Dancover Multipavillon 6x6m Manual de usuario

18-02-2016

Manual

for

Marquee

Multipavillon

6x6m

Each package must contain

No.

1

No.

2

No.

3

No.

4

No.

5

No.

6

No.

7

No.

8

No.

9

No.

10

No.

11

No.

12

12

pcs.

16

pcs.

8

pcs.

12

pcs.

16

pcs.

20

pcs.

1

pcs.

12

pcs.

8

pcs.

4

pcs.

4

pcs.

4

pcs.

It is easy to assemble

your marquee

Multipavillon

ASSEMBLY INSTRUCTION

Each marquee consists of

No. 1 Base

No. 2 Entrance tube

No. 3 Small horizontal tube

No. 4 Small corner tube

No. 5 Cross tting

No. 6 Small top tube

No. 7 Top tting

No. 8 Ground pegs

No. 9 Large top tube

No. 10 Large corner tube

No. 11 Small curved tube

No. 12 Large horizontal tube

Place the 12 corner bases (1) as shown on

drawing so they form a frame measuring 6x6 m.

If the marquee is mounted outside use ground

pegs (8) inserted into the ground with a hammer.

If the marquee is mounted on a concrete or

wooden oor, the corner base can be fastened

with concrete nails or screws.

Fasten only one corner until the entire frame has

been assembled in order to ensure that the other

corner bases are placed correctly within the

square.

4

22

1

4

2

3 5

1

8

Place the longest tubes (2) in the 2 outermost

holes in each corner base and the shorter tube (4)

in the middle hole.

Mount the tubes so the snap-and-click features

points upwards.

Mount the tubes (2) in (3) for a complete arch.

Mount the connector (5) with the middle tube

(4). Mount the horizontal tubes (3) with the

connectors (5) to make a ring.

Assemble and mount the top section consisting

of (9) and (7).

Now you can fasten the remaining corner bases

if necessary.

Finally, mount to cover onto the frame. Fasten

the 4 straps at the ends of the cover to the 4

corner bases.
