ACME LED-4TC Manual de usuario

LED PANEL

LED-4TC

User Manual

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions

2. Technical Specifications

3. Installation

4. How to set the unit

5. How to control the fixture

6. DMX512 Configuration

7. DMX512 Connections

8. Troubleshooting

9. Fixture Cleaning

1. Safety Introductions

WARNING

Please keep this User Manual for future consultation. If you sell the fixture to another

user, be sure that they also receive this instruction booklet.

Unpack and check carefully there is no transportation damage before using the fixture.

Before operating, ensure that the voltage and frequency of power supply match the

power requirements of the fixture.

It’s important to ground the yellow/green conductor to earth in order to avoid electric

shock.

Disconnect main power before servicing and maintenance.

Use safety chain when fixes this fixture. Don’t handle the fixture by taking its head only,

but always by taking its base.

Maximum ambient temperature is Ta : 40℃. Don’t operate it where the temperature is

higher than this.

In the event of serious operating problem, stop using the fixture immediately. Never try

to repair the fixture by yourself. Repairs carried out by unskilled people can lead to

damage or malfunction. Please contact the nearest authorized technical assistance

center. Always use the same type spare parts.

Do not connect the device to any dimmer pack.

Do not touch any wire during operation and there might be a hazard of electric shock.

To prevent or reduce the risk of electrical shock or fire, do not expose the fixture to rain

or moisture.

The housing must be replaced if they are visibly damaged.

Do not look directly at the LED light beam while the fixture is on.

Warning

Please read the instructions carefully which includes important

information about the installation, operation and maintenance.

If using a 230Vac 50Hz power supply, do not connect in series more than

30 units, use another mains supply for the next 30 units.

If using a 120Vac 60Hz power supply, do not connect in series more than

21 units, use another mains supply for next 21 units.

To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or

moisture.

Do not open the unit within five minutes after switching off.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly

damaged.

Caution

There are no user serviceable parts inside the fixture. Do not open the housing or attempt

any repairs yourself. In the unlikely situation, your unit may require service, please contact

your nearest dealer.

2. Technical Specifications

DMX channel: 4 channel modes

LED: 4 x 3W RGB(Tri-color) LED, 50,000 hrs rated

Power supply

Input Voltage: AC 100-240V, 50/60Hz

Power consumption: 28.5W

Fuse: T 6.3A

Dimension: 218 x 186 x 89 mm

Weight: 1.8 kgs

3. Installation

The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is

firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure

to which you are attaching the unit is secure and is able to support a weight of 10 times of

the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the

unit when installing the fixture.

The equipment must be fixed by professionals. And it must be fixed at a place where is out

of the touch of people and has no one pass by or under it.

4. How To Set The Unit

4.1 Control Panel

○

1Display: To show the various menus and the selected functions

LED:

○

2 DMX

DMX input present

○

3 MASTER

Master Mode

○

4 SLAVE

Slave Mode

○

5 SOUND

Flashing

Sound activation

Button:

○

6 MENU

To select the programming functions

○

7 DOWN

To go backward in the selected functions

○

8UP

To go forward in the selected functions

○

9 ENTER

To confirm the selected functions

○

10Microphone: Receive music for the sound active.

○

11 Only for remote control: By connect to the CA-8 or CA-9 RTX to control the unit for

Stand by, Function and Mode function.

○

12DMX output: For DMX512 link, use 3/5-pin XLR plug cable to link the next unit.

○

13DMX input: For DMX512 link, use 3/5-pin XLR plug cable to input DMX signal.

○

14Mains input: Connect to supply mains power.

○

15Mains output: Connect to supply mains power for the next unit.

4.2 Main Function

To select any of the given functions, press the MENU button up to the required one is shown

on the display. Select the function by ENTER button and the display will blink. Use DOWN

and UP button to change the mode. Once the required mode has been selected, press the

ENTER button to setup or it will automatically return to the main functions without any

change after idling 8 seconds. To go back to the functions without any change press the

MENU button. The main functions are shown below:

DMX 512 Address Setting

Press the MENU button up to when the is shown on the display. Press ENTER

button and the display will blink. Use DOWN and UP button to change the DMX512 address.

Once selected, press the ENTER button to store or automatically return to the main

functions without any changes after 8 seconds. To go back to the functions without any

change press the MENU button again.

Channel mode

Press the MENU button up to when the is shown on the display. Pressing the

ENTER button and the display will blink. Use the DOWN and UP button to select the

(channel 1) or (channel 2) or (channel 3) or (channel 4)

mode. Once the mode has been selected, press the ENTER button to setup or automatically

return to the main functions without any change after 8 seconds. To go back to the functions

without any change press the MENU button again.

Show Mode

Press the MENU button up to when the is shown on the display. Pressing ENTER

button and the display will blink. Use DOWN and UP button to select the (show 8)

or (show 1) or (show 2) or …(auto show). Once the show has

been selected, press the ENTER button to confirm, if you select (show 1) or

(show 2) or …(show 12), you can press DOWN and UP button to select

(slowest) or …(fastest), press ENTER button to store or automatically

return to the main functions without any change after 8 seconds. To go back to the functions

without any change press the MENU button again.

Chase Mode

Press the MENU button up to when the is shown on the display. Pressing ENTER

button and the display will blink. Use DOWN and UP button to select the (chase 1)

or …or (chase 16) or (fade). Once the chase has been selected, press

the ENTER button to confirm, then press DOWN and UP button to select (slowest)

or …(fastest), press ENTER button to store or automatically return to the main

functions without any change after 8 seconds. To go back to the functions without any

change press the MENU button again.

Slave Mode

Press the MENU button up to when the is shown on the display. Pressing ENTER

button and the display will blink. Use DOWN and UP button to select the (Mater) or

(normal) or … or (16 light show) mode. Once the mode has been selected,

press the ENTER button to setup or automatically return to the main functions without any

change after 8 seconds. To go back to the functions without any change press the MENU

button again.

Sound control

Press the MENU button up to when the is shown on the display. Pressing ENTER

button and the display will blink. Use DOWN and UP button to select the (sound

control on) or (sound control off). Once the mode has been selected, press the

ENTER button to setup or automatically return to the main functions without any change

after 8 seconds. To go back to the functions without any change press the MENU button

again.

Blackout Mode

Press the MENU button up to when the is shown on the display. Pressing ENTER

button and the display will blink. Use DOWN and UP button to select the (no

blackout) or (yes blackout) mode. Once the mode has been selected, press the

ENTER button to setup or automatically return to the main functions without any change

after 8 seconds. To go back to the functions without any change press the MENU button

again.
