Kramer 610T Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

610T

Detachable Optical DVI

Transmitter

610R

Detachable Optical DVI

Receiver

P/N: 2900-000152 Rev 6

610T, 610R – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

3Overview 3

3.1 Powering the 610T and the 610R 3

3.2 Defining EDID 4

3.3 Your Detachable Optical DVI Transmitter/ Receiver 4

4Using the Detachable Optical DVI System 5

4.1 Capturing the EDID 5

4.2 Connecting the Detachable Optical DVI Transmitter/Receiver 6

4.3 Avoiding Pitfalls with the 610T and 610R 7

5Technical Specifications 9

Figures

Figure 1: U610UDetachable Optical DVI Transmitter and Receiver 4

Figure 2: The Auto EDID Button on the U610UT 6

Figure 3: Connecting the Fiber Optic Cables 6

Figure 4: Connecting the U610UT/U610UR Detachable Optical DVI Transmitter/Receiver 7

610T, 610R - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer 610TDetachable Optical DVI

Transmitter and 610RDetachable Optical DVI Receiver, which are ideal for the

following typical applications:

•Digital flat panel displays, plasma display panels and projectors for medical

appliances, aero and traffic control, factory facilities, banks, conference

rooms and auditoriums

•Kiosks with digital flat panel displays for information display

•LED signboards in streets and in stadiums

•Digital signage

The package includes:

•610T Detachable Optical DVI Transmitter and 610R Detachable Optical DVI

Receiver

•2 power adapters (5V DC input)

•This user manual

2 610T, 610R - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance, high-resolution cables

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer 610T, 610R away from moisture, excessive sunlight

and dust

Caution: No operator serviceable parts inside the unit

Warning: Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning: Disconnect the power and unplug the unit from the wall

before installing

610T, 610R - Overview 3

3 Overview

The 610T and 610R are a detachable optical transmitter and receiver for sending

DVI signals with resolutions of up to 1920x1200 at 60Hz over LC optical cable.

The 610T attaches to the transmitter side of a fiber optical cable and the 610R

connects to the receiver end and both are sold as a set.

The 610T and 610R feature:

•A maximum data rate of 1.65Gbps

•Inputs: DVI-D on a DVI-I connector (610T); 4 LC optical connectors for R, G,

B & clock (610R)

•Outputs: 4 LC optical connectors for R, G, B & clock (610T); DVI-D on a DVI-

I connector (610R)

•No EMI/RFI

•HDTV Compatibility

•No HDCP Compliance

•A system range of up to 500m (1640ft)

•EDID capture that copies and stores the EDID from a display device (610T)

•Multi-mode fiber optic cable with 4 simplex or 2 duplex LC fiber connectors

•Compliance with the limits for a Class A digital device, pursuant to part 15

and 2 of FCC and CE

•External power adapter (supplied) or 5V DC from source

•NanoTools size

The Kramer 610T can be powered either by an external power adapter or

internally by the 5V pin on the DVI card of the computer. The 610T automatically

detects if it is being powered via the external power adapter, and if so, the internal

power supply will be cut off. The 610R module must always be powered by the

power adapter. Most laptops require that the external power adapter is used for

the transmitter.

4 610T, 610R - Overview

3.1 Defining EDID

The Extended Display Identification Data (EDID) is a data-structure provided by a

display, to describe its capabilities to a graphics card (that is connected to the

display’s source). The EDID enables the computer to “know” what kind of monitor

is connected to the output. The EDID includes the manufacturer’s name, the

product type, the timing data supported by the display, the display size, luminance

data and (for digital displays only) the pixel mapping data.

EDID is defined by a standard published by the Video Electronics Standards

Association (VESA).

