Avenview FO-HDSDI-SET Manual de usuario

www.avenview.com

HD/SD-SDI over Multimode LC

type Fiber Optic Extender

User’s Guide

Models

FO-HDSDI-SET

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations

or warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to

specifications and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual

property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes

no liability whatsoever, and disclaims any express or implied warranty, relating to its products including, but not limited to, the implied

warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.

Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly

prohibited.

www.avenview.com

Table of Contents

Section 1: Getting Started...................................................................................................................... 3

1.1 Important Safeguards ............................................................................................................ 3

1.2 Safety Instructions ................................................................................................................. 3

1.3 Regulatory Notices Federal Communications Commission (FCC) ......................................... 4

1.4 Introduction ........................................................................................................................... 4

1.5 Features ................................................................................................................................. 5

1.6 Package Contents................................................................................................................... 5

1.7 Before Installation.................................................................................................................. 5

1.8 Panel Description................................................................................................................... 5

Section 2: Installation............................................................................................................................. 6

Section 3: Specifications......................................................................................................................... 8

www.avenview.com

Section 1: Getting Started

1.1 Important Safeguards

Please read all of these instructions carefully before you use the device. Save this manual for future

reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.

Damage, deterioration or malfunction resulting from:

Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized

product modification, or failure to follow instructions supplied with the product.

Repair or attempted repair by anyone not authorized by us.

Any damage of the product due to shipment.

Removal or installation of the product.

Causes external to the product, such as electric power fluctuation or failure.

Use of supplies or parts not meeting our specifications.

Normal wear and tear.

Any other causes which does not relate to a product defect.

Removal, installation, and set-up service charges.

1.2 Safety Instructions

The FO-HDSDI-SET, HD/SD-SDI over Multimode LC-type Fiber Optic Extender has been tested for conformance

to safety regulations and requirements, and has been certified for international use. However, like all

electronic equipments, the FO-HDSDI-SET should be used with care. Read the following safety instructions to

protect yourself from possible injury and to minimize the risk of damage to the unit.

Do not dismantle the housing or modify the module.

Dismantling the housing or modifying the module may result in electrical shock or burn.

Refer all servicing to qualified service personnel.

Do not attempt to service this product yourself as opening or removing housing may expose you to

dangerous voltage or other hazards

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid

falls or spills on to the housing, unplug the module immediately.

Have the module checked by a qualified service engineer before using it again.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

www.avenview.com

1.3 Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this

equipment.

1.4 Introduction

The FO-HDSDI-SET is an ideal and economic solution designed for transmission of multi-rate SDI video, with

embedded audio and metadata over a multi-mode optical fiber cable.

The transmitter module (FO-HDSDI-S) receives one HD-SDI electrical input, perfectly converts SMPTE 292M,

SMPTE 259M, or DVB-ASI electrical SDI signal to multi-mode optic SDI signals. The receiver module

(FO-HDSDI-R) receives optical signal from input LC connector, and then perfectly converts it to electrical SDI

signal. Both transmitter and receiver provide equalizing and re-clocking at input unit in order to re-construct

the signal for consistent quality. The FO-HDSDI-SET is perfect for today’s broadcast applications, including

video production, video editing, studio to studio and studio to CATV head end. In addition, since transmission

of content is inherently secure and immune to outside interference, fiber applications are favored in

government, military, and medical environments.

www.avenview.com

1.5 Features

-Enable transmission of digital video signal over optical fiber up to 1 km

-Automatic cable EQ up to 300m (1000ft) at SD-SDI or 150m (500ft) for HD-SDI

-Standard LC-type fiber optic connector

-Supports following protocols:

oSMPTE 259M (270Mbps)

oSMPTE 259M (360Mbps)

oSMPTE 292M / HDTV (1.485Gbps and 1.485/1.001Gbps)

oDVB ASI (270Mbps)

-Automatic re-clocked / Manual bypass (optional upon request)

-HD/SDI Input signal detection

-Easy installation

1.6 Package Contents

Before you start the installation of the converter, please check the package contents.

