Creality HALOT-ONE PRO Manual de usuario

3D Printer User Manual

V1.0

HALOT-ONE PRO

Create reality，achieve dreams

HALOT-ONE PRO

Dear Consumers,

Thank you for choosing our products.For the best experience,please read the instructions before operating the Printer. Our

teams are always ready to render you the best services. Please contact us via the phone number or e-mail address provided

at the end when you encounter any problem with the Printer.

For a better experience in using our product, you can also access how to use the printer in the following ways:

View the accompanied instructions and videos in the U disk.

Visit our oﬃcial website www.creality.com to ﬁnd relevant software/hardware information,contact details and operation and

maintenance instructions.

Firmware/Software Downloads and Upgrades

The product has access to both LycheeSlicer and CHITUBOX. WIFI printing and access to the Creative Cloud are under development.

Download the ﬁrmware and HALOT BOX slicing software at: https://www.creality.com

Download the CHITUBOX slicing software at: https://www.chitubox.com

Download the LycheeSlicer slicing software at: https://lychee.mango3d.io

Slicing software supported：

NOTES

Do not use the printer any way other than described to avoid personal injury or property damage.

Do not place the printer near any heat source or ﬂammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment.

Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.

Please use recommended resin in case damage to machine.

Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet.

Please do not open the plastic cover during usage, otherwise the printing will be interrupted.

Do not wear cotton gloves when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage.

Please wait after the print is ﬁnished. please wear gloves to take out the print tools.

Children under 10 years should not use the printer without supervision.

Tips Do not plug or unplug the power cord when power on.

Clean the printer frequently. Always turn the power oﬀ when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material oﬀ the frame,

guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface.

Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety

obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any.

Contents

Equipment Introduction 01-01

Equipment Parameters 02-02

Parts List 03-03

04-04

10-15

05-09

16-16

17-17

Assemble the 3D Printer

Use the 3D Printer

Troubleshooting

Print Method

Wiring Connection

18-18

FCC Statement

19-19

IC Cautiont

1. Equipment Introduction

Hexalobular socket screw

Leveling screw

Platform plate

Resin vat

Air ﬁlter

Power receptacle

Power switch

USB port

Touch screen

Limit sensor

Tray ﬁxing screw

Model Name HALOT-ONE PRO

130*122*160mm (length*width * height)

2560*2400

0.051mm

1-4S/ layer

0.01-0.2mm

236*245*416mm

310*300*530mm

8.4KG

USB Disk，Creality Cloud App, Creality Cloud Online, WiFi Print

中文(简/繁)/ English/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk/Nederlands/Polskie/日本語/한국어

Win7/Win8/Win 10 64bit, Mac system(32-bit is not supported)

Common rigid photosensitive ,Standard resin ,High hardness ,High toughness ,Dental model resin

Integral Light Source(wavelength 405nm)

100-240V~,50/60Hz

100WRated Power

Machine Size

Package Size

Net Weight

Compatible Resin

Machine Language

Gross Weight

Print Method

Slicing Software Operation System

Build Size

XY Axis Resolution

Touch Screen

Light Source Type

Rated Voltage

XY Axis Accuracy

Print Speed

Layer Thickness

Basic Parameters

5 inch touch screen

6.9KG

2. Equipment parameters

3. Parts Content List

Print platform x 1 Resin vat x 1 3D printer x 1

Tips: the above accessories are for reference only, please refer to the physical accessories!

Tool list

U disk x 1 Paper funnel x 2

power cable x 1

Release ﬁlm x 1

Metal blade x 1

Screwdrivers x 1set

678

5Plastic blade x 1

Calibration card x 1

4. Assemble the 3D Printer

Machine body x 1

Plastic cover x 1

Note: put the plastic cover on the machine body and the installation is completed.

6. Interface Information

Note: Check whether the light source is normal The UI interfaceis only for reference , the actual UI.

Settings

7. Leveling Platform

Note: The platform has been leveled at the factory. If it needs leveling due to transportation or other reasons, please follow the steps below to

adjust the printing platform.

1. Raise the platform, loosen rubber screws on the left

and right sides of the resin vat, and take out the resin vat.

2. Loose the four screws on the connecting

plate on molding platform plate, attach

calibration card on the printing screen,

press Settings →Print Settings→ Z axis

movement →Leveling, Check whether the

platform ﬁts evenly with the paper by

referring to the steps on Page 7.

3.After conﬁrming that the calibration

card ﬁt evenly, lock the four screws of the

platform.
