Avenview FO-VGA-DVI Manual de usuario

www.avenview.com

VGA to DVI Extender over Fiber SET

Model #: FO-VGA-DVI

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or warranties with

respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any

time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in

Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products

including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.

Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly prohibited.

www.avenview.com

Table of Contents

Section 1: Getting Started ...................................................................................................................... 3

1.1 Important Safeguards ............................................................................................................ 3

1.2 Safety Instructions ................................................................................................................. 3

1.3 Regulatory Notices Federal Communications Commission (FCC) ......................................... 4

1.4 Introduction ........................................................................................................................... 4

1.5 Package Contents................................................................................................................... 4

1.6 Before Installation.................................................................................................................. 4

1.7 Installation ............................................................................................................................. 5

1.8 Troubleshooting..................................................................................................................... 6

1.9 Caution................................................................................................................................... 6

Section 2: Specifications......................................................................................................................... 7

2.1 Electrical & Optical Specifications................................................................................................ 8

2.1.1 Electrical Specifications......................................................................................................... 8

2.1.2 Optical Specifications ............................................................................................................ 8

2.2 Connector PIN Assignment .......................................................................................................... 9

2.2.1 Input Connector .................................................................................................................... 9

2.2.2 Output Connector ............................................................................................................... 10

2.2.3 Optical Cable Information ................................................................................................... 11

www.avenview.com

Section 1: Getting Started

1.1 Important Safeguards

Please read all of these instructions carefully before you use the device. Save this manual for future

reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.

Damage, deterioration or malfunction resulting from:

Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized

product modification, or failure to follow instructions supplied with the product.

Repair or attempted repair by anyone not authorized by us.

Any damage of the product due to shipment.

Removal or installation of the product.

Causes external to the product, such as electric power fluctuation or failure.

Use of supplies or parts not meeting our specifications.

Normal wear and tear.

Any other causes which does not relate to a product defect.

Removal, installation, and set-up service charges.

1.2 Safety Instructions

The Avenview FO-VGA-DVI, VGA to DVI Extender over Fiber Optic has been tested for conformity to safety

regulations and requirements, and has been certified for international use. However, like all electronic

equipment’s, the FO-VGA-DVI should be used with care. Read the following safety instructions to protect

yourself from possible injury and to minimize the risk of damage to the unit.

Do not dismantle the housing or modify the module.

Dismantling the housing or modifying the module may result in electrical shock or burn.

Refer all servicing to qualified service personnel.

Do not attempt to service this product yourself as opening or removing housing may expose you to

dangerous voltage or other hazards

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid

falls or spills on to the housing, unplug the module immediately.

Have the module checked by a qualified service engineer before using it again.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

www.avenview.com

1.3 Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this

equipment.

1.4 Introduction

Avenview FO-VGA-DVI, VGA to DVI Extender over Fiber SET lets you extend VGA signal and convert it to DVI up

to 500 meters (1650 feet) at 1920 x 1200 away from host by TMDS analog signal transmission with only 1 SC

Type fiber optic cable. VGA to DVI Extender over Fiber SET includes both VGA to DVI Converter / Extender and

Receiver.

-High Speed and long distance transmission by SC type Multi-Mode 1 fiber

-Automatically detects the input signal and SOG (Sync on Green)

-DVI 1.0 compliant

-Standard VGA plug on Transmitter, DVI plug on Receiver and SC Fiber connector

-R, G, B, Clock signal is transmitted by 1 Multi-Mode optical Fiber

-Supports up to WUXGA (1920 x 1200) resolution

-External power supply

1.5 Package Contents

Before you start the installation of FO-VGA-DVI, please check the package contents.

-FO-VGA-DVI x 1

-FO-DVI-1000M-EMI-R x 1

-Power Adapter +12V x 1

User’s Manual x 1

1.6 Before Installation

Put the product in an even and stable location. If the product falls down or drops, it may cause an

injury or malfunction.

Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high

humidity.

Use the DC power adapter with correct specifications. If inappropriate power supply is used then it

may cause a fire.

Do not twist or pull by force ends of the optical cable. It can cause malfunction.

www.avenview.com

1.7 Installation

The FO-VGA-DVI Transmitter should be connected to the computer’s VGA Port and the Receiver

(FO-DVI-1000M-EMI-R) should be connected the DVI Port of the digital display device. Avenview FO-VGA-DVI

and FO-DVI-1000M-EMI-R Receiver is designed to be used with SC type standard optical cable (Multi-Mode

optical fiber: 50/125, 62.5/125um).

