ACME MP-400Z IP Manual de usuario

MP-400Z IP

User Manual

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions.....................................................................................................................2

2. Techical Specfications ................................................................................................................4

3. How To Set The Fixture..............................................................................................................5

3.1 Control Panel ...........................................................................................................................5

3.2. Main Functions.......................................................................................................................6

4.How To Control The Unit ..........................................................................................................11

4.1 Master/Slave Built In Preprogrammed Function...................................................................12

4.2 DMX Controller......................................................................................................................12

4.3 DMX 512 Configuration .........................................................................................................12

4.4 DMX512 Connection .............................................................................................................17

5. Troubleshooting.......................................................................................................................18

6. Fixture Cleaning.......................................................................................................................18

1. Safety Instructions

WARNING

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure

that they also receive this instruction booklet.

Caution

：

All fixtures are intact from the manufacturer, please operate follow up the user manual,

artificial fault are not under guarantee repair.

Unpack and check carefully there is no transportation damage before using the unit.

Do install and operate by operator.

Use safety chain when fixes the unit.

The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces.

Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.

Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

Maximum ambient temperature TA : 40℃. Don’t operate it where the temperature is higher

than this.

Don’t connect the device to any dimmer pack.

First run, there will be smoke or smells, and all disappearing a few minutes later.

Make sure there are no flammable materials close to the unit while operating, as it is fire

hazard.

Look over power wires carefully, replace immediately if there is any damage.

Unit surface temperature may reach up to 60℃. Don’t touch the housing bare-hand during its

operation.

Never run on for a long time lest shortening lifespan.

Do not operate in dirty and dusty environment, also cleaning fixtures regularly.

Do not allow children to operate the fixture.

Please read the instructions carefully which include important

information about the installation, operation and

maintenance.

Do not touch any wire during operation as there might be a hazard of electric shock.

Avoid power wires together arounding other cables.

In the event of serious operating problem, stop using the unit immediately.

Never turn on and off the unit time after time.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Do not open the unit as there are no user serviceable parts inside. Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center.

Disconnect the mains power if the fixture is not used for a long time.

Do use original packing materials once transport it again.

To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or

moisture.

Do not look directly at the LED light beam while the fixture is on.

To protect the machine, power off 10s rear can electrify.

Installation

The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is

firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure to

which you are attaching the unit is secure and is able to support a weight of 10 times of the

unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit

when installing the fixture.

The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people and has no one pass by or under it.

2.Techical Specfications

DMX Channel: 5 CH/ 7 CH/ 9 CH channels

Control Mode: DMX512,RDM

Firmware Upgrade: Update via DMX link

Display: OLED display

Data In/Out: 5-pin IP XLR

Power In/Out: IP connector

Protection Rating: IP65

Built-in programs for selection

Can change the DMX address code, machine reset, voice mode conversion and other functions

from the console

Uniform RGBW color mixing and rainbow effect

Advanced RDM function

Voltage: AC 100-240V/50HZ

Power consumption: 250W

Light source: 7 x 30W RGBW

Zoom Range: 6°~40°

Power Cable Daisy Chain: 6 Fixtures Max.(120V, 60Hz); 12 Fixtures Max. (230V, 50Hz)

Dimension: 316x295x357 mm

Weight

：

8.5 kg

3.How To Set The Fixture

3.1 Control Panel

1. Display

To show the menu and the selected functions

2. Button:

To select the programming functions

DOWN

To go backward in the selected functions

To go forward in the selected functions

ENTER

To confirm the selected functions

3. DMX IN

Water proof connectors for DMX512 operation,3/5-pin XLRcable tolinkthe DMX console

4. DMX Out

Water proof connectors for DMX512 operation,3/5-pin XLRcable tolinkthe next unit

5. Power In

Connects to power supply

6. Power Out

Connects to next fixture

3.2. Main Functions

To select any functions, press the MENU button until the required one is shown on the display.

Select the function by the ENTER button and the display will blink. Use the DOWN and UP button

to change the mode. Once the required mode has been selected, press the ENTER button to setup

or it will automatically return to the main functions without any change after idling one minute.

Back to the functions without any change press the MENU button. The main functions are shown

below:

DMX Setting

To select DMX Setting press the ENTER button to confirm, use the UP/DOWN button to select

DMX Address or Channel Mode.

DMX Address —DMX512 address setting

To select DMX Address, press the ENTER button to confirm. Use the UP/DOWN button to

adjust the address from 001 to 512, press the ENTER button to store. Press the MENU button

back to the last menu or let the unit idle one minute to exit menu mode.

Channel Mode

To select Channel Mode, press the ENTER button to confirm. Use the UP/DOWN button to

adjust the address from 7 CH, 9 CH or 5 CH, press the ENTER button to store. Press the MENU

button back to the last menu or let the unit idle one minute to exit menu mode.

DMX State

To select DMX State, press the ENTERbutton to confirm, use the UP/DOWN button to select,

Blackout, Last State or Show.

Fixture Setting

To select Fixture Setting, press the ENTER button to confirm, use the UP/DOWN button to select

Light Mode, Constant Color, Dimmer Curve, Dimmer Speed or Fan Mode.

Light Mode

To select Light Mode, press the ENTER button to confirm. Use the UP/DOWN button to select

White Balance, press the ENTER button to store. Press the MENU button back to the last

menu or let the unit idle one minute to exit menu mode.

Constant Color

To select Constant Color, press the ENTER button to confirm. Use the UP/DOWN button to

select No or Yes, press the ENTER button to store. Press the MENU button back to the last

menu or let the unit idle one minute to exit menu mode.

Dimmer Curve

To select Dimmer Curve, press the ENTER button to confirm. Use the UP/DOWN button to

select Inverse Square, S-Curve, Optically Linear or Square Law, press the ENTER button to

store. Press the MENU button back to the last menu or let the unit idle one minute to exit

menu mode.

Mode 1 (Optically Linear): The increase in light intensity appears to be linear as DMX value is

increased.

Mode 2 (Square Law): Light intensity control is finer at low levels and coarser at high levels.

Mode 3 (Inverse Square Law): Light intensity control is coarser at low levels and finger at

highlevels.

Mode 4 (S-cure): Light intensity control is finger at low levels and high levels and coarser at

medium levels.

Dimmer Speed

To select Dimmer Speed, press the ENTER button to confirm. Use the UP/DOWN button to

select Smooth or Fast, press the ENTER button to store. Press the MENU button back to the

last menu or let the unit idle one minute to exit menu mode.

Fan Mode

To select Fan Mode, press the ENTER button to confirm. Use the UP/DOWN button to select

Auto or Silent, press the ENTER button to store. Press the MENU button back to the last menu

or let the unit idle one minute to exit menu mode.

Show Program

To select Show Program, press the ENTER button to confirm, use the UP/DOWN button to

select Set Scene Totals, Edit Scene Color, Fade Time, Hold Time or Zoom, use the UP/DOWN

button to adjust the value, press the ENTER button to store. Press the MENU button back to

the last menu or let the unit idle one minute to exit menu mode.
