Kramer RC-116 Manual de usuario

Kramer Electronics, Ltd.

USER MANUAL

Models:

TP-107AVR, XGA/Audio Line Transmitter

RC-108, Presentation Controller

RC-116, Presentation Controller

BoardView™ Kits:

Kit 2AVR: TP-107AVR (2 units) and TP-122

Kit 4AVR: TP-107AVR (4 units) and TP-122

Kit 8AVR: TP-107AVR (8 units) and TP-122

Contents

1Introduction 1

2Getting Started 2

2.1Quick Start 2

3Overview 4

3.1About the TP-107AVR/TP-122 Kits 4

3.2Controlling via the RC-108 and RC-116 Presentation Controllers 6

3.3Shielded Twisted Pair (STP)/Unshielded Twisted Pair (UTP) 6

3.4About the Power Connect™ Feature 6

3.5Recommendations for Achieving the Best Performance 7

4Your Line Transmitter, Receiver and Presentation Controllers 7

4.1Your TP-107AVR XGA/Audio Line Transmitter 8

4.2Your TP-122 XGA/Audio Line Receiver 9

4.3Your RC-108/RC-116 Presentation Controller 11

5Configuring a TP-107AVR System 13

5.1Connecting the TP-107AVR/TP-122 Transmitter/Receiver System 13

5.2Connecting the TP-107AVR/TP-122 BoardView™ Kit 15

5.3Configuring the TP-107AVR/TP-122 Kit with the RC-108 16

5.4Wiring the CAT 5 LINE IN/LINE OUT RJ-45 Connectors 17

5.5Connecting via the K-NET™ 17

5.6Setting the Address Number of the TP-107AVR 18

6Controlling the TP-107AVR 19

6.1Controlling the TP-107AVR/TP-122 Kit via the RC-108 19

6.2Controlling the TP-107AVR/TP-122 Kit via an RS-485 Controller 19

6.2.1RS-485 Communication Protocol 20

7Installing a Remote Button 22

8Flash Memory Upgrade 22

8.1Downloading from the Internet 22

8.2Connecting the PC to the RS-232 Port 22

8.2.1Connecting the RC-108 to a PC via RS-232 23

8.3Upgrading the Firmware 23

9Technical Specifications 28

Figures

Figure 1: TP-107AVR/TP-122 Configuration 5

Figure 2: TP-107AVR XGA/Audio Line Transmitter 8

Figure 3: TP-122 XGA/Audio Line Receiver 9

Figure 4: TP-122 XGA/Audio Line Receiver (Underside) 10

Figure 5: RC-108 Presentation Controller 11

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Figure 6: RC-116 Presentation Controller 11

Figure 7: RC-108 Underside Panel 12

Figure 8: RC-116 Underside Panel 12

Figure 9: Connecting the XGA/Audio Line Transmitter/Receiver System 14

Figure 10: Connecting the TP-107AVR 15

Figure 11: Configuring the TP-107AVR/TP-122/RC-108 System 16

Figure 12: CAT 5 PINOUT 17

Figure 13: Wiring the RS-485 Connector 17

Figure 14: Rotary Switch Settings 18

Figure 15: Wiring to an RS-485 Controller 20

Figure 16: Connecting a PC without using a Null-Modem Adapter 23

Figure 17: Splash Screen 23

Figure 18: Atmel – Flip Window 24

Figure 19: Device Selection Window 24

Figure 20: Device Selection Window 25

Figure 21: Loading the Hex 25

Figure 22: RS-232 Window 26

Figure 23: Atmel – Flip Window (Connected) 26

Figure 24: Atmel – Flip Window (Operation Completed) 27

Tables

Table 1: Single Units 1

Table 2: BoardView™ Kit Options 1

Table 3: Connecting a Power Adapter to a System 2

Table 4: TP-107AVR XGA/Audio Line Transmitter Features 8

Table 5: TP-122 XGA/Audio Line Receiver Features 9

Table 6: TP-122 XGA/Audio Line Receiver (Underside) Features 10

Table 7: RC-108/RC-116 Presentation Controller Features 11

Table 8: RC-108/RC-116 (Underside Panel) Features 12

Table 9: CAT 5 PINOUT 17

Table 10: Rotary Switch Setting Features 18

Table 11: RS-485 Communication Protocol (Address Number 0 – 127) 21

Table 12: RS-485 Communication Protocol (Address Number 128 – 256) 21

Table 13: Remote PINOUT 22

Table 14: Technical Specifications of the TP-107AVR 28

Table 15: Technical Specifications of the RC-108/RC-116 28

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups1that are clearly defined by function.

Thank you for purchasing the Kramer TP-107AVR XGA/Audio Line

Transmitter, and/or the RC-108 and/or RC-116 Presentation Controllers and/or

the BoardView™ kits (specified in Table 2), which are ideal for presentation

and multimedia applications.

