Agilent Technologies 5DX 5000 Series Manual de usuario

5DX Series

5000

5DX Series 5000 Installation Guide

Manual Version A

Software Revision 8.0

April 2002

N7200-90116

Agilent Technologies

Emergency Shut Down Procedure

In the event of a disaster or system emergency, shut down the 5DX by pressing one of the

Emergency Stop Buttons, as indicated in Figure T-1:

For additional information on safety and the 5DX system, see the Safety Summary

(Chapter 2 of the User’s Guide or Service Guide).

Figure T-1 Emergency Stop Button Locations

Emergency Stop

Release Keys

Emergency Stop Button

(Locking Switch)

Emergency Stop Button locks

when pressed

X-ray On Indicator

5DXSeries

5000

iii

Notices

Printed in USA

N7200-90116 Printed: April 2002

NOTICE

This manual is provided “as is” and is subject to change without notice.

AGILENT TECHNOLOGIES MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NONINFRINGEMENT,

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Agilent Technologies shall not be liable for errors contained herein, nor for direct, indirect, general, special, incidental

or consequential damages in connection with the furnishing, performance, or use of this material.

Adobe™ is a trademark of Adobe Systems Incorporated which may be registered in certain jurisdictions.

Hewlett-Packard®is a registered trademark of Hewlett-Packard Company

Microsoft®is a U.S. registered trademark of Microsoft Corp.

Windows®and MS Windows®are U.S. registered trademarks of Microsoft Corp.

Manual Printing History And System Software Revisions:

This page lists this manual's printing history and the system's software revisions. If you receive manual updates or

system software revisions, a new Printing History Page will accompany the updates and revisions. It is important that

you insert the new Printing History Page in the manual and remove the old one.

Software Revision Manual Revision

8.0 Rev A.1, April 2002

Safety Information

ELECTRIC SYMBOLS

WARNING This product produces X-rays. Do not attempt to open any part of the

product. Exposure to X-rays can cause serious bodily injury. Refer all

servicing to service-trained personnel.

WARNING This product produces X-rays. Do not operate this product or turn on

the X-rays source unless all shielding is in place. Operation without

shielding in place can result in serious bodily injury.

Direct Current (dc)

Alternating current (ac)

Indicates the field wiring terminal that must be connected to earth

ground before operating the equipment — protects against electrical

shock in case of fault.

Frame or chassis ground terminal — typically connects to the equip-

ment’s metal frame.

SAFETY SYMBOLS

WARNING Calls attention to a procedure, practice, or condition that could result in bodily

injury or death.

Caution Calls attention to a procedure, practice, or condition that could cause damage to

equipment or permanent loss of data.

Instruction symbol affixed to product. Indicates that the user must refer to the

manual for specific WARNING or CAUTION information to avoid personal injury

or damage to the product.

Indicates hazardous voltage.

Indicates Pinch Hazard.

Indicates this equipment produces laser radiation when energized.

Indicates this equipment produces X-rays when energized.

WARNINGS

The following general safety precautions must be observed during all phases of operation, service, and repair of

this product. Failure to comply with these precautions or with specific warnings elsewhere in this manual

violates safety standards of design, manufacture, and intended use of the product. Agilent Technologies, Inc.

assumes no liability for the Customer’s failure to comply with these requirements.

Ground the Equipment: For Safety Class 1 equipment (equipment having a protective earth terminal), an

uninterruptible safety earth ground must be provided from the main power source to the product input wiring terminals

or supplied power cable.

DO NOT operate the product in an explosive atmosphere or in the presence of flammable gases or fumes.

For continued protection against fire, replace the line fuses(s) only with the fuse(s) of the same voltage and current

rating and type. DO NOT use repaired fuses or short-circuited fuse holders.

Keep away from live circuits: Operating personnel must not remove equipment covers or shields. Procedures

involving the removal of covers or shields are for use by service-trained personnel only. Under certain conditions,

dangerous voltages may exist even with the equipment switched off. To avoid dangerous electrical shock, DO NOT

perform procedures involving cover or shield removal unless you are qualified to do so.

