PLANET ENW-3503 User's Manual

ENW-3503

Ethernet + Fax/Modem

Multifunction PC Card

User’s Manual

FCC REGULATORY STATEMENTS

FCC Certification

Ethernet + 56K Fax/Modem PC Card FCC ID: MQ4LM560T

The United States Federal Communication Commission (FCC) and the Canadian

Department of Communications have established certain rules governing the use

of modems and other electronic equipment.

FCC Part 68 Registration

This high speed Ethernet + FAX/MODEM PC Card complies with FCC Part 68

rules, and the use of this modem is subject to the following restrictions:

1. The FCC has established rules which permit this device to be directly connected

to the telephone network. Standardized jacks are used for these connections.

This equipment should not be used on party lines or coin phones.

2. If this device is malfunctioning, it may also be causing harm to the telephone

network; this device should be disconnected until the source of the problem can

be determined and until repair has been made. If this is not done, the telephone

company may temporarily disconnect service.

3. The telephone company may make changes in it's facilities, equipment,

operation and procedures; if such changes affect the compatibility or use of this

device, the telephone company is required to give adequate notice of the

situation with the FCC.

4. If the telephone company requests information on what equipment is

connected to their lines, inform them of:

a. The telephone number to which this unit is connected.

b. The Ringer Equivalence Number (REN).

c. The USOC jack required.

d. The FCC Registration number.

Items (b) and (d) are indicated on the label. The Ringer Equivalence Number

(REN) is used to determine how many devices can be connected to your telephone

line. In most areas, the sum of the REN's of all the devices on any one line should

not exceed 5.0. If too many devices are attached, they may not ring properly.

FCC Part 15 Registration

This device complies with Part 15 of FCC rules. Operation is subject to the

following two conditions:

1) This device may not cause harmful interface, and

2) This device must accept any interface received, including interface that may

cause undesired operation.

III

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy, and if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

(1) Reorient or relocate the receiving antenna.

(a) Increase the distance between the equipment and

receiver

(b) Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

(2) Consult an experienced radio/TV technician for help.

Trademarks

Contents subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. The

information in this manual is subject to change without notice. All other

trademarks belong to their respective owners.

Revision

This user's manual is for PLANET PCMCIA LAN + FAX/MODEM PC

Card model -- ENW-3503

Rev: 1.00 (May, 1998)

Part No: EM3503

TABLE OF CONTENTS

1. INTRODUCTION........................................................1-1

1.1. ABOUT THIS MANUAL........................................1-1

1.2. ABOUT ENW-3503................................................1-1

1.2.1. Specifications.................................................1-2

1.2.2. Features.........................................................1-2

1.3. SYSTEM REQUIREMENTS ..................................1-3

1.4. PACKAGE CONTENTS.........................................1-3

2. INSTALLATION.........................................................2-1

2.1. HARDWARE INSTALLATION ............................2-1

2.2. INSTALLING THE SOFTWARE ...........................2-2

2.2.1. Novell Netware Installation............................2-3

2.2.2. MS LAN Manager Installation........................2-4

2.2.3. Packet Driver Installation..............................2-5

2.2.4. Windows for Workgroups 3.11 Installation.....2-6

2.2.5. Windows NT 3.51 & NT 4.0 Installation .........2-7

2.2.6. Windows 95 Installation...............................2-12

2.2.7. Artisoft Lantastic 6.0 Installation.................2-13

3. MODEM BASICS........................................................3-1

4. DRIVERS INFORMATION........................................4-1

4.1. NOTES FOR NDIS DRIVER.........................................4-1

4.2. NOTES FOR PACKET DRIVER......................................4-2

4.3. NOTES FOR WINDOWS FOR WORKGROUPS .................4-2

5. Q & A ...........................................................................5-1

6. APPENDIX A: NDIS2 AND ODI DRIVERS FOR WFW

3.11................................................................................6-1