3.2 Your Detachable Optical DVI Transmitter/ Receiver

Figure 1 illustrates the 610Tand 610Rdetachable optical DVI extension system:

Figure 1: 610 Detachable Optical DVI Transmitter and Receiver

610T, 610R - Using the Detachable Optical DVI System 5

4 Using the Detachable Optical DVI System

This section describes how to:

•Capture the EDID of the display device (see Section 4.1)

•Connect the detachable optical DVI transmitter and receiver (see Section 4.2)

•Troubleshooting the 610T and 610R ((see Section 4.3)

4.1 Capturing the EDID

The 610Tand 610Rare connected via four channels that transmit R, G, B and

clock signals. The EDID of the display device is captured onto the transmitter for

the computer to read.

You can capture the EDID of the display device on the 610T so that when the

computer connects to the 610T, it will read the virtual EDID information and

identify the display device. This procedure is performed only once for the

connected display device. After storing the EDID, the system can be connected

and disconnected without having to set the EDID again. If the display device is

replaced, the new EDID should be set on the 610T transmitter.

To capture the EDID of a display device, do the following:

1. Connect the 5V power adapter to the power socket of the 610T, and connect

the adapter to the mains electricity.

The Indication LED lights.

2. Push the Auto EDID button (illustrated in Figure 2), using a thin screwdriver.

3. Connect the 610T unit directly to the display device.

The Indication LED flashes several times while reading the EDID.

4. When the Indication LED stops flashing, disconnect the power.

5. Disconnect the 610T.

The EDID information is now stored and the Indication LED is on.

6 610T, 610R - Using the Detachable Optical DVI System

Figure 2: The Auto EDID Button on the 610T

4.2 Connecting the Detachable Optical DVI

Transmitter/Receiver

To connect the 610T Detachable Optical DVI Transmitter with the 610R

Detachable Optical DVI Receiver, as the example in Figure 4 illustrates, do the

following:

1. Set the EDID of the display device (see Section 4.1).

2. Plug the 610T DVI connector directly to the DVI connector of the computer.

Do not use any intermediate cable or adapter between them.

3. Connect the 610R to the 5V DC power adapter and connect the adapter to

the mains electricity. The Indication LED is on.

4. Connect the 610R DVI connector directly to the DVI connector of the display

device.

Do not use any intermediate cable or adapter between them.

5. Connect the duplex LC fiber cables to the 610T and 610R modules, one

cable at a time, as illustrated in Figure 3.

Two duplex LC receptacles connected to two duplex LC patch cord multimode glass of

fibers with a 62.5/125µm or a 50/125µm core.

Figure 3: Connecting the Fiber Optic Cables

6. Turn ON the Power on the computer and the display device.

7. If the transmitter does not power up, connect the 5V power adapter to the

610T transmitter, and connect the adapter to the mains electricity.

The Auto

EDID Button

123 4

123

610T Transmitter 610R Receiver

610T, 610R - Using the Detachable Optical DVI System 7

You can use the power supplied through a DVI pin from the graphic cards instead of

using the power adapter. After completing the installation, if the system does not seem

to work properly, reconnect the power adapter while the system is powered.

8. Set up the screen resolution as required.

Figure 4: Connecting the 610T/610R Detachable Optical DVI Transmitter/Receiver

4.3 Avoiding Pitfalls with the 610T and 610R

If any of these problems occur, we recommend the following:

If the display device shows only a black screen:

•Check that all the AC and DC plugs and jacks used by the external power

supplies are firmly connected

•Check that the DVI ports are firmly plugged into the computer and the

display device, and be sure that the transmitter and receiver modules are

correctly plugged into the computer and display device, respectively

•Check if the computer and display are powered ON and properly booted

•Reset the system by unplugging and then replugging the transmitter DVI port

or receiver DVI port and then reboot the system

If the screen is distorted or displays noise:

•Check if the graphics resolution is properly set

•Go to the Display Properties of Windows and check the settings

8 610T, 610R - Using the Detachable Optical DVI System

•Be sure that the resolution is set for WUXGA (1920 x 1200) at 60Hz, or lower

•Reset the system

•Disconnect and reconnect the optical DVI cables

Be sure that at all times the cables are stored and used away from

liquid or dirt.
