American Weigh Scales

H-110 (110lb x 0.05lb)

User Manual

H-110

Thank you for purchasing the H-110 digital hanging

scale. Please read all operating instructions carefully before

use. Scales are precision measuring devices and should

always be handled with proper care. To ensure years of

reliable service, keep these simple tips in mind:

• Do not exceed the scale’s maximum capacity.

Overloading your scale can permanently damage it!

• Avoid exposure to extreme heat or cold. Scales

perform best at normal room temperature. If

temperatures have changed dramatically, calibration

and adjustment may be necessary.

• Allow your scale to warm up for 30-60 seconds before

performing calibration and adjustment(if available).

• Store your scale in a clean, dry location. Dust, dirt,

and moisture can accumulate on the weighing

sensors and electronics causing inaccuracy or

malfunction.

• Avoid using your scale in close proximity to strong

radio wave emitting devices such as computers, cash

registers, and cordless phones.

• Alwaysweighonaatandlevelsurface,freefrom

vibrations and drafts. The corner of a room is usually

the most stable.

• Gently apply all items to be weighed. Do not drop

items onto the weighing platform.

• Avoid dropping your scale. The warranty does not

cover damage due to rough treatment or overload.

• Checkthebatteriesrstifyouarehavinganytrouble

with your scale. This simple step can remedy most

scale issues.

• Do not disassemble your scale. This product contains

no user serviceable parts.

I. Part List

1. Scale

2. CR2032 Batteries (x2)

II. Key Description

III. Battery Installation

1. Turn the battery cover counterclockwise to open.

Gently tap the back against your hand to release the

batteries and cover.

2. Ifyouarereplacingthebatteries,makesuretheat

side (positive side) of the CR2032 battery faces out

when installing.

Hold Key

Tare Key

On/O Key

Set Key

Install batteries positive

side facing out

H-110

IV. Operation

1. Press the ON/OFF key to turn the scale on.

2. Once the start-up process completes and the scale

goes to zero you are ready to weigh.

3. Place the quantity to be weighed on the end of the

hook.

4. Wait a couple seconds for the display to stabilize

before taking a weight reading. For best results,

hangscalefromaxedpointratherthanholding

by hand.

V. Changing the Unit of Measure

1. Press the SET key to change the scales displayed

unit of measure.

2. If the scale is turned off then back on, it will default

to the last unit used.

• H-110 Units: kg (kilogram) lb (pound) lb:oz

(pound:ounce)

VI. Using the Tare Feature

You can use this scale’s tare feature to subtract the weight

of an empty container or vessel for net weight determination.

NOTE: The weight of the container will subtract from the

available capacity.

1. Place the empty container or vessel on the hook.

2. Press the TARE key once. The display will then

reset to zero. If the container is removed, it’s weight

will be displayed as a negative number.

3. Youmaynowllthecontainerwiththequantityto

be weighed. The display will show the net weight of

the contents.

4. To return to normal weight display (gross weight),

remove any items from the weighing platform and

press the TARE key again to re-zero the scale.

VII. Using the Hold Feature

1. To hold the current weight on the display, press the

HOLD key.

2. To return to normal weighing, press the HOLD key

again.

VIII. Calibration

Calibration and adjustment are performed at the factory.

However, the weighing range can shift slightly during

shipping. Also, due to changes in local acceleration of gravity

around the world, adjustment is recommended when moving

the scale from one location to another. To check calibration:

1. Place the required calibration weight on the scale

and note the displayed value.

2. If the displayed value is not within acceptable

tolerance (see chart below), adjustment is required.

Model Acceptable

Tolerance (±)

Calibration

Weight

Recommended

Accuracy Class

H-110 0.15 lb / 60g 40 kg OIML M2

IX. Adjustment

1. With the scale OFF, press and hold the SET key and

ON/OFF keys simultaneously.

2. The display will show a random number (ISN). You

may now release the SET and ON/OFF keys.

H-110

3. PressON/OFFagain.Thedisplaywillashthe

required calibration weight.

4. Place the weight on the end of the hook and press

ON/OFF when the weight is stable.

5. The display will show PASS and return to normal

weighing. If EEEE is displayed, try calibration again.

X. Troubleshooting

• Problem: Scale will not turn on

• Solution: Check the batteries

• Problem: Displayedweightuctuatesrandomly

• Solution: Make sure your workspace is stable and

free of any air currents or vibration

• Problem: Displayed weight is inaccurate

• Solution: Perform a calibration adjustment

XI. Error Codes

1. OUTZ - Zero range has shifted. Perform calibration

adjustment. If the problem persists, the load cell may

be permanently damaged due to overloading.

2. EEEEE - Maximum capacity exceeded. Remove the

extra weight to avoid damaging the load cell.

3. No Display - Batteries are low. Replace the

batteries.

XII. Specications

H-110

Max. Capacity 110 lb

Readability 0.05lb

Min. Capacity 100 grams / 0.25 lb

Power Two (2) CR2032 Batteries

Operating Temp 50°F - 86°F

Dimensions 1.0 x 2.5 x 5.2 in.

Warranty 10 Year Limited Warranty

XIII. Capacity/Readability Charts

H-110

110lb x 0.05lb

50kg x 20g

110lb x 1oz