-FO-HDSDI-SET x 1

-Power Adapter (+5VDC) x2

-User’s Manual x1

1.7 Before Installation

Put the product in an even and stable location. If the product falls down or drops, it may cause an

injury or malfunction.

Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high

humidity.

Use the DC power adapter with correct specifications. If inappropriate power supply is used then it

may cause a fire.

Do not twist or pull by force ends of the optical cable. It can cause malfunction.

1.8 Panel Description

www.avenview.com

TRANSMITTER

RECEIVER

Section 2: Installation

Follow these instructions for installation of FO-HDSDI-SET:

1. Connect a camera or other HD/SD-SDI device to transmitter of FO-HDSDI-SET

www.avenview.com

2. Connect devices equipped with HD/SD-SDI inputs (e.g. monitors or video processors) to receiver

FO-HDSDI-SET

3. Plug power adapter to 5V DC power jack of FO-HDSDI-R & FO-HDSDI-S

www.avenview.com

Section 3: Specifications

Item

Description

Model

FO-HDSDI-S

FO-HDSDI-R

Model

Transmitter (TX)

Receiver (RX)

SDI Standards

SD-SDI & HD-SDI

Auto HD/SD-SDI Detection

Yes

Supported Protocols

SMPTE 259M (270Mbps / 360Mpbs), DVB ASI (270Mbps)

SMPTE 292M / HDTV (1.485Gbps and 1.485/1.001Gbps)

Video Bandwidth

[1.485Gpbs & 1.485/1.001Gbps]

Data Rates

270 / 1483 / 1485 Mbps

Supported Video

[HD] 720p50/59.94/60, 1035i50/59.94/60, 1080i50/59.94/60, 1080p24/30

[SD] [email protected], PAL@50Hz

SDI signal type

SMPTE-292M, SMPTE-259M, DVB-ASI

Output impedance

75

Auto Reclocking Mode

Automatic detection: 270Mbps / 1.483Gbps / 1.485Gbps

Automatic bypass: 177Mbps / 360Mbps / 540Mbps

Cable equalization

[HD-SDI] up to 150m (500ft)

[SD-SDI] up to 300m (1000ft)

[HD-SDI] up to 125m (410ft)

[SD-SDI] up to 300m (1000ft)

Audio support

Yes

RP-918 pathological

patterns

Immune

Input Connectors

1x BNC (SDI)

1 x Optical LC (SDI)

Output Connectors

1x Optical LC (SDI)

1 x BNC (SDI)

BNC connector

75inter-locked socket

Optical Fiber Connector

LC Type

Fiber Optics

Wavelength: 850 nm

Extinction ratio: 8-10

Overshoot < 10%

Optical power: -4 to -10 dBm

Type: Multi-mode

Jitter < 0.2 UI

Rise/fall < 500 pS

Receiver sensitivity: -17 dBm

Dimensions

4.3” x 1.6” x 1.2” (L x W x H)

Weight

155g

Power Supply

5V 4A DC

Power Consumption

5 Watts (max)

Operating Temperature

0~40°C [32~104°F]

Storage Temperature

-20~60°C [-4~140°F]

Relative Humidity

20~90% RH [no condensation]

www.avenview.com

Disclaimer

www.avenview.com

While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the

operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of

Avenview concerning such products or this documentation, for any interruption of service, loss or interruption of business, loss of

anticipatory profits, or for punitive, incidental or consequential damages in connection with the furnishing, performance, or use of the

Avenview hardware, software, or other products and documentation provided herein.

Avenview Inc. reserves the right to make changes without further notice to a product or system described herein to improve reliability,

function or design. With respect to Avenview products which this document relates, Avenview disclaims all express or implied warranties

regarding such products, including but not limited to, the implied warranties of merchantability, fitness for a particular purpose, and

non-infringement.