This user manual2is supplied with each machine (see Table 1) and kit (see

Table 2). The power supply is purchased separately3.

You can purchase single TP-107AVR machines to work as standalone units or

for adding them to a BoardView™ kit, as defined in Table 1:

Table 1: Single Units

The unit Recommended Cables

TP-107AVR One K-NET4and one CAT 5 cable

RC-108 One K-NET cable

RC-116 One K-NET cable

Table 2: BoardView™ Kit Options

BoardView

Kit Name Machines

Included Recommended Cables Recommended5Power

Adapter (12V DC)6Recommended

Controller

STP CAT 5 K-NET7

2AVR Two TP-107AVR

One TP-122 2 1 1.25A N/A

4AVR Four TP-107AVR

One TP-122 4 3 2.1A RC-108

8AVR Eight TP-107AVR

One TP-122 8 7 5A RC-108/RC-116

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 For single machines as well as for the BoardView™ kits

4 Kramer model BC-2T

5 The power supply is not provided with the kit, it can be purchased separately, see Table 3

6 Adding additional single units to a kit probably changes the power requirements, see Table 3

7 K-NET™ is a proprietary Kramer protocol for interconnecting Kramer units

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Table 3: Connecting a Power Adapter to a System

The quantity of machines in a

system Recommended Power

Adapter (12V DC) Part Number

Up to two TP-107AVR units 1.25A EU/US:

UK:

Japan:

2535-000005

2535-000006

2535-700005

Three to four TP-107AVR units 2.1A EU/US:

UK:

Japan:

EU/US: 2535-000251

UK: 2535-025121

Japan: 2535-700251

Five to eight TP-107AVR units15A EU/US/UK2:

Japan: 2535-000635

2535-700635

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables3

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 If more than eight units are used, it is recommended to connect two 5A power adapters to the system

2 A desktop power supply with a DC plug. This power supply requires an AC power cord; use the power cables with a US

plug for the US, an EU plug for Europe, and a UK plug for the UK

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Getting Started

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

This section describes:

•The TP-107AVR/TP-122 BoardView™ kits, see section 3.1

•The RC-108 and the RC-116, presentation controllers, see section 3.2

•Using shielded twisted pair (STP)/unshielded twisted pair (UTP), see

section 3.3

•The Power Connect™ feature, see section 3.4

•Recommendations for achieving the best performance, see section 3.5

3.1 About the TP-107AVR/TP-122 Kits

The TP-107AVR is an XGA/Audio Line Transmitter that accepts a

computer graphics1video signal and an analog audio signal and transmits

them over a CAT 5 cable.

The TP-122 is an XGA/Audio Line Receiver2that receives the coded CAT 5

signal transmitted by a TP-107AVR decodes it and converts it to XGA,

stereo analog and S/PDIF digital audio outputs.

You can use a single TP-107AVR unit together with the TP-122 to

configure an XGA/Audio Line to Twisted Pair Transmitter and Receiver

system.

The BoardView™ kits include two, four or eight3TP-107AVR units that

can be interconnected (via CAT 5 and K-NET™ cables) and each assigned

an address number4. Pressing an ONLINE button on any of the

interconnected machines transmits the signal from that machine to the

TP-122 receiver, which is also connected to the system (see Figure 1). The

signal is then decoded on the TP-122 and converted to an XGA output and

audio outputs. If the ONLINE button is pressed simultaneously on several

machines, the machine with the highest address number transmits the signal

to the receiver (for example, address number 5 has priority over address

number 1).

If a controller (for example, the RC-108/RC-116 Presentation Controller, see

section 3.2) is connected to the BoardView™ kit, it can be used to determine

which machine in the chain has access to the TP-122.

1 The terminology XGA is used throughout this manual. This implies any RGBHV signal on a 15-pin HD computer graphics

video connector having a resolution from VGA up to and including UXGA

2 You can download the Kramer TP-122 user manual at: http://www.kramerelectronics.com

3 Single TP-107AVR units can be added to a kit (up 16 units in a chain)

4 A priority number

Overview

Figure 1: TP-107AVR/TP-122 Configuration

The TP-107AVR includes:

•A LINE IN CAT 5 connector, that connects to the LINE OUT CAT 5

connector on the previous Line Transmitter

•A LINE OUT CAT 5 connector, that connects to a receiver (for

example, the TP-122) or to the next Line Transmitter in the chain

•A pair of rotary selector switches for setting the ADDRESS (see

section 5.6)

In addition, the TP-107AVR:

•Must be controlled via KNET

•Has a resolution of up to UXGA

•Is 12V DC fed

The TP-122:

•Can power—or be powered by—the transmitter over the same CAT 5

cable (see section 3.4)

•Can change the polarity of decoding H and V Sync for video

•Includes EQ. and level controls

•Allows an operation range of more than 300ft (more than 100m) over

standard CAT 5 cable

•Is 12V DC fed

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.2 Controlling via the RC-108 and RC-116 Presentation Controllers

The RC-108 and RC-116 are presentation controllers designed specifically to

control a BoardView™ system1. Each presentation controller has the

appropriate number of input selector buttons2, an RS-485 and 12V DC port

and an RS-232 9-pin D-sub port for firmware upgrade.

