Interlogix TruVision TVB-4410 Manual

P/N 1073359-EN • REV B • ISS 22AUG17

TruVision HD

-TVI 5MPX

Camera Installation

and

Configuration Man

ual

Installation and Configuration Manual 1

Contents

Introduction 5

Product overview 5

HD-TVI fixed lens bullet camera: 5

HD-TVI VF motorized lens bullet camera: 5

HD-TVI fixed lens turretcamera: 5

HD-TVI VF motorized lens turret camera: 6

HD-TVI VF motorized lens dome camera: 6

Installation 7

Installation environment 7

Package contents 10

HD-TVI fixed lens bullet camera 10

HD-TVI VF motorized lens bullet camera 12

HD-TVI fixed lens turret camera 14

HD-TVI VF motorized lens turret camera 17

HD-TVI VF motorized lens dome camera 19

Camera description 22

Mounting the HD-TVI fixed lens bullet camera 28

2 Installation and Configuration Manual

Surface mount 28

Surface mount when using the optional back

box 30

Mounting the HD-TVI VF motorized lens bullet

camera 34

Surface mount when not using the supplied

back box 34

Surface mount when using the back box 37

Mounting the HD-TVI fixed lens turret camera 40

Surface mount 40

Surface mount when using the optional back

box 45

Mounting the HD-TVI VF motorized lens turret

camera 48

Surface mount 48

Surface mount when using the optional back

box 53

Mounting the HD-TVI VF motorized lens dome

camera 57

Surface mount 57

Installation and Configuration Manual 3

Programming 61

Call up the camera OSD menu 62

Menu trees 64

TVB-2409/4409 and TVT-2403/4403 cameras 65

TVB-2410/4410, TVT-2404/4404, and TVD-

2406/4406 cameras 66

Configuration 67

Output Mode 67

Focus 69

Language 69

Main Menu 70

Exposure 70

White Balance 74

Day/Night 75

Video Settings 77

Reset 79

Save & Exit 79

4 Installation and Configuration Manual

Specifications 80

Legal and regulatory information 83

Installation and Configuration Manual 5

Introduction

Product overview

This is the installation guide for TruVision

5MPX HD-TVI camera models:

HD-TVI fixed lens bullet camera:

TVB-2409 (5MPX Bullet, 3.6 mm lens, PAL)

TVB-4409 (5MPX Bullet, 3.6 mm lens,

NTSC)

HD-TVI VF motorized lens bullet

camera:

TVB-2410 (5MPX Bullet, 2.8 to 12 mm lens,

PAL)

TVB-4410 (5MPX Bullet, 2.8 to 12 mm lens,

NTSC)

HD-TVI fixed lens turret camera:

TVT-2403 (5MPX Turret, 2.8 mm lens, PAL)

TVT-4403 (5MPX Turret, 2.8 mm lens,

NTSC)

6 Installation and Configuration Manual

HD-TVI VF motorized lens turret

camera:

TVT-2404 (5MPX Turret, 2.8 to 12 mm lens,

PAL)

TVT-4404 (5MPX Turret, 2.8 to 12 mm lens,

NTSC)

HD-TVI VF motorized lens dome

camera:

TVD-2406 (5MPX Dome, 2.8 to 12 mm lens,

PAL)

TVD-4406 (5MPX Dome, 2.8 to 12 mm lens,

NTSC)

Installation and Configuration Manual 7

Installation

This section provides information on how to

install the cameras.

Installation environment

Please keep in mind that there are

restrictions/rules when using the HD-TVI

5MPX cameras with TruVision TVI recorders:

The TVI 5MPX cameras only work with the

higher resolution TVI recorders (TVR 15HD

or TVR 45HD, or higher), firmware version

1.1 (or higher)

A maximum number of TVI 5MPX cameras

can be supported per TVI recorder

The TVI 5MPX cameras are only supported

on specific ports of the TruVision TVI

recorders

8 Installation and Configuration Manual

Guidelines:

TVR 15HD four-channel recorder, v1.1:

Supports a maximum of one TVI 5MPX

camera on BNC port 1

TVR 15HD/TVR 45HD eight-channel

recorder, v1.1: Supports up to two TVI

5MPX cameras on BNC ports 1 and 2

TVR 15HD/TVR 45HD 16-channel recorder,

v1.1: Supports up to four TVI 5MPX

cameras on BNC ports 1, 2, 3 and 4

When installing your product, consider these

factors:

•Electrical: Install electrical wiring carefully.

It should be done by qualified service

personnel. Always use a proper 12 VDC or

24 VAC UL listed Class 2 or CE certified

power supply to power the camera. Do not

overload the power cord or adapter.

•Ventilation: Ensure that the location

planned for the installation of the camera is

well ventilated.
