USER MANUAL

20600 Nordhoff St, Chatsworth CA 91311

1-800-545-6900 818-772-9100

Keyboard

Mouse

Trackball

Touchscreen

ASKING FOR ASSISTANCE

TechnicalSupport:

Telephone (818) 772-9100

(800)545-6900

Fax (818) 772-9120

TechnicalSupportHours:

8:00AMto5:00PMMondaythruFriday.

WriteTo:

GefenSystems

c/o CustomerService

20600 Nordhoff Street

Chatsworth, CA 91311 USA

Notice

GefenSystemsreservestherighttomakechangesinthe

hardware,packagingandanyaccompanyingdocumentation

withoutpriorwrittennotice.

ADB100isatrademarkofGefenSystems

MacintoshisatrademarkofApple,Inc.

TABLE OF CONTENTS

GeneralInformation

Introduction ........................................................ 1

OperationNotes................................................... 2

ADB100PanelLayout ........................................... 3

ADB100FunctionDescription ................................ 4

Warranty............................................................. 9

InstallationWiringDiagrams

1KeyboardExtended............................................ 5

2KeyboardsLocal/Extended................................. 6

2KeyboardExtended............................................ 7

TSE100LinkCable ............................................... 8

ThankyouforpurchasingGefenSystems'

ADB100Series.TheADB100extendsyourcomputer

ADBport(keyboard,mouse,trackball,andtouch

screen)device upto1000feetawayfromthe

locationofyourMacintoshcomputer.

TheADB100systemconsistsoftwounits,the

ADB100Sendermodewhichresidesnexttothe

computersideandtheADB100Receivermode,which

residesnexttotheextended keyboard.

TheADBsignalcontrolsthekeyboard,mouse,

trackballandotherADBdevicessuchasatouch

screen.TheADB100bufferstheADBsignalthrough

sendandreceivelinedrivers,andthesignalis

extendedbyusingstandardtelephonecable.

YoucanconnectadditionalADB100Series tothe

samecomputer,allowingyoutoaccessthecomputer

fromotherlocationsupto 1000feetapart.

INTRODUCTION

OPERATION NOTES

READTHESENOTESBEFOREINSTALLINGOR

OPERATINGTHEADB100SYSTEM.

1. WARNING!:TheADB100weredesignedtooperate on

Macintoshcomputers.Donotattempttousethisequipment

withanyothertypecomputers.

2. WARNING!:Whenusingalocalkeyboardnotextended

withtheADB100Senderunit,usetheGefenmodifiedADB

cable.ModifiedcableisconnectedbetweentheADB100

senderandthelocalkeyboardormouse.

3. WARNING!:WhenplugginginaADB100Senderunit

ONLY,withouttheADB100receiverunit,thekeyboardand

mousewillfreeze.TheADB100Receiverunitmustbe

connected,andpoweredup,andthelinkcableinstalled

betweenbothunits,inordertooperateproperty.

4. LinkCable:Refertothewiringdiagramonpage10for

wiringinstructions.

ADB100 PANELS LAYOUT

ADB

OWERLINK

GEFENSYSTEMS

WOODLANDHILLS,CA 91367

MADE INU.S.A.

RECEIVER

SENDER

3 5

ADB

Mini din sub connector which connects to the computer

ADB port. (For keyboard, Mouse and Trackball).

Power On Light

Power on status indicates that the unit is plugged in.

Send/Receiver Switch

Push button switch for setting ADB100 as a Sender or

Receiver unit.

Link

RJ-11 Modular Jack which connects to the TSE100R

(Receiver Unit).

Power

9 Volt A/C 1A external power supply.

FUNCTION DESCRIPTION

Set switch to IN to receive

Use Power supply at this end

Set switch to OUT to send

No power supply is required at this end

1 KEYBOARD EXTENDED - WIRING DIAGRAM

Set switch to OUT to send

No power supply is required at this end Set switch to IN to receive

Use Power supply at this end

2 KEYBOARDS LOCAL/EXTENDED - WIRING DIAGRAM
