jbc TR245-A Manual de usuario
Soldering Irons for Automation
Ref. TR245-A
INSTRUCTION MANUAL
www.jbctools.com
Packing List
The following items are included:
Manual ......................... 1 unit
Ref. 0020951
Insulator ..................... 1 unit
Ref. 0020440
Screws
DIN 912 M3X10............. 2 units
Ref. 0722900
Clamp .............................. 1 unit
Ref. 0018779
Screw
DIN 912 M4X16............. 1 unit
Ref. 0002984
Soldering Iron ........... 1 unit
Ref. TR245-A
Works with
R245 Cartidges
2
Assembly
Soldering Iron
for Automation*
Ref. TR245-A
Insulator Bushing
Ref. 0020440
Clamp
Ref. 0018779
Screw
Ref. 0002984
* If the Soldering Iron is fixed in another way, it must be isolated from the fixation.
The electrical Insulator Bushing
must be assembled for the tool to
work properly.
Do not remove the Insulator
Bushing.
Cooling fitting
For the correct operation
of this tool constant air flow is
needed. Always provide clean air.
Input preassure: 0,4 bar/ 5,8 psi.
www.jbctools.com
3
Screws
Ref. 0722900
Soldering Head
for Automation*
Ref. RBA-A
Assembly with RBA-A
* Not included, sold separately
The TR245 is connecta-
ble to the UCR245 using
the Tool Cable
Ref. 0021403
4
Inserting and removing Cartridges
The square recess of the Soldering Iron for
Automation must be matched with the square
shape of the Cartridge. Insert the Cartridge
until the two square shapes come to a limit
stop inside.
Insert the cartridge and press lightly until it
is placed in the Soldering Iron for Automation
(a). Use an allen key to tighten the Cartridge
in the Handle (b).
a
b
Cartridge range
Find the cartridge models that best suits your soldering needs in www.jbctools.com
Compatibility
Cartridge Range Control Unit
TR245 R245 UCR245
RBA, SFR, GSFR and CLMR are compatible with both R245 and R470 ranges.
For any hand operation make sure the power is off and both tool and cartridge are cold.
Before removing or inserting the cartridge, make sure air preassure is off.
www.jbctools.com
5
Dimensions
mm
(in)
TR245-A
6
Maintenance
- Before carrying out maintenance, always unplug the tool.
- Use a damp cloth to clean the tool. Alcohol can only be used to clean the metal parts.
- Periodically check that the metal parts of the tool are clean so the station can detect the tool status.
- Maintain tip surface clean and tinned prior to storage in order to avoid tip oxidation.
Rusty and dirty surfaces reduce heat transfer to the solder joint.
- Replace any defective or damaged parts. Use original JBC spare parts only.
- Repairs should only be performed by a JBC authorized technical service.
It is imperative to follow safety guidelines to prevent electric shock,
injury, fire or explosion.
- Do not use the soldering iron for any purpose other than soldering or rework. Incorrect use may
cause fire.
- The temperature of accessible surfaces may remain high after the unit is turned off. Handle with care.
- Do not leave the appliance unattended when it is on.
- Be sure that the power supply is disconnected before changing any spare part.
- Allow cartridges to cool down before changing them.
- Heat can cause inflamable products to ignite even when not visible.
- Avoid flux coming into contact with skin or eyes to prevent irritation.
- Be careful with the fumes produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protective glasses and gloves when
working to avoid personal injury.
- Utmost care must be taken with liquid tin waste which can cause burns.
Safety
www.jbctools.com
7
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
www.jbctools.com
0024719-0420
Specifications
TR245-A
- Net Weight: 230 g (0.51 lb)
- Dimensions: 144.5 x 28 mm (5.69 x 1.10 in)
Clamp only
- Net Weight: 44 gr (0.10 lb)
- Dimensions: 55 x 33.5 x 10 mm (2.16x 13.18 x 0.39 in)
Complies with CE standards.