DO NOT operate damaged equipment: Whenever it is possible that the safety protection features built into this

product have been impaired, either through physical damage, excessive moisture, or by any other reason, REMOVE

POWER and do not use the product until safe operation can be verified by service-trained personnel. If necessary,

return the product to an Agilent Technologies Sales and Service Office for service and repair to ensure that safety

features are maintained.

Do not service or adjust alone: Do not attempt internal service or adjustment unless another person, capable of

rendering first aid and resuscitation, is present.

Do not substitute parts or modify equipment: Because of the danger of introducing additional hazards, do not install

substitute parts or perform any unauthorized modification to the product. Return the product to an

Agilent Technologies Sales and Service Office for service and repair to ensure that safety features are maintained.

Agilent 5DX Installation Guide

Emergency Shut Down Procedure . . . . . . . . . . . . . . . . . . . .ii

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Agilent 5DX Installation Guide . . . . . . . . . . . . . . . . . . . . . . vii

Agilent 5DX Installation

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Preparing for Agilent 5DX Installation . . . . . . . . . . . . . . . . . 1

Time Required for Installation . . . . . . . . . . . . . . . . . . . . 2

What has to be done before installation begins? . . . . . 2

System Arrival, Inspection and Placement . . . . . . . . . . 3

System Hardware Installation and Setup . . . . . . . . . . . . . 14

System Performance Verification Procedure . . . . . . . . . . 24

System Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Panel Handling Subsystem Verification . . . . . . . . . . . . . . 30

Appendix A: SMEMA

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

SMEMA Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

SMEMA Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Appendix B: Wiring Configuration

Wiring Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

3-Phase Wye or Delta . . . . . . . . . . . . . . . . . . . . . . . 52

3-Phase Wye with Neutral . . . . . . . . . . . . . . . . . . . . . 54

Agilent 5DX Installation

Overview

This document is intended to guide you through the Agilent 5DX

installation process. All major steps have check boxes like this: on

the left side of the page. Use these check boxes as you proceed with the

installation to ensure all steps of the installation are complete.

Preparing for Agilent 5DX Installation

You may need to refer to the following documents.

• Unpacking Instructions (N7200-90075-C)

• Site Preparation Manual (N7200-90109)

• Agilent 5DX System Administration Manual (N7200-90124) (This

document is also on-line.)

• 5DX Service Guide (on-line document)

• Agilent Electrostatic Discharge Control Specification (A-5951-1589-1)

• Agilent X-Ray Safety Test Procedure (5021-1979) and X-Ray Safety Test

Report (N7200-90092)

The unpacking instructions (N7200-90075-C) will be located on the

outside of the crate. The Site Preparation Manual has been sent to the

customer before this installation began. The Service Guide and System

Administration Manual are on-line when you get the system up and

running. The ESD document is one of general corporate nature that you

should already be familiar with, if you are not, please review it as soon as

possible.

NOTE Installation is intended to be performed by qualified Agilent

Customer Engineering personnel only.

Agilent 5DX Installation2

Time Required for Installation

It will generally take one or two days to install the Agilent 5DX System. If

this is the first installation at the site, the three-day Basic Maintenance

Training should also be provided for the customer’s maintenance personnel

and primary operators.

The time estimate is a general guideline. You may take more or less time

to install the 5DX system depending on the customer’s requirements, what

components are to be installed, and how the 5DX system is handled

throughout the delivery and installation process.

You will need a copy of the X-ray Safety Test Procedure (5021-1979) and the

X-Ray Safety Test Report (N7200-90092) to complete the installation.

You may need to acquire these before entering the customer site. These

documents are available from your Agilent logon at: http://

mskc.usa.agilent.com. Click on the EPT/SPT tab at the top of the page.

Click on LMC Quality X-ray documentation. Both the procedure and

report are available from this page.

What has to be done before installation begins?

All system components and software have been delivered and an

acceptable site has been chosen for installation. All utilities (air, electric,

etc.) are ready for the installation and are at the site of installation as

specified in the Site Preparation Manual.

NOTE An Agilent CE must be present to break the seal on the truck

(domestic shipments) and for pallet unloading, system

movement, uncrating and placement (whenever possible).