3.3 Shielded Twisted Pair (STP)/Unshielded Twisted Pair (UTP)

We recommend that you use Shielded Twisted Pair (STP) cable. There are

different levels of STP cable available, and we advise you to use the best

quality STP cable that you can afford. Our non-skew-free cable, Kramer

BC-STP is intended for analog signals where skewing is not an issue. For

cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP,

may be used. Bear in mind, though, that we advise using STP cables where

possible, since the compliance to electromagnetic interference was tested

using those cables.

Although Unshielded Twisted Pair (UTP) cable might be preferred for long

range applications, the UTP cable should be installed far away from electric

cables, motors and so on, which are prone to create electrical interference.

However, since the use of UTP cable might cause inconformity to

electromagnetic standards, Kramer does not commit to meeting the standard

with UTP cable.

3.4 About the Power Connect™ Feature

The Power Connect feature applies as long as the cable can carry power.

This feature is available when using STP cable and the distance does not

exceed 50m on standard CAT 5 cable. For longer distances, heavy gauge

cable should be used3.For units which are connected via RJ-45 connectors,

make sure that the shield of the STP cable is connected to the metal casing

of the connectors on both ends of the cable. For units which are connected

via terminal block connectors, the shield of the STP cable must be

connected to a ground terminal on the units at both ends (use the ground

terminal of the power supply connection if necessary).

For a CAT 5 cable exceeding a distance of 50m, separate power supplies

should be connected to the transmitter and to the receiver simultaneously.

1 Up to eight and up to 16 units, respectively

2 Eight and 16 buttons, respectively

3 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

Your Line Transmitter, Receiver and Presentation Controllers

3.5 Recommendations for Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables1to avoid interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables).

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer product

away from moisture, excessive sunlight and dust

4 Your Line Transmitter, Receiver and Presentation

Controllers

This section defines the:

•TP-107AVR XGA/Audio Line Transmitter (see section 4.1)

•TP-122 XGA/Audio Line Receiver (see section 4.2)

•RC-108 and RC-116 Presentation Controllers (see section 4.3)

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Transmisor de Kramer

Kramer

Kramer WP-110 Manual de usuario

Kramer

Kramer TP-551N Manual de usuario

Kramer

Kramer 610T Manual de usuario

Kramer

Kramer TP-410 Manual de usuario

Kramer

Kramer TP-205A Manual de usuario

Kramer

Kramer SWT3-41-U-T Manual de usuario

Kramer

Kramer 614T Manual de usuario

Kramer

Kramer TP-114 Manual de usuario

Kramer

Kramer TP-202 Manual de usuario

Kramer

Kramer SID-X3N Manual de usuario

Kramer

Kramer 622T Manual de usuario

Kramer

Kramer DigiTOOLS KW-11T Manual de usuario

Kramer

Kramer 610T Manual de usuario

Kramer

Kramer 671T Manual de usuario

Kramer

Kramer TP-112HD Manual de usuario

Kramer

Kramer PT-571 Manual de usuario

Kramer

Kramer SID-X2N Manual de instalación y operación

Kramer

Kramer SID-VGA Manual de usuario

Kramer

Kramer VP-5R Manual de usuario

Kramer

Kramer TP-145 Manual de usuario

Kramer

Kramer PT-572HDCP+ Manual de usuario

Kramer

Kramer SID-X1 Manual de usuario

Kramer

Kramer VP-428H2 Manual de usuario

Kramer

Kramer KW-14T Manual de usuario

Manuales populares de Transmisor de otras marcas

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manual del propietario

Honeywell

Honeywell 5816WMBR Manual de usuario

Kamstrup

Kamstrup READy MTU Instrucciones de funcionamiento

Omega

Omega ZW Series Manual de usuario

ABB

ABB Field 264H Guía

Alinco

Alinco DJ-V17T Manual de usuario

Dejero

Dejero EnGo 3x Manual de usuario

Rosemount

Rosemount 4600 Manual de usuario

Speaka Professional

Speaka Professional 2342740 Manual de usuario

trubomat

trubomat GAB 1000 Manual de usuario

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manual de usuario

Rondish

Rondish UT-11 Manual de usuario

MG 10JRE Manual de usuario

Burkert

Burkert 8177 Manual de usuario

Firetide

Firetide HotPort 3203 Manual

Tele Radio

Tele Radio T9-02 Manual de usuario

Rotronic

Rotronic HygroFlex HF3 Series Manual de usuario

Jamara

Jamara FCX6 Pro Tel Manual de usuario
