AC1200 MU-MIMO WIRELESS

VDSL/ADSL2+ MODEM ROUTER

DSL-3785

QUICK

INSTALLATION

GUIDE

DSL-3785 1

IMPORTANT

INFORMATION

IMPORTANT INFORMATION REGARDING YOUR

INTERNET SUBSCRIPTION

USERS WHO SUBSCRIBE TO LIMITED OR “PAY AS YOU USE” BROADBAND INTERNET

ACCESS.

In the WAN conguration settings, there is a parameter called Maximum idle timer. This parameter controls how

many seconds of inactivity before dropping connection to the Internet. The default setting is “0” which disables this

functionality and the Internet will be connected all the time. We suggest that you should change the Maximum idle

timer to “300” (5 minutes) so that the device will drop the line after 5 minutes of inactivity and keep usage costs down.

USERS WHO SUBSCRIBE TO UNLIMITED BROADBAND INTERNET ACCESS.

You can just leave this parameter unchanged or enable Auto-reconnect to be always online.

TECHNICAL NOTES:

The Maximum idle timer is only relevant if your ISP is using PPPoE connection.

DSL-3785

ENGLISH

CONTENTS OF

PACKAGING

CONTENTS

POWER ADAPTER

12 V 1.5 A

ETHERNET CABLE

CONNECT THE ROUTER TO YOUR PC DURING SET-UP

If any of these items are missing from your packaging contact

your reseller

RJ-11 PHONE CABLE

CONNECT THE ROUTER TO YOUR WALL PHONE JACK

AC1200 MU-MIMO WIRELESS VDSL/ADSL2+

MODEM ROUTER

DSL-3785

DSL-3785 3

ENGLISH

PRODUCT SETUP

Step 1

Position your DSL-3785 near your PC and a telephone wall jack

which provides DSL service. Keep the modem router in an open

area for better wireless coverage.

DSL-3785 Phone

Step 2

Plug one end of the supplied DSL phone cable into the DSL port on

the back of the modem router, and the other end into the telephone

wall jack.

DSL-3785 Phone

HARDWARE SETUP

Step 3

Connect the supplied power adapter to the modem router and a

power outlet, and press the power button. The device LEDs will light

up. Wait approximately one minute before going on to step 4.

DSL-3785Power

Step 4

Plug one end of the supplied Ethernet cable into the port labeled

1 on the back of the modem router, and the other end into the

Ethernet port on your computer.

If you are setting up the DSL-3785 using a laptop or mobile

device, connect it using the Wi-Fi network name and password

printed on the label attached to the back your router.

DSL-3785Power

SYSTEM REQUIREMENTS

• ADSL/VDSL Internet service

• Computer with:

• Microsoft Windows® 10/8/7/Vista/XP SP3 or Mac with OS X 10.7 or higher

• Internet Explorer 8, Edge 25, Firefox 20, Safari 4, or Chrome 17 or higher version with Java

installed and enabled

DSL-3785

ENGLISH

To configure your DSL-3785, open a browser on the connected

computer. Go to "192.168.1.1" or "http://dlinkrouter.local./" and follow

the onscreen instructions. If prompted, log in using the username

and password printed on the label attached to the back your router.

Admin Password:

CONFIGURE USING THE BUILT-IN WEB INTERFACE

SETUP USING THE BUILT-IN WEB INTERFACE

1. HOW DO I RESET MY DSL-3785 ROUTER TO THE FACTORY DEFAULT

SETTINGS?

- Ensure the router is powered on.

- Use an unfolded paperclip to press and hold the reset button on the back of the device for more

than 5 seconds until all the front LEDs turn on. The router will reset to the factory defaults and

begin rebooting.

Note: Resetting the router to the factory defaults will erase the current conguration settings.

To recongure your settings, log in to the router as outlined in question 1, then run the Setup Wizard.

2. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY

WI-FI NAME (SSID) OR WI-FI PASSWORD?

- Use the web-based user interface (as described in question 1 above) to check or choose your

wireless settings.

- Make sure you write down these settings so that you can enter them for each wirelessly

connected PC. The back of this document features an area to record this important information.

- If your device supports WPS, you may press the WPS button on the side of the router for

approximately 5 seconds to begin the WPS pairing process. Refer to your wireless device's

documentation for information on how to pair a device to your DSL-3785 using WPS.

3. WHY CAN'T I GET AN INTERNET CONNECTION USING DSL?

- If you are replacing a DSL modem or combination DSL modem router, make sure to completely

disconnect and power o󰀨 your existing equipment. Connect your DSL-3785 to the wall jack

which worked with your previous DSL modem.

- Verify that the BROADBAND LED is lit solid green. If it isn't, please contact your ISP to make

sure the service has been enabled/connected by your ISP.

- If the BROADBAND LED is lit solid green, but the INTERNET LED is lit solid red or o󰀨, or you

are having trouble with the Setup Wizard, make sure that the username and password provided

by your ISP are correct.

- If you are still having trouble, you may need to contact your ISP for additional Bring Your Own

Device (BYOD) conguration steps. Refer to the product manual, available at www.dlink.com/

support for additional conguration help.

TROUBLESHOOTING

CONFIGURATION

TECHNICAL SUPPORT dlink.com/support

Ver. 1.00(AU)_130x183 2017/12/04 610000008329
