Release Notes for Cisco CallManager

Release 3.0(10)

Original CCO appearance: June 20, 2001

Revised: July 2, 2001

These release notes describe the new features and caveats for Cisco CallManager

Release 3.0(10).

For a list of the open and resolved caveats for Cisco CallManager Release 3.0(10),

see “Resolved Caveats” section on page 20 and “Open Caveats” section on

page 64. These release notes are updated every maintenance and major release.

Use these release notes in conjunction with the Installing Cisco CallManager

Release 3.0(10) document, located on Cisco Connection Online (CCO), and the

Cisco Documentation CD-ROM. The Installing Cisco CallManager Release

3.0(10) document is also packaged with your CDs or convergence server.

Access the latest software upgrades and release notes for Cisco CallManager

3.0(10) on Cisco Connection Online (CCO) at

http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.

Contents

Release Notes for Cisco CallManager Release 3.0(10) 78-13493-02

Contents

These release notes discuss the following topics:

•Introduction, page 2

•System Requirements, page 3

•Related Documentation, page 3

•New and Changed Information, page 4

•Resolved Caveats, page 20

•Open Caveats, page 64

•Documentation Updates, page 82

•Obtaining Documentation, page 100

•Obtaining Technical Assistance, page 102

Introduction

Cisco CallManager, a network business communication system, provides

high-quality telephony over IP networks. Cisco CallManager enables the

conversion of conventional, proprietary, circuit-switched PBXs to multiservice,

open LAN systems.

Release Notes for Cisco CallManager Release 3.0(10)

78-13493-02

System Requirements

Make sure Cisco CallManager Release 3.0 is installed and configured on a Cisco

Media Convergence Server. You may also install Cisco CallManager on a

Cisco-approved Compaq server configuration or a Cisco-approved IBM server

configuration.

Caution The installation will not complete if you do not follow the exact configuration.

Access the correct Cisco-approved server configuration for IBM server or

Compaq server at

http://www.cisco.com/go/swonly/

For other system hardware component information and system requirements,

refer to Installing Cisco CallManager Release 3.0(10).

Determining the Software Version

To determine the software version of Cisco CallManager 3.0(10), open Cisco

CallManager Administration; then click Details on the main Cisco CallManager

Administration page. The following information displays:

•Cisco CallManager System version

•Cisco CallManager Administration version

•Database information and database DLL versions

Related Documentation

The following list shows related documents for Release 3.0(10) of

Cisco CallManager:

•Installing Cisco CallManager 3.0(10)

•Quick Start Guide for Cisco CallManager Release 3.0

•Cisco CallManager Administration Guide for Release 3.0(5)

•Troubleshooting Guide for Cisco CallManager Release 3.0(5)

New and Changed Information

Release Notes for Cisco CallManager Release 3.0(10) 78-13493-02

•Cisco IP Phone 7900 Family Administration Guide

•Configuring Remote Serviceability for Cisco CallManager Release 3.0

•Using Cisco CallManager Trace Gathering Tool for Diagnostic Traces

•Cisco WebAttendant Quick Start Guide

•Cisco WebAttendant User Guide

•Cisco JTAPI Developer Guide

•Cisco TAPI Developer Guide

•Software License Agreement

New and Changed Information

New Software Features for Release 3.0(10)

Cisco CallManager Release 3.0(10) adds features and provides additional

workarounds to open caveats and resolves caveats.

Refer to “Resolved Caveats - Release 3.0(10)” section on page 20,“Open

Caveats” section on page 64, and the “Important Notes for Release 3.0(10)”

section on page 5 for more information.

Customer Enterprise Directory Integration Component for Microsoft Active

Directory and Netscape Directory Server

Cisco CallManager Release 3.0(10) supports the customer enterprise directory

integration component for Microsoft Active Directory and Netscape Directory

Server.

The enterprise directory integration component allows the customers' enterprise

directories to maintain the association of devices to users. Using these directories,

administrators can add users manually or link to them from an existing corporate

Lightweight Directory Access Protocol (LDAP) directory.

To read installation instructions, refer to

http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.

Release Notes for Cisco CallManager Release 3.0(10)

78-13493-02

New and Changed Information

Backup Utility

The Backup Utility now creates backup files with the .sti extension instead of

using the .tar extension.

If you have .tar files already on your system, such as from an upgrade, the Backup

Utility restores those files as well, but all current back ups are saved as a .sti

extension.