1. Connect FO-VGA-DVI Transmitter to the VGA Source and FO-DVI-1000M-EMI-R Receiver to the

Display.

2. Connect the optical fiber between Transmitter and Receiver.

3. Power on Display

4. Connect DC power to the Receiver

5. Restart the computer or VGA Source.

www.avenview.com

1.8 Troubleshooting

General Troubleshooting

Problem

Possible Solution

No Image

Check if the PC Power is on

Check if connection to the computer and the monitor are

correct.

Turn the PC Power off and on again.

Screen Defects Appear

This product supports up to WUXGA resolution.

Check the maximum resolution range of the graphics card.

1.9 Caution

1. Do not put heavy object on top of the FO-VGA-DVI. It may cause product malfunction.

2. Put the product on even and stable location. If the product falls down or dropped, it may get

damaged.

3. Keep away from high temperature (over 50°C), low temperature (under 0°C) or high humidity. It may

cause a fire and injury by electrical shock.

4. Use DC power adapter with correct specification. Otherwise it may cause fire.

5. Do not twist or pull by force either ends of the optical cable. It can cause malfunction. Minimum

bending diameter is 75mm.

6. Use the multimode (50/125um, 62.5/125um) optical fiber.

www.avenview.com

Section 2: Specifications

Item

Description

Input Signal

PC: up to 1920x1200@60Hz (165MHz)

TV (HD): up to 1080p 60Hz

Input Connector

VGA D-Sub (15pin)

Output Connector

SC Type Fiber Optic, DVI-I

Power

DC +12V 1.5A

Supported Resolution

and Distance

WUXGA 1920 x 1200 @ 500 meters (1650 feet)

Optical

Optical Source

850nm VCSEL

O/E Converter

PIN Photo Diode

Fiber Type

50/125 or 62.5/125 SC Multi-Mode Fiber, SC Fiber

Environmental

Operation

0˚to +50˚C Degree

Storage

-20˚ to +70˚C Degree

Relative Humidity

10 ~ 80%

Power Supply

-=03 ~ 12V

Stresses greater than those listed under “Environmental Ratings” may cause permanent damage to the

device. This is a stress rating only and functional operation of the device at these

or any other conditions above those indicated in the operations section for extended periods of time may

affect reliability.

www.avenview.com

2.1 Electrical & Optical Specifications

2.1.1 Electrical Specifications

Parameter

Symbol

Min

Type

Max

Units

Condition

Supply Voltage

Vcc

+ 12

Supply Current

Icc

Standby

400

Working

Power Dissipation

0.84

Standby

4.8

Working

2.1.2 Optical Specifications

Parameter (per Channel)

Symbol

Min

Typ

Max

Units

Optical Power1

Pout

-3.0

0.0

dBm

Optical Modulation Amplitude

-6.25

dBm

Center Wavelength –Lane 0

771.5

778

784.5

Center Wavelength –Lane 1

793.5

800

806.5

Center Wavelength –Lane 2

818.5

825

831.5

Center Wavelength –Lane 3

843.5

850

856.5

Optical Rise/Fall Time2(P1TX4B-SX4V-01)

200

RMS Spectral Width

0.5

Transmitter module of FO-VGA-DVI includes VCSEL (Vertical Surface Emitting Laser Diode) with 850

nm invisible laser radiation.

DO NOT view directly at laser module of Transmitter or the end of the other side of optical cable

connected to Transmitter with optical instrument.

www.avenview.com

2.2 Connector PIN Assignment

2.2.1 Input Connector

Signal Assignment

Red

N/C

Green

Ground

Blue

Ground

SDA

Ground

H Sync

Red Ground

V Sync

Green Ground

SCL

Blue Ground

www.avenview.com

2.2.2 Output Connector

Signal Assignment

T.M.D.S. optical output

Signal

Assignment

Signal

Assignment

Signal

Assignment

CH 2-

CH 1-

CH 0-

CH 2+

CH 1+

CH 0+

CH2 Ground

CH1 Ground

CH0 Ground

N/C

+5V

CLK Ground

N/C

Ground

CLK+

N/C

CLK-

Ground
