BLADE-V2-50
BLADE-V2-100
BLADE-V2-400
User Manual
BLADE V2.0
Digital Pocket Scale
g
Blade Scale® V2.0 Manual
Thank you for purchasing the American Weigh Blade
Scale® V2.0 digital scale. Please read all operating
instructions carefully before use. This electronic scale
is a precision instrument. With normal care and proper
treatment, it will provide years of reliable service.
Never load the scale with more than the maximum
capacity. Overloading will permanently damage it!
Avoid any exposure to extreme heat or cold. Your
scale works better when operated at normal room
temperature. Always allow the scale to acclimate to
normal room temperature for at least one hour before
use.
Give your scale sufcient warm up time. Usually
30-60 seconds before calibration to give the internal
components a chance to stabilize.
Keep your scale in a clean environment. Dust, dirt,
moisture, vibration, air currents and a close distance to
other electronic equipment can all cause an adverse
effect on the reliability and accuracy of your scale.
Handle with care. Gently apply all items to be weighed
onto tray top. Although this scale is designed to be
quite durable, try to avoid rough treatment as this may
permanently damage the internal sensor.
Avoid shaking, dropping or otherwise shocking the
scale. This is a precision instrument and must be
handled with extreme care.
Only operate the scale on a stable, vibration free
surface.
I. OPERATION
Place Scale on a horizontal at surface.
1. Press the [ ] key.
2. Wait until "0.0” is displayed.
3. Put the object(s) on the weighing platform.
4. Using the [
M
] key, you can switch between the
weighing units.
II. TARE WEIGHING
1. Turn on scale as described above.
2. Place the "tare item" on the platform.
3. Press [
T
] and wait until "0.0" is displayed.
4. Add the "net-weight-item".
III. CALIBRATION
Calibration is NOT required before rst use. Only
calibrate if scale is not weighing properly.
**Make sure you use the correct calibration weight for
your scale or the calibration will not be accurate**
BLADE-v2-50: 50g calibration weight
BLADE-v2-100: 100g calibration weight
BLADE-v2-400: 200g calibration weight
1. Turn OFF the scale.
2. Press the [ ] key, then quickly press and hold
the [
M
] key until "CAL" is displayed. You may now
release the [
M
] key.
3. Press [
M
] again. The display will show "CAL"
followed by the required calibration weight (see
above).
4. Place the required calibration weight onto the center
of the platform. Wait 3-4 seconds. The display should
show "PASS", then return to normal weighing.
5. Remove the weight and press [ ] to turn the scale
off. Calibration is complete!
V. TROUBLESHOOTING
The primary reasons for inaccuracy or malfunction
are low batteries, incorrect calibration, overload or
operating on an unstable surface. Please keep this in
mind and maintain and operate your scale properly.
This scale is a precise instrument and must be
handled with the utmost care and caution.
[Display] Elimination of errors
-----------------------------------------------
[Lo] Change the batteries.
[OUT2] Recalibrate the scale as shown above.
[O_Ld] You are overloading the scale. Remove the
excessive load immediately!
[UnST] Use the scale in a more stable position
Model Blade-v2-50 Blade-v2-100 Blade-v2-400
Capacity 50.00g
1.764oz
250.00ct
771.5gn
100.00g
3.528oz
500.00ct
1543.2gn
400.0g
14.11oz
12.86ozt
257.2dwt
Resolution 0.01g
0.001oz
0.05ct
0.1gn (0.2gn minimum)
0.01g
0.001oz
0.05ct
0.1gn (0.2gn minimum)
0.1g
0.01oz
0.01ozt
0.1dwt
Weighing Units g, oz, ct, gn g, oz, ozt, dwt
Calibration Weight (not Included) 50g 100g 200g
Platform Dimensions (inches) 2.75 x 2.75 (Stainless Steel )
Scale Dimensions (inches) 2.9 x 2.9 x 0.7
Power 2 x AAA Batteries (included)
Warranty 10 Year Warranty
Specications
