Konica Minolta Magicolor 2430 DL Manual de usuario

magicolor 2430 DL

Printer Driver for

Mac OS 9 User’s Guide

4139-7749-01A

1760672-001A

The digitally encoded software and publication included with your printer are

Marunouchi Center Building, 1-6-1 Marunouchi, Chiyoda-ku, Tokyo, 100-0005,

This software may not be reproduced, modified, displayed, transferred, or copied in

any form or in any manner or on any media, in whole or in part, without the express

written permission of KONICA MINOLTA PRINTING SOLUTIONS U.S.A., INC.

No part of this publication may be reproduced, stored in a retrieval system, or trans-

mitted in any form or by any means, electronic, mechanical, photocopying, record-

ing, or otherwise, without the prior written permission of KONICA MINOLTA. The

information contained in this guide is intended for use with the KONICA MINOLTA

magicolor 2430 DL printers only.

Trademarks

KONICA MINOLTA and the KONICA MINOLTA logo are trademarks or registered

trademarks of KONICA MINOLTA HOLDINGS, INC.

magicolor is a trademark or registered trademark of KONICA MINOLTA PRINTING

SOLUTIONS U.S.A., INC.

Notice

KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to make

changes to this guide and to the equipment described herein without notice. Consid-

erable effort has been made to ensure that this manual is free of inaccuracies and

omissions. However, KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. makes

no warranty of any kind including, but not limited to, any implied warranties of mer-

chantability and fitness for a particular purpose with regard to this manual.

KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. assumes no responsibility

for, or liability for, errors contained in this manual or for incidental, special, or conse-

quential damages arising out of the furnishing of this manual, or the use of this man-

ual in operating the equipment, or in connection with the performance of the

equipment when so operated.

System Requirements for the Printer Driver 1

System Requirements for the Printer Driver

Before installing the printer driver, make sure that your system meets the fol-

lowing system requirements.

Computer Apple Macintosh computer with a Pow-

erPC G3 or later processor (PowerPC G4

or later is recommended)

Connection between computer

and printer

USB connection

Network connection

(10Base T/100Base TX)

Operating system Mac OS 9.0.4 or later

Mac OS X Classic mode (9.2.2 or later)

When using the Classic environment of

Mac OS X, Mac OS X 10.2.6 or later is

required.

RAM More than OS recommendation (128 MB

or more is recommended)

Available disk space 256 MB or more is recommended (for

storing images)

Installing the Printer Driver2

Installing the Printer Driver

1Double-click the magicolor 2430 DL Installer icon.

The installer for the printer driver starts up.

" When using Mac OS X, start up the Classic environment before

installing the printer driver.

2Check the details of the license agreement, and click Accept if you agree

to the terms of the license.

3While Easy Install is selected, click Install.

Easy Install installs the printer driver and ColorSync profiles.

Installation starts.

Selecting the Printer in the Chooser 3

4After the installation has been completed, click Quit.

This completes the installation of the magicolor 2430 DL printer driver.

Selecting the Printer in the Chooser

1Connect the printer and computer.

If you are using a USB connection, use the USB cable to connect the

printer and your computer.

If you are using a network connection, use an 10Base-T/100Base-TX

cable to connect the printer to a Ethernet network.

2Select Chooser from the Apple menu.

" When using Mac OS X, the Apple menu is available with the icon

for the Classic environment in the menu bar.

To display the Classic status in the menu bar, select the “Show

Classic status in menu bar” check box in the Classic dialog box.

Selecting the Printer in the Chooser4

3Select the magicolor 2430 DL icon from the icons on the left side of the

Chooser.

The printer name appears in the Select a printer section on the right side

of the Chooser.

The icon displayed for the printer name differs depending on whether you

are using a USB connection or a network connection.

4Select the printer.

If you are using a USB connection, select the icon.

If you are using a network connection, select the icon.

5Click Configure.

The Printer Setup dialog box appears.

6Select the options that are installed, and then click OK.

7Close the Chooser.

The icon for the magicolor 2430 DL appears on the desktop.

With a USB connection, mc2430DL appears.

With a network connection, KONICA MINOLTA magicolor2430D

appears.

" In the Classic environment, no icon appears on the desktop.

Selecting the Printer in the Chooser 5

" You can log in to PageScope Web Connection and use the Rendez-

vous Configuration menu to change the name of the printer. If

Enable Rendezvous Service Discovery is not selected, the printer

name will not appear in the Select a printer section on the right side

of the Chooser. Refer to Utilities and Documentation CD-ROM for a

description of PageScope Web Connection.

Specifying Page Setup Settings6

Specifying Page Setup Settings

The Page Setup dialog box appears when Page Setup... is selected from the

File menu.

Page Attributes Options

The Page Attributes section is used to specify the options for the Paper

Size, scaling, and page orientation.

Paper Size

Select the desired Paper Size from the Paper Size pop-up menu.

Show all Paper Sizes

Select to display all available paper sizes in the Paper Size pop-up menu.

Scaling (%)

If you want to enlarge or reduce the size of the printout, enter the scale

ratio (25%-400%) here.

Orientation

Select either a vertical or horizontal page orientation for printouts.

Flip Horizontal: Select this option to flip the image along its vertical

axis; the left and right sides of the print image are

reversed.

Flip Vertical: Select this option to flip the image along its horizon-

tal axis; the top and bottom of the print image is

inverted.

" Regardless of which paper size is selected, the printer does not print

within 0.157 inch (4 mm) of the edge of the paper.

Specifying Page Setup Settings 7

Specifying a Custom Paper Size

You can also specify a paper size that is not listed in the Paper Size pop-up

menu.

1Select Edit Custom Paper Sizes... from the Paper Size pop-up menu, in

the Page Setup dialog box.

The Edit Paper Sizes dialog box appears.

2Enter a name for the custom paper size in the Name field, enter the

dimensions in the Width and Height fields, and then click Add.

" The default units used for the dimensions for Width and Height is

inches. To specify the dimensions in millimeters, enter “mm” after

entering the each of the values for the dimensions.

Specifying Page Setup Settings8

3To add several different custom paper sizes, click New and repeat step 2.

" To delete an existing custom paper size, select the custom paper

size from the list on the left of the dialog box, and then click Delete.

4The custom paper size setting is saved, and the name of the custom

paper size can now be selected from the Paper Size pop-up menu.

5After you have finished entering the settings, click Done.

If you clicked Add in step 2, but do not save the custom paper size set-

ting, a message appears, asking if you want to save the settings. Click

OK.

" The Default Size option in the lower left of the Edit Paper Sizes

dialog can be used to select the default paper size. Changes to

this setting take effect the next time the application is used.
