Geeetech Prusa I3 X Manual de usuario

Geeetech Prusa I3 X

GEEETECH

- 1 -

The copyright of this manual belongs to the Shenzhen GETECH

CO., LTD. (hereinafter referred to as the "Geeetech"), and all rights

reserved. No part of this specification should be reproduced or

extracted in any forms or means without the prior written consent of

Geeetech by any company and individuals.

GEEETECH

- 2 -

Technical Support

If you are interested in the technology of 3 D printing, flight

control and U-home, welcome to Geeetech, we have series of

made-up products, main boards, modules and a variety of peripherals

for you. Or if you are looking for relevant information or technical

support, please login our Forum where you can find anything you

want about open source. To know more about our new products,

please visit www.geeetech.com, we will serve you wholeheartedly.

GEEETECH

- 3 -

SAFETY INSTRUCTIONS

Building the printer will require a certain amount of physical

dexterity, common sense and a thorough understanding of what you

are doing. We have provided detailed instructions to help you

assemble it easily, please download at geeetech.com.

However ultimately we cannot be responsible for your health and

safety whilst building or operating the printer, with that in mind be

sure you are confident with what you are doing prior to commencing

with building or buying. Read the entire manual to enable you to

make an informed decision.

Building and operating involves electricity, so all necessary

precautions should be taken and adhered to, the printer runs on 12V

supplied by a certified power supply, so you shouldn’t ever have to

get involved with anything over 12V but bear in mind there can still

be high currents involved and even at 12V they shouldn’t be taken

lightly.

High temperatures are involved with 3D Printing, the Extrusion

nozzle of the hot end can run about 230°C, the heated bed runs 110°C

and the molten plastic extruded will initially be at around 200°C, so

GEEETECH

- 4 -

special care and attention should be made when handling these parts

of the printer during operation.

We wouldn’t recommend leaving your printer running unattended,

or at least until you are confident to do so. We cannot be held

responsible for any loss, damage, threat, hurt or other negligent result

from either building or using the printer.

GEEETECH

- 5 -

INTRODUCTION:

Geeetech Prusa I3 X is a new member of the prestigious Prusa I3

family, it was engineered to provide redefined usability, quality ,

performance and most important, best affordability in desktop 3D

printer market.

The Geeetech Prusa I3 X is completely made from piano-black

laser-cut acrylic frame. To maintain the garage-built feel and the

handmade charms, Geeetech Prusa I3 X is also a DIY kit, which

provides you an unforgettable step-by-step learning experience of 3D

printer from scratch.

Geeetech Prusa I3 X has a wide range of customers, young or old,

professional or amateur, as long as you have a passion for creativity,

you can not afford to miss our Prusa I3 X.

GEEETECH

- 6 -

PACKAGE LIST:

This list includes all the parts required to assemble your Geeetech

Prusa I3 X 3D Printer. After you received your package, please check

if all the parts listed are included. Also make sure all the components

are in good condition and not damaged during shipping. If anything

is missing please contact with our customer service straight away,

provide us the NO. , Name, and Qty.

Mechanical parts

Name

Specifications

Qty

Pic

Smooth

Rod

D8*L322mm

Smooth

Rod

D8*L430mm

Smooth

Rod

D8*L420mm

Threaded

Rod

M8*L300mm

Z-axis

Threaded

Rod

M10*L450mm

Y-axis

M2.5

Washers

M2.5

Washers

139

GEEETECH

- 7 -

Washers

M10

Washers

M10

Spring

washer

M10

Hex Nut

M2.5

Hex Nut

M10

Lock nut

GEEETECH

- 8 -

Wing nut

Square nut

Z-axis nut

M8（tin-bronze）

Hex

Counter-

sunk-head

screw

M3x16 mm

Hex

Counter-

sunk-head

screw

M3x30 mm

Screw

M2.5x16mm

Screw

M3x8mm

Screw

M3x12mm

Screw

M3x16mm

Screw

M3x20mm

Screw

M3x25mm

Screw

M3x30mm

GEEETECH

- 9 -

Screw

M3x35mm

Screw

M3x50mm

Screw

M4x12mm

Screw

M4x16mm

Screw

M4x25mm

locking

ring

M8 + M5x6mm

screw

Spring

4 x 20（for heat

bed）

Spring

3.5 x 30(for Z

endstop)

Ball

Bearing

MR84zz

（Placed in

No.37）

Linear

Bearing

PCS8UU
