CYP CMSI-48E Manual de usuario
CMSI-48E
4 by 8 Matrix
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2013 by Cypress Technology.
All Rights Reserved.
Version 1.0 December 2013
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 08/04/14 Preliminary Release
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 2
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Side Panel .........................................5
6.4 Remote Control................................6
6.5 IR Pin Assignment .............................6
6.6 RS-232 Protocols ...............................7
6.7 RS-232 & Telnet Commands............7
6.8 Telnet Control .................................10
6.9 WebGUI Control .............................12
7. Connection Diagram .......................... 14
8. Specications ...................................... 15
8.1 CAT5e/6/7 Cable Specication ...15
8.2 Input Timing Support Chart ...........16
9. Acronyms ............................................. 18
1
1. INTRODUCTION
The 4 by 8 Matrix allows HDMI signal from any of its four sources to be
routed to any of its eight outputs simultaneously. With a thoughtful
design for local and remote connections both required in system
integration, the model is engineered with 4 HDMI and 4 CAT5e/6/7
outputs, the later ones carry major HDBaseT features including the
transmission of high denition audio and video, bidirectional IR, RS-232
and PoC (Power over Cable) over 100 meters. The remote control, RS-
232, Telnet and IP Control, with all information including system status
presented on its LCM display.
2. APPLICATIONS
• HDMI system controls
• Video/TV wall display and control
• Security surveillance and control
• Commercial advertising, displaying and control
• Lecture room display and control
• Hyper market demonstration and control
3. PACKAGE CONTENTS
• 1 x 4 by 8 Matrix
• HDMI over CAT5e/6/7 Receivers (Optional)
• 1 x IR Extender
• 1 x IR Blaster
• 1 x 24V/3.75A DC Power Supply
• 1 x Power Cable
• 1 x Remote Control with Battery
• 1 x L&R Rack Ear with Screws
• 1 x Operation Manual
2
4. SYSTEM REQUIREMENTS
• Input source equipment with HDMI connection cables
• Industry CAT5e/6/7 cable
• HDMI over CAT5e/6/7 Receivers with industrial CAT5e/6/7 cables
• Output displays or audio receiver equipments with HDMI
connection cables
5. FEATURES
• Supports resolutions VGA to WUXGA and 480i to 1080p dependent
upon the output display’s EDID settings
• Supports distances up to 100m for CAT5e/6/7 cables
• Supports 3D signal display dependent upon the output display’s
EDID settings
• Supports bidirectional IR from input and output locations
• Supports external and internal EDID settings
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio Transmission
• Supports PoC (Power over Cable) on compatible Receiver Supports
Ethernet function
3
6. OPERATION CONTROLS AND FUNCTIONS
The following sections describe the hardware components of the unit.
6.1 Front Panel
CMSI-48E
4X8 HDMI MATRIX
POWER LOCK MENU OUT
C3
B2
A1D4
IN
HGFE
1 2 3 4 5 6
1LCM: This monitor displays your setting information with each input
and output selection.
2IR: This IR window accepts the remote control signal of this device
only.
3Power Button & LED: Press this button to turn ON the device and
the green LED will illuminate when the power is ON. When the LED
illuminate in red it is in standby mode.
4LCOK: Press this button to lock all the buttons on the panel and the
LED will illuminate. To unlock, just press it again.
5Menu: Press this button once to select EDID setting from
STD(internal) 1 or TV(external) 2 then press it again to conrm the
selection. Press this button every time to conrm the selection.
61~4/A~H & OUT/IN button: Press OUT/IN button rst to select the
output/input then press the number button to make the selection
accordingly. For example, output A~B wish to select input 1 and
C~E wish to select input 2. Press OUT →A→B→IN →1→Menu,
and then press OUT →C→D→E→IN →2→Menu. If the menu
button is not pressed the selection will not be changed.
4
6.2 Rear Panel
SERVICE
RS232
IP &
ETHERNET
B DA F HE
DC 24V
1
2
3
4
GND
GND GND
IR OUT
IR IN
ALL
V+
V+
1
IR IN IR OUT
2
IR IN IR OUT
3
IR IN IR OUT
4
IR IN IR OUT
HDMI IN 1 HDMI IN 2 HDMI IN 3 HDMI IN 4
HDMI OUT CAT5e/6/7 OUT CAT5e/6/7 OUT
HDMI OUT CAT5e/6/7 OUT CAT5e/6/7 OUT
G
HDMI OUT
C
HDMI OUT
2 3 4 4 45 5 5 10 115 6
1
7
8
7
8
7
8
7
8 9
1RS-232: This slot is to connect with D-Sub 9pin cable from the PC/
Laptop device for RS-232 control.
Note: This RS-232 obtain routable function that is, from the Matrix it
can send commands to all Receivers or from Receiver sides it can
also send commands to control the Matrix. In order to allow the
Receivers to send command to control the Matrix, a null modern
cable/adaptor is required.
2IP & Ethernet: This port is for Telnet and WebGUI control. Connect
and active network system with RJ45 terminated cable (for details,
please refers to RS-232 & Telnet commands and WebGUI Control
sections). Also, it allows Ethernet access when connecting to an
active network source or when any of the CAT outputs has the
Ethernet link.
3Service: This slot is to connect with mini USB B type cable for
rmware update only.
4HDMI OUT A/C/E/G: These slots are to connect with HD TV/display
for instant display.
5CAT5e/6/7 OUT B/D/F/H: These slots are to connect with HDMI over
CAT5e/6/7 Receiver for signal extension up to 100m.
6HDMI IN 1~4: These slots are to connect to input source equipment
such as DVD player or Set-Top-Box with HDMI cable or DVI to HDMI
converter cable for input signal sending.
7IR IN 1~4: These slots are to connect with IR Extender included in
the package for IR signal reception. Ensure that remote being
used is within the direct line-of-sight of the IR Extender.
8IR OUT 1~4: These slots are to connect with IR Blaster included in
the package for IR signal transmisstion. Place the IR Blaster in direct
line-of-sight of the equipment to be controlled.
5
9ALL IR OUT: Connect to the IR Blaster for IR signal transmission to
the source side. Place the IR Blaster in direct line-of-sight of the
equipment to be controlled for it will blaster out all signal received
from the IR IN at the Receiver sides.
10 ALL IR IN: Connect to the IR Extender for IR signal reception. Ensure
that remote being used is within the direct line-of-sight of the IR
Extender for it will send out the signal to all Receiver's IR OUT.
11 DC24V: This slot is to plug the power cord with adaptor included
in the package and then connect them with AC wall outlet for
power supply.
6.3 Side Panel
1
1Ventilator: These are fan ventilator area, DO NOT block these area
or cover it with any object.
