OPERATION MANUAL

QU-12S

v1.3 HDMI Distribution

Amplier

1. Introduction 1

2. Features 1

3. Package Contents 1

4. Operation Controls and Functions 2

4.1 Front Panel Diagram 2

4.2 Rear Panel Diagram 3

5. Connection Diagram 4

6. Specications 4

Table of Contents

Finden Sie ab Seite 7.

1. Introduction

QU-12S HDMI distribution amplier is an advanced solution within the

Quantum Range of HDMI Distribution Ampliers. Each product in The Quantum

Range is compatible to v1.3 HDMI specications, a cutting edge technology

which denes the support of the transfer of Deep Colour (10-bit and 12-bit)

video and new lossless compressed (LPCM 7.1CH, Dolby TrueHD, Dolby Digital

Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to

225MHz (6.75Gbps). Besides splitting and distributing, the QU-12S also boasts

signal amplication and equalization to provide high performance I/O of audio

and video.

2. Features

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant.

• Supports ‘Deep Colour’ (10, 12, and 16 bit).

• One HDMI source to connect up to two HDMI displays simultaneously.

• HDCP keysets allows each output to work independently when connecting to

a HDMI display.

• Supports DVI source and DVI display by using HDMI to/from DVI adaptor cable.

• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master

Audio transmissions (32-192kHz Fs sample rate).

• Supports a wide range of PC and HDTV resolutions from VGA to UXGA and 480i

to 1080p.

• Supports EDID functionality.

Note: The detection priority is v1.3 HDMI > v1.2 HDMI > DVI On output1

• Supports CEC bypass.

3. Package Contents

• QU-12S

• 5V DC power supply adaptor.

• Operation Manual.

Page 1

Page 2

4. Operation Controls and Functions

4.1 Front Panel

1. HDMI output 1 to 2: Connect each of the output ports to an HDMI enabled

display. When more than one output is connected both screens display the

HDMI signal simultaniously.

1

HDMI OUTPUT 1 HDMI OUTPUT 2

Page 3

4.2 Rear Panel

1. HDMI Input: Connect input port to the HDMI or DVI output of your source

equipment such as DVD player or set-top-box.

2. POWER Indicator: The power LED will illuminate when power is on.

3. Power: Plug the 5V DC power supply into the QU-12S and connect the adaptor

to AC wall outlet.

1 2 3

HDMI INPUT

POWER

DC 5V

5. Connection Diagram

Input Port 1 x HDMI

HDCP Version V1.1

Output Port 2 X HDMI

HDMI Specication V1.3

Frequency bandwidth 2.25Gbps (single link)

Power Supply 5VDC/2.6A (US/EU standards, CE/FCC/UL Certied)

Dimensions 100(W) x 147(D) x 25(H)

Weight (g) 300g

Chassis Colour Black

Chassis Material Aliminium

Operating Temperature Operating from 0°C ~ 48°C

6. Specications

Page 4

Notes:

Page 5

www.cypeurope.com

Page 6

Bedienungsanleitung

QU-12S

V1.3 HDMI Verteiler und

Verstärker

Page 7

1. Einleitung 9

2. Funktionen 9

3. Lieferumfang 9

4. Bedienelemente und Anschlüsse 10

4.1 Darstellung der Frontansicht 10

4.2 Darstellung der Rückseite 11

5. Anschlussschema 12

6. Spezikationen 12

Inhaltsverzeichnis

Page 8
