MEGA STROBE 5000

LED-ST5000

User Manual

Please read the user manual before use

1 A

2 A

Table of Contents

1，Safety Information…………………………………………………. 3

2，Rear Panel…………………………………………………………. 5

3，Preparation for Use ………………………………………………...5

4，Main Function …………………………………………………….. 6

5，Remote Control…………………………………………………….11

6，Technical Specification…………………………………………….14

3 A

1. Safety Information

Warning: This product is for professional use only! It is not for

household use.

The LED-ST5000 presents risks of lethal or severe injury due to fire and

heat, electric shock, ultraviolet radiation, and falls. Flashing light is also

known to trigger epileptic seizures in persons who are photosensitive.

Read this manual before powering or installing the fixture, follow the

safety precautions listed below and observe all warnings in this manual

and printed on the fixture.

Noted: high voltage in the LED board!

Super power strobes, so please avoid extended periods of

continuous flashing

To guard against electric shock

Do not remove the rear cover: there are no user-serviceable parts inside.

Always ground (earth) the fixture electrically.

Use only a source of AC power that complies with local building and electrical

codes and has both overload and ground-fault protection.

Do not expose the fixture to rain or moisture.

To guard against UV radiation, burns, and fire

Never operate the fixture with the front glass open, missing or damaged.

Do not stare directly into the light. Never look at an exposed LED while it is lit.

Never attempt to bypass the fuse. Always replace defective fuses with ones of the

specified type and rating.

Verify that the power feed cable is rated for the current draw of all connected

fixtures.

Keep all combustible materials (for example fabric, wood, paper) at least 0.5 meters

(20 inches) away from the fixture. Keep flammable materials well away from the

fixture.

Minimum distance to illuminated surface is 10 meters.

Provide a minimum clearance of 0.1 meters (4 inches) around air vents.

Never place filters or other materials over the front glass cover.

The exterior of the fixture can reach temperatures up to 120° C (248° F). Allow the

4 A

fixture to cool for at least 15 minutes before handling.

Do not modify the fixture or install other than genuine parts.

Do not operate the fixture if the ambient air temperature (Ta) exceeds 40° C (104°

F).

To guard against falls

When suspending the fixture above ground level, verify that the structure can hold

at least 10 times the weight of all installed devices.

Verify that all external covers and rigging hardware are securely fastened and use

an approved means of secondary attachment such as a safety cable.

Block access below the work area whenever installing or removing the fixture.

To guard against epileptic seizure

Do not operate the fixture near stairways.

Provide advance notice that strobe lighting is in use.

Avoid extended periods of continuous flashing, particularly at frequencies of 10 to

20 flashes per second.

5 A

2. Rear Panel

1, Power In/Out

2, Circuit Breaker

3. LED display

4, Menu /UP/DOWN/ Enter button

5, DMX signal/ Flash indicator

6, DMX input/output

3. Preparation for Use

Table1: Cord cap wirings

INSTALLATION

The LED-ST5000 may be installed in any orientation. The mounting bracket provides

five 12 mm holes for direct fastening or attachment of rigging clamps.

To install the mounting bracket

1. Place the fixture face down on a table.

2. Place an aluminum washer on each mounting bracket stud.

3. Make clear the direction of left and right side of bracket and lock the screws. After

6 A

that, tighten one hand knob to lock the mounting bracket in one end of bracket.

4. MAIN FUNCTION

Press MENU button enter the function, then use UP/DOWN or MENU button

to select the function you want, final press ENTER button to confirm the

function you select. Wait for 30 seconds, it will return to main interface. If

you want back to main menu, please hold MENU button for 1 second. The

main menu as follow:

4.1 DMX 512 address setting

Select ADDR option and the display will blink, press ENTER button to

confirm your selection. You can check the current DMX address from LED

display. The DMX address can be changed by press UP/DOWN button and

then press ENTER button to confirm your selection. Wait for 30 seconds, it

will return to main interface. If you want back to main menu, please hold

MENU button for 1 second.

4.2 Channel mode setting

Select CHMD option, press ENTER button to confirm your selection. Change

the channel way (1/2/3/4) by press UP/DOWN button. Press ENTER button

to confirm your selection. Wait for 30 seconds, it will return to main interface.

7 A

If you want back to main menu, please press MENU button.

4.3 LED display setting

Select the LED option, press ENTER button to confirm your selection. You

can see the current ON/OFF status of LED display now. You can change its

status by press UP/DOWN button. Then press ENTER button to confirm your

selection. If you choose OFF, than the LED display will close without any

operation for I min. Wait for 30 seconds, it will return to main interface. If you

want back to main menu, please hold MENU button for 1 second.

4.4 LED display direction setting

Select DISP option, press ENTER button to confirm your selection. Select

the DISP / DSIP by press UP/DOWN button. Press ENTER button to confirm

your selection. Wait for 30 seconds, it will return to main interface. If you

want back to main menu, please hold MENU button for 1 second.

4.5 Test setting

Select TEST option, press ENTER button to confirm your selection. The

flash indicator will light up and the unit will test automatically. Wait for

several seconds self-test, it will return to main interface. If you want back to

main menu, please hold MENU button for 1 second.

4.6 Temperature

Select the LEMP, press ENTER button and the display will show the

temperature of unit. Wait for 30 seconds, it will return to main interface. If

you want back to main menu, please hold MENU button for 1 second.

8 A

4.7 Check the version number

Select the VER, press ENTER button to confirm. You can see the current

version number now (b 10/v 10) and check them by UP/DOWN. Wait for 30

seconds, it will return to main interface. If you want back to main menu,

please hold MENU button for 1 second.

Channel Mode:

1 Channel Mode

Channel

Value

Function

0-5

Blackout

6-250

Flash rate, slow to fast

251-255

Continuous ”Blinder”effect

2 Channel Mode

Channel

Value

Function

0-5

Blackout

6-255

Flash rate, slow to fast

Flash intensity

0-5

Blackout

6-255

Minimum to maximum

3 Channel Mode

Channel

Value

Function

Flash intensity

0-5

Blackout

6-255

Minimum to maximum

9 A

Flash duration

0-255 0-650 ms@50 Hz AC, or 0-530 ms@60 Hz AC

Flash rate

0-5

No flash

(single flash with ch. 1)

6-255

0.5-25 Hz@50 Hz AC, or 0.6-30 Hz @60 Hz AC

4 Channel Mode

Channel

Value

Function

Flash intensity

0-5

Blackout

6-255

Minimum to maximum

Flash duration

0-255 0-650 ms@50 Hz AC, or 0-530 ms@60 Hz AC

Flash rate

0-5

No flash

(single flash with ch. 1)

6-255

0.5-25 Hz@50 Hz AC, or 0.6-30 Hz @60 Hz AC

Special effects

0-5

No effect

6-50

Ramp up

51-100

Ramp down

101-150

Ramp up-down

151-200

Lightning
