TruVision

Panoramic

-Fi Wedge IP

Camera Installation

Guide

P/N 1073033-EN • REV A • ISS 29SEP15

Interlogix is part of UTC Building & Industrial Systems, a unit of United

Trademarks and patents

Trade names used in this document may be trademarks or registered trademarks

of the manufacturers or vendors of the respective products.

Manufacturer

Interogix

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA

UTC Fire and Security Inc.

858 Partridge Dr., Burlington, ON

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

4. Consult the dealer or an experienced radio technician for help.

CC Caution

To assure continued compliance, use only shielded interface cables when

connecting to computer or peripheral devices. Any changes or modifications not

expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference

(2) This Device must accept any interference received, including interference that

may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Federal Communication Commission (FCC) Radiation Exposure Statement

This equipment complies with FCC radiation exposure set forth for an

uncontrolled environment. In order to avoid the possibility of exceeding the FCC

radio frequency exposure limits, human proximity to the antenna shall not be less

than 20 cm (8 inches) during normal operation.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux

appareils radioexempts de licence. L'exploitation est autorisée aux deux

conditions suivantes :

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d'en compromettre le fonctionnement.

Under Industry Canada regulations, this radio transmitter may only operate using

an antenna of a type and maximum (or lesser) gain approved for the transmitter

by Industry Canada. To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the equivalent isotropically

radiated power (e.i.r.p.) is not more than that necessary for successful

communication.

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio

peut

fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur)

approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les

risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut

choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée

équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une

communication satisfaisante.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF

THE EUROPEAN PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio

equipment and telecommunication terminal Equipment and the mutual

recognition of their conformity (R&TTE). The R&TTE Directive repeals and

replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment

and Satellite Earth Station Equipment) as of April 8, 2000.

Safety

This equipment is designed with the utmost care for the safety of those who

install and use it. However, special attention must be paid to the dangers of

electric shock and static electricity when working with electrical equipment. All

guidelines of this and of the computer manufacture must therefore be allowed at

all times to ensure the safe use of the equipment.

National Restrictions

This device is intended for home and office use in all EU countries (and other

countries following the EU directive 1999/5/EC) without any limitation except for

the countries mentioned below:

Country Restriction Reasons/remarks

Bulgaria

None

General authorization required for

outdoor use and public service

France

Outdoor use;

limited to 10 mW

e.i.r.p. within the

band 2454-

2483.5 MHz.

Military Radiolocation use. Refarming

of the 2.4 GHz band has been ongoing

in recent years to allow current relaxed

regulation. Full implementation

planned 2012

Luxembourg

None

General authorization required for

network and service supply(not for

spectrum).

Annex 3 B and A Wideband Data Transmission systems 2400.0-2483.5 MHz:

Country Restriction Reasons/remarks

Norway

Implemented

This subsection does not apply for the

geographical area within a radius of

20 km from the centre of Ny-Ålesund.

Italy

Implemented

The public use is subject to general

authorization by the respective service

provider.

Russian

Federation

Limited

implementation

1. SRD with FHSS modulation

1.1. Maximum 2.5 mW e.i.r.p.

1.2. Maximum 100 mW e.i.r.p.

Permitted for use SRD for outdoor

applications without restriction on

installation height only for purposes of

gathering telemetry information for

automated monitoring and resources

accounting systems. Permitted to use

SRD for other purposes for outdoor

applications only when the installation

height is not exceeding 10 m above

the ground surface. 1.3 maximum

100 mW e.i.r.p. indoor applications.

2. SRD with DSSS and other than

FHSS wideband modulation

2.1. Maximum mean e.i.r.p. density is

2 mW/MHz. Maximum 100 mW e.i.r.p.

2.2. Maximum mean e.i.r.p. density is

20 mW/MHz. Maximum 100 mW

e.i.r.p. It is permitted to use SRD for

outdoor applications only for purposes

of gathering telemetry information for

automated monitoring and resources

accounting systems or security

systems.

2.3. Maximum mean e.i.r.p. density is

10 mW/MHz. Maximum 100 mW

e.i.r.p. indoor applications.

Ukraine

Limited

implementation

e.i.r.p. ≤100 mW with built-in antenna

with amplification factor up to 6 dBi.

The following information shall also be included in the case of radio equipment

intentionally emitting radio waves:

(a) frequency band(s) in which the radio equipment operates;

(b) maximum radio-frequency power transmitted in the frequency band(s) in

which the radio equipment operates.

2012/19/EU (WEEE directive): Products marked with this

symbol cannot be disposed of as unsorted municipal waste

in the European Union. For proper recycling, return this

product to your local supplier upon the purchase of

equivalent new equipment, or dispose of it at designated

collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product contains a

battery that cannot be disposed of as unsorted municipal

waste in the European Union. See the product

documentation for specific battery information. The battery

is marked with this symbol, which may include lettering to

indicate cadmium (Cd), lead (Pb), or mercury (Hg). For

proper recycling, return the battery to your supplier or to a

designated collection point. For more information see:

www.recyclethis.info.

Contact

information

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

Installation Guide 1

Content

Introduction 2

Product overview 2

Installation 2

Installation environment 2

Package contents 3

Cable requirements 5

Camera description 6

Setting up the camera 6

Setting up Wi-Fi transmission 7

Accessing the SD card 14

Connecting a speaker 15

Alarm input connection 16

Alarm output connection 16

Resolution and viewing angle 18

Mounting the accessories 20

Mounting the wedge camera 23

Using the camera with a recorder 39

Using the camera with TruVision Navigator 39

Specifications 40

TruVision IP wedge cameras 40

Pin definitions 42

2 Installation Guide

Introduction

Product overview

This is the installation guide for TruVision Panoramic wedge

camera models:

TVW-1130 (3MPX Panoramic, 1.6 mm lens, Gray, Wi-Fi,

PAL)

TVW-3130 (3MPX Panoramic, 1.6 mm lens, Gray, Wi-Fi,

NTSC)

Note:

The camera has a horizontal viewing angle range of between

127 to 160 degrees, depending on the resolution ratio settings.