Important Notes for Release 3.0(10)

Compatibility Matrix

Table 1 lists versions with which Cisco CallManager 3.0(10) has been tested.

Table 1 Compatibility Matrix

Component/Application Version Tested

Cisco Unity 2.4.6.102

Cisco Unity TSP 1.0.0.28

Cisco Personal Assistant 1.1

Apps 2.1 and 2.2

Cisco Customer Response

Application 2.2

IOS 12.2(2T)

Cisco WebAttendant 3.0(3.36)

Cisco IP SoftPhone 1.1(1), 1.1(2) and 1.2(1)

ICD 2.1(1a)

Firmware:Cisco IP Phone 7960 P003D310

Firmware: Cisco IP Phone 7940 P003D310

Firmware: Cisco IP Phone 7910 P004D310

IPCC/ICM Do not upgrade to

Cisco CallManager Release

3.0(10)

New and Changed Information

Release Notes for Cisco CallManager Release 3.0(10) 78-13493-02

Service Parameters

During an upgrade, Cisco CallManager does not overwrite service parameter

values that the system administrator manually configures in Cisco CallManager

Administration.

New Software Features in Release 3.0(9)

The following section contains new and changed software features in

Cisco CallManager Release 3.0(9).

User Interface Enhancement

A new configuration parameter check box exists on the Cisco CallManager

Administration H.323 Gateway Configuration Web page. This allows a H.225D to

"run on every node.” If you select this option (by default it is on), theH.225D runs

on every node.

When upgrading an existing system, your current configuration remains.

Note See CSCdt40606 in the Resolved Caveats - Release 3.0(9) section

for more information.

JTAPI 1.1(1.19)

TAPI 3.0(1.18)

Table 1 Compatibility Matrix

Component/Application Version Tested

Cisco Unity 2.4.6.102

Release Notes for Cisco CallManager Release 3.0(10)

78-13493-02

New and Changed Information

Service Parameters

Cisco CallManager Release 3.0(9) supports new service parameters.

Refer to Table 9 on page 83 for a complete listing of all service parameters, which

includes descriptions and default values, that were not included in Release 3.0(5)

of Cisco CallManager Administration Guide.

New Software Features in Release 3.0(8)

The following sections contain new and changed software features in

Cisco CallManager Release 3.0(8).

Strong Encryption

Cisco CallManager Release 3.0(8) contains low encryption (56-bit or less) in all

of its components.

Access the Download Cryptographic Software link from the main CCO

download location at http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr for

applications that contain 128-bit encryption, such as, TNDconnect.exe (Bridged

Telnet application) and DC directory .dll extensions.

Note Versions preceding Cisco CallManager Release 3.0(8) included

TNDconnect.exe (Bridged Telnet application) and DC Directory .dll

extensions. These files contain strong encryption (128-bit).

Global Call ID

The TAPI Service Provider (TSP) Version 3.0, which is packaged with

Cisco CallManager 3.0, supports Global Call ID.

Applications use the Global Call ID to identify a specific call as it traverses

various resources in the Cisco CallManager. For example, a Call Center

application uses Global Call ID to track a call that comes into a CTI route point,

gets redirected to a CTI port, and terminates at an Agent IP phone.

New and Changed Information

Release Notes for Cisco CallManager Release 3.0(10) 78-13493-02

New Software Features in Release 3.0(7)

Cisco CallManager Release 3.0(7), a maintenance release, adds no new features.

Refer to the “Resolved Caveats - Release 3.0(7)” section on page 47 for more

information.

Important Notes for Release 3.0(7)

Service Parameter Restart Conditions

If you modify any of the service parameters in the following list, you must restart

the Cisco CallManager 3.0(7) before the modifications take effect.

•Digital Port

•Ethernet Phone Port

•Analog Port

•MGCP Listen Port

•MGCP Keep-alive Port

•MessageWaitingOffDN

•MessageWaitingOnDN

•StatisticsEnabled

•MaxDaResponseTimeoutErrorCount

•MaxTotalNumberOfRegisteredCallingEntities

Note The service parameter restart conditions apply to all versions up to

an including Cisco CallManager 3.0(7).

Note Refer to Table 9 on page 83 for more information on service

parameter definitions and defaults.

Release Notes for Cisco CallManager Release 3.0(10)

78-13493-02

New and Changed Information

Cisco IP Phone 7910 and Cisco IP Phone 7940 Compatibility Issue

Cisco IP Phone 7910 and Cisco IP Phone 7940 are only supported by

Cisco CallManager Release 3.0(5a) and higher. If you are running an earlier

version, you must upgrade to a later version at

http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.

