D-Link DSL-504T Manual de usuario

ADSL2/2+ MODEM ROUTER

DSL-504T

QUICK

INSTALLATION

GUIDE

DSL-504T

ENGLISH

CONTENTS OF

PACKAGING

CONTENTS

INSTALLATION CD

INCLUDES SET-UP WIZARD & TECHNICAL MANUALS

ADSL2/2+ MODEM ROUTER

DSL-504T

12V 1.25A POWER ADAPTER

ADAPTER

ETHERNET CABLE (RJ-45 CABLE)

CONNECT THE ROUTER TO YOUR PC DURING SET-UP

If any of these items are missing from your packaging contact

your reseller

DSL-504T 3

ENGLISH

PRODUCT

SET-UP

CD SET-UP WIZARD

English

SET-UP WIZARD CD

The CD contains all of the instructions required to set-up DSL-

504T

INSERT CD

Insert the CD into the CD drive of your computer. The set-up

wizard should start automatically. Make sure that your internet

connection is active. (Do not plug in DSL-504T yet)

SET-UP WIZARD

Select your language from the list of options and follow the

steps within the wizard to complete the set-up of DSL-504T

ADVANCED SET-UP (ACCESS VIA IP ADDRESS)

To congure DSL-504T manually (without the set-up CD) connect your computer to the DSL-

504T using the ethernet cable provided. Then connect the power cable on the DSL-504T. The

power light will display as solid green.

Then simply open a browser window and enter the IP address in the browser address eld:

IP ADDRESS: http://10.1.1.1

USERNAME: admin

PASSWORD: admin

DSL-504T

ENGLISH

TROUBLESHOOTING

SET-UP AND CONFIGURATION PROBLEMS

1. HOW DO I CONFIGURE MY DSL-504T ROUTER WITHOUT THE CD?

- Connect your PC to the router using an Ethernet cable.

- Open a web browser and enter the address http://10.1.1.1

- The default username is admin. The default password is admin.

- If you have changed the password and can not remember it, you will need to reset the router to

set the password back to admin.

2. HOW DO I RESET MY DSL-504T ROUTER TO FACTORY DEFAULT SETTINGS?

- Ensure the router is powered on.

- Press and hold the reset button on the rear of the device for 10 seconds.

Note: Resetting the router to factory default will erase the current conguration settings. To re-

congure your settings, log into the router as outlined in question 1, then run the Setup Wizard.

3. WHY CAN I NOT GET AN INTERNET CONNECTION?

For ADSL users please contact your ISP to make sure the service has been enabled/connected

by your ISP and that your ISP username and password is correct.

TECHNICAL SUPPORT

Australia:

Tel: 1300-766-868

24/7(24Hrs, 7days a week) technical support

http://www.dlink.com.au

e-mail: [email protected]

New Zealand:

Tel: 0800-900-900

24/7(24Hrs, 7days a week) technical support

http://www.dlink.co.nz

e-mail: [email protected]

DSL-504T 5

NOTES

DSL-504T

NOTES

DSL-504T 7

NOTES

Ver. 2.00(AU) 2009/05/15

WIRELESS NETWORK REMINDER

Wireless Network Name (SSID)

Wireless Network Password