7. APPENDIX B: UNINSTALLATION THE

ETHERNET + FAXMODEM IN WIN 95...................7-1

8. APPENDIX C: FAX/MODEM AT COMMAND........8-1

8.1. BASIC AT COMMAND SET.........................................8-1

8.2. EXTENDED "AT&" (AMPERSAND) COMMAND SET.....8-4

8.3. EXTENDED "AT" (BACK SLASH) COMMAND SET .......8-6

8.4. EXTENDED "AT%" (PERCENT) COMMAND SET..........8-7

8.5. EXTENDED "AT-" (DASH) COMMAND SET.................8-8

8.6. RESULT CODE OPTIONS ............................................8-8

8.7. EXTENDED RESULT CODE OPTIONS TABLE ..............8-10

8.8. S-REGISTERS, "ATSN=X".......................................8-12

PLANET ENW-3503 User's Manual

1. INTRODUCTION

1.1. ABOUT THIS MANUAL

This manual will explain how to install and use your

multifunction Ethernet + Fax/Modem PC Card -- ENW-3503.

1.2. ABOUT ENW-3503

The PC Card -- ENW-3503 is a multifunction communication

device that lets you perform multiple communication tasks at

the same time:

(1) transmit and receive data up to 56,000 bps

(2) send and receive FAXes from computers or

FAX machines

(3) connect to an Ethernet 10Base-T LAN

And it uses only one PCMCIA socket while it can provide the

functions listed above.

This PC Card is a credit-card-size Type II PCMCIA adapter

that complies with the PCMCIA 2.1 and JEIDA 4.1 standards

and works with computers that incorporate a compatible

interface.

It is Bell, ITU-T (formerly CCITT) and Hayes AT commands

compatible, allowing it to be used worldwide with today's

popular communication software programs. You will be able

to send and receive faxes with any Group 3 fax machine.

Using standard phone lines and 10Base-T Ethernet, the data

communication functions of the ENW-3503 PC Card will

1INTRODUCTION

LAN + Fax/Modem PC Card

1-2

enable you to successfully access to the servers on Ethernet

LAN and hook up to the Internet, transmit E-Mail, send and

receive information and communicate with other PCs, Bulletin

Board Services (BBS) or on-line computer networks such as

CompuServe and America On line.

1.2.1. Specifications

PC Card Interface

: PCMCIA Type II

Dimension : 3.37”X 2.128”X 0.197”(85.6 mm X

54 mm X 5 mm)

Weight : 35 g

Power : +5V ±5%

Cable and

Connector : Single 15-pin detachable connector to

PC Card combines two UTP cables

terminated with a RJ-11 6-pin plug for

Fax/Modem and a RJ-45 8-pin plug for

Ethernet LAN connections

Network : IEEE 802.3 10Base-T, 10Mbps.

NE2000 compatible

Modem : K56flex 56Kbps, V.34+ 33.6Kbps, V.34

28.8Kbps, V.32bis 14.4Kbps.

V.42bis/V.42, MNP 2-5 data

compression and error correction.

AT command set

Fax : Group 3, V.17 14400bps, V.29

9600bps

Fax Service Class 1 compliant

Modem COM Port

: COM2, COM3, COM4

IRQ : 3, 4, 5, 7, 9, 10, 11, 12, 15

I/O Address : 300, 320, 340, 360

1INTRODUCTION

PLANET ENW-3503 User's Manual 1-3

1.2.2. Features

1. Compatible with most notebook computers and

PCMCIA Card and Socket Service drivers.

2. High degree of reliability letting you out of

trouble.

3. Easy to install and play.

4. Support most of the popular Network Operating

Systems.

5. Include popular Fax/Modem communication

programs.

6. Hot swappable.

7. Feature concurrent use of Ethernet LAN and

Fax/Modem.

8. NE2000 compatible.

1.3. SYSTEM REQUIREMENTS

•An IBM compatible PC or notebook computer with

386SX or faster processor

•At least one type II PCMCIA socket

•PCMCIA release 2.1 compliant Card Services and

Socket Services

•Drivers and utilities provided with this product

•RJ11 jack for connecting to a phone receptacle

•RJ45 jack for 10Base-T connectivity to your

network resources

•Driver software loaded on your PC

•Data and/or fax communications software.

1.4. PACKAGE CONTENTS

•Multifunction ENW-3503 PC Card

•PCMCIA cable with RJ-11 and RJ-45 plugs

1INTRODUCTION

LAN + Fax/Modem PC Card

1-4

•A 3-1/2”driver diskette

•User’s Manual

•Windows-based fax/modem application program

•RJ-45 extension connector for LAN

•RJ-11 extension connector for Fax/Modem
