Avenview VTS-C5-R Manual de usuario

VTS-C5 Series

Part #: VTS-C5-R

Part #: VTS-C5-S

www.avenview.com

Description

VTS-C5 Series solution is an extension system to transmit VGA and RS-232 Data (Tx/Rx) over

Cat 5/5e/6 cable up to 300 meters (1000 ft). VTS-C5 system consists of a Transmitter and a

Receiver unit. The Transmitter is placed near PC and Receiver near Touch Screen and Cat 5/5e/6

cable is used to connect both devices. It is suitable for the interactive application of Touch Screen

Extension and Flat Panel Remote Control. It can simplify the installation, ease the maintenance

and reach a longer distance. The video quality can be adjusted very easily from the FOCUS and

GAIN Control in the Receiver. Now, you can centralize PC and servers in a secured place and

extend the VGA and Data signal up to 300 meters (1000 ft).

The VTS-C5 Series is easy to install and provides accurate signal. It come with a magnetic pad on the

bottom of unit and an attachable metal plate, so you can place the VGA Data Extender very easily on the

surface of PC or any preferred place.

Features

Extend VGA and Data signal over Cat 5/5e/6 cable

Supported VGA Resolution and Distance (distance is based on UTP Cable skew at

30ns/100m):

o1024x768 @ 300m (1000ft)

o1280x1024 @ 200m (650ft)

o1600x1200 @ 200m (650ft)

o1920x1440 @ 200m (650ft)

o2048x1536 @ 50m (165ft)

Bi-directional Serial RS-232 control

Remote and Local monitors can display simultaneously

Plug & Play

Supports VGA, SVGA, XGA, TFT_LCD, with DDC2B function

Equipped with magnetic pad and metal plate for easy installation

Compact size

www.avenview.com

System Devices and Functions

Transmitter VTS-C5-S

Built-in one set of VGA (DB15) and Data (DB9) inputs

Built-in one set of VGA (DB15) output for monitor

Built-in one RJ45 port for system output which can be connected by Cat5/5e/6 cable

and send signal to System Receiver

Receiver VTS-C5-R

Built-in one set of VGA (DB15) and Data (DB9) output for Touch Screen

Maximum VGA resolution of up to 2048x1536 @ 300m (1000ft)

Built-in Video and Focus control to adjust video quality

A PS/2 connector to provide power for Touch Screen’s RS-232 control

Connection Diagram of VTS-C5 Series

www.avenview.com

Cable and Accessories

DB0 Female VTS Cable

VGA Cable 1m

DB9 Male VTS Cable

Package Content

VTS-C5

(Transmitter

& Receiver Set)

Touch Screen 1 Port Transmitter

Touch Screen 1 Port Receiver

VGA Cable 1m

RS232 Cable 1.8m Male

RS232 Cable 1.8m Female

AC 7.5V 1000mA

User Manual

VTS-C5-R

Receiver

Touch Screen 1 Port Receiver

VGA Cable 1m

RS232 Cable 1.8m Male

RS232 Cable 1.8m Female

AC 7.5V 1000mA

User Manual

www.avenview.com

Specifications

VGA-C5-S

VGA-C5-R

Description

1 Port Transmitter

1 Port Receiver

AV Input

DB15 / DB9

RJ45

AV Output

DB15 / RJ45

DB15 / DB9

Video CTRL

Gain & Focus

LED

Tx / Rx

Maximum Resolution

1024 x 768 @ 300m (1000ft)

1280 x 1024 @ 200m (650ft)

1600 x 1200 @ 200m (650ft)

1920 x 1440 @ 200m (650ft)

2048 x 1536 @ 50m (165ft)

Power Input

AC 7.5V

Power Output

DC 5V

Dimensions

62 x 113 x 29

Operating

Temperature

0 - 50°C

Storage Temperature

-20 - 60°C

Humidity

10 –90%

Features, availability and specifications are subject to change without notice.

Avenview Inc.

[email protected]

www.avenview.com
