Canon CANOSCAN N650U Manual de usuario

ScanGear CS-U 5.7

for CanoScan N650U/N656U/N1220U Color Scanner

User’s Guide

Top Page

Glossary

Contents

Index

laws, this manual may not be copied, in whole or in part, without

written consent of Canon Inc. Under the law, copying includes

translating into another language or format.

Microsoft and Windows are registered trademarks or trademarks of the

Microsoft Corporation in the United States and other countries.

Canon, and CanoScan are registered trademarks of Canon, Inc.

ColorGear and ImageTrust are registered trademarks of Canon Inc.

All other names are trademarks of their respective companies.

In this manual, screen shots are taken with Windows 98. When you use

Windows 2000 Professional, different screens may appear from this

manual.

Top Page

Glossary

Contents

Index

Chapter 1 Before You Begin................................ 5

Welcome to ScanGear CS-U ...................................................... 6

System Requirements................................................................ 8

Hardware ............................................................................ 8

Software ............................................................................. 9

Getting Help in ScanGear CS-U............................................... 10

Chapter 2 Installing ScanGear CS-U.................. 11

Installing ScanGear CS-U......................................................... 12

Installing ScanGear CS-U ................................................... 13

Uninstalling ScanGear CS-U .................................................... 16

Uninstalling ScanGear CS-U using the CanoScan Setup Utility

CD-ROM ....................................................................... 16

Uninstalling ScanGear CS-U (Windows 98) ........................ 17

Chapter 3 Simple Mode and Advanced Mode.. 19

What are the Simple Mode and Advanced Mode?............... 20

Switching Between the Simple and Advanced Modes ........ 21

Simple Mode Main Window................................................... 22

Advanced Mode Main Window.............................................. 23

Chapter 4 What is on the screen?..................... 25

Main Window.......................................................................... 26

Toolbar..................................................................................... 27

Scanning Buttons..................................................................... 30

Simple Mode Main Window................................................... 31

Advanced Mode Main Window.............................................. 36

The Main Sheet ................................................................. 36

The Tone Sheet.................................................................. 40

Contrast/Brightness Sheet ......................................... 43

Gamma Sheet........................................................... 44

Histogram Sheet ....................................................... 46

Special Tone Curves Sheet......................................... 48

Editing a Special Tone Curve Directly ......................... 49

The Halftone Sheet............................................................ 51

The Scanner Sheet............................................................. 52

Top Page

Glossary

Contents

Index

Chapter 5 Scanning an Original........................ 55

Preparing for the Scanning Job.............................................. 56

Quick Start ............................................................................... 57

Previewing and Scanning an Original.................................... 59

Scanning in the Simple Mode ............................................ 59

Scanning in the Advanced Mode ....................................... 64

Chapter 6 Settings in the Windows Control Panel.. 68

Opening Scanners and Cameras Properties........................... 69

General Settings ...................................................................... 71

Events Settings......................................................................... 72

Preferences Settings................................................................ 73

Color Management Settings................................................... 75

Chapter 7 Troubleshooting................................ 76

Pre-Scan Checklist.................................................................... 77

How to Avoid Problems .......................................................... 78

Troubleshooting Checklist ...................................................... 80

Glossary ........................................................... 85

Index ........................................................... 99

Top Page

Glossary

Contents

Index

chapter 1

Before You Begin

Welcome to ScanGear CS-U

System Requirements

Getting Help in ScanGear CS-U

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

Welcome to ScanGear CS-U

Welcome to Canon ScanGear CS-U 5.7 software for Windows 98 and

Windows 2000 Professional.

ScanGear CS-U 5.7 (hereafter referred to as ScanGear CS-U) will provide

flexible, efficient image enhancement tools for scanning with your

CanoScan N650U/N656U/N1220U Scanner by providing an interface

with a variety of TWAIN-compliant software applications. (TWAIN ☞p.97)

ScanGear CS-U has a number of powerful features that help you achieve

peak performance with your scanner. Using ScanGear CS-U, you can

preview and adjust an image before the image is scanned and acquired

by the parent software application.

Here is a quick summary of the important features of ScanGear CS-U:

• Two operation modes, Simple Mode which allows you to select all

optimum settings with one selection, and Advanced Mode which

allows you to create professional color and other enhancements for

artistic effects.

• Flexible, fully automatic image acquisition, and pre-scan image

manipulation prior to passing data to the image application

• TWAIN 1.6 compliant

• Text Enhanced mode for OCR applications

• Canon ColorGear (Color Matching software technology)

• Automatic preview or preview image cache

• ScanGear CS-U can run with or without its main window,

depending on the acquiring application.

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

Normally when you start a scanning job, you will see the ScanGear CS-U

main window with its toolbar, Preview Area, and tabs.

However, some software applications may not open the ScanGear CS-U

main window. When this occurs you cannot use the settings described in

this user’s guide because the host software application will provide the

settings so you can change the image after it is acquired. When a

software application uses ScanGear CS-U without opening the ScanGear

CS-U main window, this is called the windowless mode.

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

System Requirements

The hardware and software listed below is required to use ScanGear

CS-U.

Hardware

• You can use following scanner with ScanGear CS-U: CanoScan

N650U/N656U/N1220U.

• IBM PC or its compatible on which Windows 98 or Windows 2000

Professional can run

• Memory (RAM) required is determined by your system:

Windows 98 32 MB (64 MB or more recommended)

Windows 2000 Professional

32 MB (64 MB or more recommended)

• 10 MB of free disk space for ScanGear installation

• Free disk space, at least 50 MB. The amount of space required

depends on the scanning area and the Color Mode or Resolution

settings (color images scanned at higher resolution require more

storage space).

Note

Before you scan an image, check the file size in the

status bar. You should have at least twice that amount

of free space available on the hard disk.

• Minimum requirement for monitor: 800 x 600 resolution

(minimum), 256-color (higher resolution with TrueColor

recommended).

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

Software

• Microsoft®Windows®98 or Microsoft®Windows 2000 Professional

• TWAIN-compliant parent software application

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

Getting Help in ScanGear CS-U

For information about using ScanGear CS-U, open the on-line Help by

clicking the Help button on the toolbar or in the dialog boxes.

Click the Contents or Index tab to see if the topic you are looking for is

covered elsewhere in on-line Help.
