installation Instructions

For the latest information on our products and a list of Kramer distributors,

visit our Web site at www.kramerelectronics.com

P/N:

2900-000712

Rev:

Kramer Electronics, Ltd.

Web site: www.kramerelectronics.com

E-mail: info@kramerel.com

P/N: 2900-000712 REV 4
