Dancover 2m Series Manual de usuario
PARTY TENT SEMI PRO
6m series
13-08-2014-SH
Safety Advice
Attention
In some countries approval is needed to set up a marquee/tent larger than 75 m2. It is
your responsibility to comply with local rules and regulations and to ensure that the
marquee/tent is assembled correctly.
In case of bad weather conditions, it is your responsibility to ensure the marquee/tent is
safely secured and that the marquee/tent does not cause damage to others.
close to the tent.
The marquee/tent must be safely secured. We recommend you secure your marquee/tent
with straps and pegs as soon as it is assembled.
Make sure to check if the marquee/tent is covered by your home contents
insurance.
Marquees/tents must be evacuated under extreme weather conditions.
In the event of snow always remove snow from the roof of the marquee/tent regularly to
prevent snow from building on the roof as heavy snow can cause the marquee/tent to
collapse.
In the event of rain there is a risk of rain puddles building up on top of the roof of the
marquee/tent. Heavy rain puddles can cause the roof to collapse. It is your responsibility
to ensure rain puddles do not build up. As a precaution, make sure the roof of the
marquee/tent is stretched out properly and adequately over the side frames of the
marquee/tent and remove rain water regularly.
Do not unpack or repack your marquee/tent in freezing temperatures. In case of
temperatures below zero always unpack and repack your marquee/tent indoors to avoid
the risk of cracking parts.
The marquee/tent must be totally dry before you repack and store it to avoid mildew.
Warranty Information
Please visit dancovershop.com for information on warranty.
Note: Marquees are intended for events and other arrangements and are as such only
meant for short term temporary assembly and the following disassembly. Dancover
warranty applies only to the normal use of the Product, normal wear and tear excepted,
in accordance with written use instructions or manual. The warranty does not apply to
Please always check our website for the latest safety advice and manuall.
6m -2.3 PARTY TENT SEMI PRO
x66x6Part No.noisnemiD 8 6x10 6x12 6x14
Pipe 50-50 1 16 20 24 28 32
Pipe 38-38 2 23 30 37 44 51
Pipe 38-38 with hole 3-1
22222
3-2 2 2 2 2 2
Pipe
roof brace
6-series horizental 4 8 10 12 14 16
Pipe
roof brace
6-series horizental 5 4 5 6 7 8
Pipe
25-25 diagonal pipe 6 4 4 4 4 4
Pipe
50-50 with holes 7 4 6 8 10 12
Pipe
50-50 with holes and a hole 8 4 4 4 4 4
connector Three way
110 °54-42 10 4 4 4 4 4
13-08-2014-SH
connector Three way
140 °54-42 11 2 2 2 2 2
connector four way
140 °54-42 12 2 3 4 5 6
connector four way
110 °54-42 13 4 6 8 10 12
Cross piece 54-42 14 4 6 8 10 12
T-piece 54-42 15 4 4 4 4 4
Connector three way –foot for the
corners 54-42 16 2 2 2 2 2
6m -2.3 PARTY TENT SEMI PRO
13-08-2014-SH
x66x6Part No.noisnemiD 8 6x10 6x12 6x14
Connector three way –foot for the
corners 54-42 17 2 2 2 2 2
Connector three way –foot for the
sidewalls 54-42 18 4 6 8 10 12
Connector three way –foot for the
endwalls 54-42 19
20
21
22
4 4 4 4 4
Groundpegs 4 6 8 10 10
Screw hook 4 4 4 4 4
Groundpeg 6x180mm 8 10 12 14 16
6m -2.3 PARTY TENT SEMI PRO
13-08-2014-SH
x66x6Part No.noisnemiD 8 6x10 6x12 6x14
Screw M8X50mm 5824
25
26
72 86 100 114
Screw M8X60mm 52 64
76 88
100
Locknuts M8 110 136
162 188 214
Screw M6X25mm
29
Wing nut M6 16 20
24 28 32
30
16 20 24 28 32
6m -2.3 PARTY TENT SEMI PRO
13-08-2014-SH
23
Groundpeg 4x180mm 36 42 48 54 60
x66x6Part No.noisnemiD 8 6x10 6x12 6x14
spanner
231
33
34
35
37
2 2 2 2
Long bungeeball 112 132 152 172 192
Short bungeeball 26 26 26 26 26
rope 4 4 4 4 4
roof
1
1
1
1
1
6m -2.3 PARTY TENT SEMI PRO
x66x6Part No.noisnemiD 8 6x10 6x12 6x14
sidewall 638 8 10 12 14
13-08-2014-SH
39
endwall with large door 1 1 1 1 1
40
endwall with small door 1 1 1 1 1
6m -2.3 PARTY TENT SEMI PRO
x66x6Part No.noisnemiD 8 6x10 6x12 6x14
13-08-2014-SH
6m -2.3 PARTY TENT SEMI PRO
I
Select a flat surface for the
tent.Unpack the boxes and check if
all listed parts are included .Assemble
the roof frame by mounting parts10-15
on the pipes (Parts 1,2,and 3)Use the
screws to firemly attach the parts
II
Attach the reinforcement braces
(part4 and 5)using screws (30) and
wing nuts (29)
15
15
3-1 3-2
3-2 3-1
10
10
6m -2.3 PARTY TENT SEMI PRO
III
Lift one side of the tent frame and
attach the legs(7).Attach the legs with
part no. 8 to the outside in all four
corners. Place the roof onto the frame
and use the bungees to fasten it .Be
sure not to put too much tension on
the bungees in order not to make
attaching the other side more difficult.
IV
Attach the legs on the other side and
install the feet(16,17,18,19)at the
bottom.Use the long ground pegs to
fasten the feet to the ground.Attached
the side covers to the pipes(7,8)
Reinforce the side frame
by
attaching the diagonmal pipes(6)
to all four corners .Complete
the bottom frame with the required
pipes(2) and connectors(16,17,18,19).
33
2
2
50