Installation

This section provides information on how to install the cameras.

Installation environment

When installing your product, consider these factors:

•Electrical: Install electrical wiring carefully. It should be

done by qualified service personnel. Always use a proper

PoE switch or a 12 VDC UL listed Class 2 or CE certified

power supply to power the camera. Do not overload the

power cord or adapter.

•Ventilation: Ensure that the location planned for the

installation of the camera is well ventilated.

•Temperature: Do not operate the camera beyond the

specified temperature, humidity or power source ratings.

Installation Guide 3

The operating temperature of the camera is between -30

to +60°C (-22 to 140°F). Humidity is below 90%.

•Moisture: Do not expose the camera to rain or moisture,

or try to operate it in wet areas. Turn the power off

immediately if the camera is wet and ask a qualified

service person for servicing. Moisture can damage the

camera and also create the danger of electric shock.

•Servicing: Do not attempt to service this camera yourself.

Any attempt to dismantle or remove the covers from this

product will invalidate the warranty and may also result in

serious injury. Refer all servicing to qualified service

personnel.

•Cleaning: Do not touch the sensor modules with fingers. If

cleaning is necessary, use a clean cloth with some ethanol

and wipe the camera gently. If the camera will not be used

for an extended period of time, put on the lens cap to

protect the sensors from dirt.

Package contents

Check the package and contents for visible damage. If any

components are damaged or missing, do not attempt to use the

unit; contact the supplier immediately. If the unit is returned, it

must be shipped back in its original packaging.

IP wedge camera

Camera:

4 Installation Guide

Installation manual:

CD with Configuration

Manual and TruVision Device

manager:

Template to mount with

the converter pan:

Template A:

Template B:

Screws:

Drywall anchor

Φ7.5 x 24.5mm (3 pcs)

Screw M4

(4 x 25mm (3 pcs)

Water joint: provides

water resistance to

network connection.

12 VDC connector: DC jack

socket to terminal connectors

with positive and negative

indicators.

Tabla de contenidos

Otros manuales de Cámara IP de Interlogix

Interlogix

Interlogix TruVision Line Manual de usuario

Interlogix

Interlogix TVB-2203 Manual de usuario

Interlogix

Interlogix UltraSync RS-3230 Hoja de instrucciones

Interlogix

Interlogix TruVision Line Manual de usuario

Interlogix

Interlogix TruVision TVC-1201 Hoja de instrucciones

Interlogix

Interlogix TruVision Line Hoja de instrucciones

Interlogix

Interlogix TruVisioin 12 Series Manual de usuario

Interlogix

Interlogix TruVision 11/31 Series Manual de usuario

Interlogix

Interlogix TruVision Line Hoja de instrucciones

Interlogix

Interlogix TVD-2202 Manual de usuario

Interlogix

Interlogix TruVision TVF-5201 Hoja de instrucciones

Interlogix

Interlogix TruVision 6 Series Manual de usuario

Interlogix

Interlogix UltraView IP XP4 Box Day/Night Range Camera Manual de usuario

Interlogix

Interlogix FW5.1 Manual de usuario

Interlogix

Interlogix TruVision Bullet IR TVC-BIR6-SR Manual de usuario

Interlogix

Interlogix VC-IP-XP4DN-HR Manual de usuario

Interlogix

Interlogix TruVision TVB-4409 Manual

Interlogix

Interlogix VD-IP-XP4DNP Manual de usuario

Interlogix

Interlogix TVB-5302 Hoja de instrucciones

Interlogix

Interlogix TruVision Line Hoja de instrucciones

Interlogix

Interlogix TruVision 11 Series Manual de usuario

Interlogix

Interlogix TruVision TVT-2202 Manual de usuario

Interlogix

Interlogix TruVision Line Manual de usuario

Interlogix

Interlogix TVD-TIR6-MR Manual de usuario

Manuales populares de Cámara IP de otras marcas

FLIR

FLIR Exx series Manual de usuario

Avigilon

Avigilon H4A-BO1-IR Manual de usuario

Digital Watchdog

Digital Watchdog DWCA-C128-64 Manual de usuario

ShareTech

ShareTech AV1 Manual de usuario

Ezviz

Ezviz C6C Manual de usuario

Melchioni

Melchioni UCAM 2015 Manual de usuario

Geutebruck

Geutebruck G-Cam/ESD-4630 Manual de usuario

Arecont Vision

Arecont Vision MegaBall AV3146DN-3310-D-LG Manual de usuario

Mitel

Mitel 6800i Series Manual de servicio

Vitek

Vitek VTC-IR403-212NP Manual de usuario

THOMSON

THOMSON DSC - 323W Manual de usuario

AVer

AVer FB2027 Manual de usuario

ENFORCER

ENFORCER EV-T5105-N2SQ Manual de usuario

Wansview

Wansview NC543 Manual de usuario

Eneo

Eneo MCB-64A0003M0A Manual de usuario

deView electronics

deView electronics CBDNI36F Manual de usuario

Swann

Swann SwannEye Manual de usuario

LevelOne

LevelOne IP CamSecure Manual de usuario