New Software Features in Release 3.0(6)

The following sections contain new and changed hardware and software features

in Release 3.0(6) of Cisco CallManager.

Cisco WebAttendant

Cisco WebAttendant supports the traditional role of a manual attendant console.

Associated with a Cisco IP Phone, the application allows the attendant to quickly

accept and dispatch calls to enterprise users. An integrated directory service

provides traditional busy lamp field (BLF) and direct station select (DSS)

functions for any line in the system. The application is Web-enabled and,

therefore, portable to Windows 98, NT, and 2000 platforms.

As one of its primary benefits over traditional attendant console systems, Cisco

WebAttendant monitors the state of every line in the system to efficiently dispatch

calls. The absence of a hardware-based line monitor device offers a much more

affordable and distributable manual attendant solution than traditional consoles.

Note Each Cisco CallManager in a cluster can process as many as 2000

Cisco WebAttendant calls per hour.

New and Changed Information

Release Notes for Cisco CallManager Release 3.0(10) 78-13493-02

Tech Prefixes

Cisco CallManager Release 3.0(6) supports tech prefixes in the Gatekeeper. To

properly configure the Cisco CallManager to register with a tech prefix you must

go to service parameters and perform the following steps:

Step 1 Choose Cisco CallManager.

Step 2 Choose Cisco CallManager from Configured Services.

Step 3 Enter GateKeeperSupportedPrefix in the Params section.

Step 4 Choose String as the type.

Step 5 Click update.

Step 6 Select GateKeeperSupportedPrefix from the Configured Service Parameters.

Step 7 Add the proper value; i.e., 1#, 2#, etc. Only one tech prefix is allowed.

Service Parameter

Cisco CallManager Release 3.0(6) supports a new service parameter.

MaxCTIConnections—This parameter sets the maximum number of

simultaneous active CTI connections between an application and the

Cisco CallManager. The default value is 400 connections.

Note Refer to Table 9 on page 83 for more information on service

parameter definitions and defaults.

Important Notes for Release 3.0(6)

Cisco IP Phone 7910 and Cisco IP Phone 7940 Compatibility Issue

Cisco IP Phone 7910 and Cisco IP Phone 7940 are only supported by

Cisco CallManager Release 3.0(5a) and higher. If you are running an earlier

version, you must upgrade to a later version at

http://www.cisco.com/cgi-bin/tablebuild.pl/callmgr.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de Cisco

Cisco

Cisco OL-6900-01 Manual del operador

Cisco

Cisco IPICS Manual de usuario

Cisco

Cisco SMART BUSINESS COMMUNICATIONS SYSTEM - FEATURE ... Manual del propietario

Cisco

Cisco CVPN3002-8E-K9 - Fast Ethernet VPN Gateway Manual de usuario

Cisco

Cisco OL-4015-08 Manual de usuario

Cisco

Cisco PVDM2 24DM - Digital Modem Module Manual de usuario

Cisco

Cisco OL-11757-01 Manual de instrucciones

Cisco

Cisco 4700M Manual de usuario

Cisco

Cisco TELEPRESENCE MANAGEMENT SUITE SECURE SERVER - CONFIGURATION GUIDE... Manual de usuario

Cisco

Cisco DVD-ROM Manual de instalación y operación

Cisco

Cisco Cisco Access Registrar 4.2 Manual del operador

Cisco

Cisco TELEPRESENCE MOVI 4.1 - ADMINISTRATOR GUIDE... Manual de servicio

Cisco

Cisco 861W - Integrated Services Router Wireless Manual de usuario

Cisco

Cisco 3600 Series Manual de usuario

Cisco

Cisco Unified Videoconferencing Manager Manual de usuario

Cisco

Cisco Unified Contact Center Express Manual de usuario

Cisco

Cisco Nexus 7000 Series Guía

Cisco

Cisco TMS SQL DATABASE Manual de usuario

Cisco

Cisco GEM318P Manual de usuario

Cisco

Cisco ACTIVE NETWORK ABSTRACTION - BROCHURE WHATS NEW IN RELEASE... Manual de usuario

Cisco

Cisco MCS 7825 Series Manual de usuario

Cisco

Cisco CRS-1 Series Manual de usuario

Cisco

Cisco OL-10426-01 Manual de usuario

Cisco

Cisco TMS SERVER REDUNDANCY - CONFIGURATION GUIDE... Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario
