EXT-HDRS2IR-4K2K-1FO

User Manual

*Preferred

RELEASE A1

4K Ultra HD Extender

over One Fiber

w/ RS-232 and 2-way IR

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install or place this product near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. To reduce the risk of electric shock and/or damage to this product, never handle or

touch this unit or power cord if your hands are wet or damp. Do not expose this

product to rain or moisture.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Batteries that may be included with this product and/or accessories should never be

exposed to open ame or excessive heat. Always dispose of used batteries

according to the instructions.

Important Safety Instructions

iii

Gefen warrants the equipment it manufactures to be free from defects in material and

workmanship.

If equipment fails because of such defects and Gefen is notied within two (2) years from

the date of shipment, Gefen will, at its option, repair or replace the equipment, provided

that the equipment has not been subjected to mechanical, electrical, or other abuse or

modications. Equipment that fails under conditions other than those covered will be

repaired at the current price of parts and labor in effect at the time of repair. Such repairs

are warranted for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or tness for any particular purpose, all of

which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cables must be in their original

condition.

The information in this manual has been carefully checked and is believed to be accurate.

However, Gefen assumes no responsibility for any inaccuracies that may be contained

in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or

consequential damages resulting from any defect or omission in this manual, even if

advised of the possibility of such damages. The technical information contained herein

regarding the features and specications is subject to change without notice.

For the latest warranty coverage information, refer to the Warranty and Return Policy under

the Support section of the Gefen Web site at www.gefen.com.

Warranty Information

Technical Support

8:00 AM to 5:00 PM Monday - Friday, Pacic Time

(818) 772-9100 (800) 545-6900

Fax

(818) 772-9120

[email protected]

Web

http://www.gefen.com

Mailing Address

Gefen, LLC

c/o Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

Product Registration

section of the Gefen Web site.

Contacting Gefen Technical Support

Operating Notes

• This product operates with SC-terminated single strand multimode ber optic cable.

Singlemode ber is not supported.

4K Ultra HD Extender over One Fiber w/ RS-232 and 2-way IR is a trademark of Gefen, LLC.

All trademarks are the property of their respective owners.

Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation

without prior written notice.

This product uses UL or CE listed power supplies.

Features and Packing List

Features

• Extends HDMI, RS-232, and Bi-Directional IR over a single ber strand

• Extends Ultra HD 4K x 2K (3840 x 2160 @ 30Hz) up to:

► 3300 feet (1000 meters) over 50/125μm OM3e/OM4 ber

► 500 feet (150 meters) over 50/125μm (OM3) ber

► 165 feet (50 meters) over 62.5/125μm (OM1) ber

• Extends 1080p Full HD (1920 x 1080 @ 60Hz) up to:

► 6600 feet (2000 meters) over 50/125μm OM3e/OM4 ber

► 1000 feet (300 meters) over 50/125μm (OM3) ber

► 330 feet (100 meters) over 62.5/125μm (OM1) ber

• Supported HDMI Features

►HDCP-compliant

►12-bit Deep Color

► LPCM 7.1, Dolby® TrueHD, and DTS-HD Master Audio™

►3DTV pass-through

►Lip-sync pass-through

• EDID Management for rapid integration of source and display

• Full duplex RS-232 up to 115200 baud

• RS-232 pass-through

• Automatic calibration based on the type and length of ber optic cable

• Immune to electromagnetic interference (EMI)

• Locking power supplies

• Firmware upgradable via USB

• Surface-mountable

1080P

vii

Packing List

The 4K Ultra HD Extender over One Fiber w/ RS-232 and 2-way IR ships with the items

listed below. If any of these items are not present in the box when you rst open it,

immediately contact your dealer or Gefen.

• 1 x 4K Ultra HD Extender over One Fiber w/ RS-232 and 2-way IR (Sender unit)

• 1 x 4K Ultra HD Extender over One Fiber w/ RS-232 and 2-way IR (Receiver unit)

• 1 x 6 ft. HDMI cable (M-M)

• 1 x DB-9 cable (M-F)

• 1 x IR extender

• 1 x IR emitter

• 2 x 5V DC power supplies

• 1 x Quick-Start Guide

Features and Packing List

viii

Table of Contents

1 Getting Started

Introduction............................................................................................................ 2

Sender Unit ................................................................................................... 2

Receiver Unit................................................................................................. 4

Installation ............................................................................................................. 6

Connection Instructions................................................................................. 6

Sample Wiring Diagram ................................................................................ 6

2 Basic Operation

Bidirectional IR Control........................................................................................ 10

Controlling the Source from the Viewing Location ...................................... 10

Controlling the Display from the Source Location ....................................... 11

Controlling the Source / Display from Different Locations........................... 12

LED Indicator Status ........................................................................................... 13

DIP Switch Conguration .................................................................................... 15

Baud Rate ................................................................................................... 16

Using RS-232...................................................................................................... 17

3 Appendix

Updating the Firmware........................................................................................ 20

Installing the Device Driver ......................................................................... 20

Updating the Firmware................................................................................ 25

Surface Mounting Instructions............................................................................. 28

Specications ...................................................................................................... 29
